Summary of Contents for Astar LTV-1701
- Page 1 17” TFT LCD TV 17” TFT LCD TV INSTRUCTION MANUAL INSTRUCTION MANUAL MODEL: LTV-1701 MODEL: LTV-1701...
-
Page 2: Table Of Contents
IMPORTANT SAFETY INSTRUCTIONS... PREFACE... WARNINGS AND CAUTIONS ... SPECIFICATIONS... ASSEMBLY DRAWINGS... INSTALLATION ... REMOTE CONTROLLER DESCRIPTION ..BATTERY INSTALLATION (REMOTE CONTROLLER UNIT) ... OPERATION INSTRUCTIONS ... TROUBESHOOTING... TABLE OF CONTENTS 9-12 15-23 24-25... -
Page 3: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTION 1.Read these safety instructions. 2.Keep these safety instructions. 3.Heed all warnings. 4.Follow all safety instructions. 5.Do not use this apparatus near water. 6.Clean only with dry cloth. 7.Do not block any ventilation openings. Install in accordance with the manufacturers instructions. 8.Do not install near any heat sources such as radiators, heat registers,stoves, or other apparatus (including amplifiers)that produce heat. -
Page 4: Important Safety Instructions
CAUTION TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK).NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. T h e s y m b o l i n d i c a t e s t h a t d a n g e r o u s v o l t a g e c o n s t i t u t i n g a r i s k o f e l e c t r i c s h o c k i s p r e s e n t w i t h i n t h i s u n i t . -
Page 5: Preface
Thank you very much for purchasing this TV. To enjoy your from the very beginning, read this manual carefully and keep it handy for ready reference. INSTALLATION Locate the TV in the room where light does not strike the screen Total darkness or a reflection on the picture screen can cause eyestrain. -
Page 6: Warnings And Cautions
WARNINGS AND CAUTIONS Warning High voltages are used in the operation of this television receiver. Do not remove the cabinet back from your set.Refer servicing to qualified service personnel. Warning To prevent fire or electrical shock hazard, do not expose the television receiver to rain or moisture. -
Page 7: Warnings And Cautions
Never stand on, lean on, or suddenly push the television or its stand. You should pay special attention to children. Serious injury may result if it should fall. Do not place your television on an unstable cart, stand, shelf or table. Serious injury to an individual , and damage to the television, may result If it should fall. -
Page 8: Specifications
Model LTV-1701 LCD panel 17 INCHES TFT LCD Television system NTSC-M/N PAL-M/N PAL-4.43MHz-50Hz NTSC-3.58MHz-60Hz SECAM-4.29MHz-50Hz AV system NTSC-4.43MHz-60Hz PAL-3.58MHz-60Hz Channel coverage VHF-L: VHF-H: UHF: Analog RGB mode 1280x1024/ 60Hz Resolution 1280X1024 Display Colour 16.0million colours Comb Filter Adaptive 2/4 line... -
Page 9: Assembly Drawings
1. Adjust the angle of the screen. The horizontal angle could be adapted to suit yourself. It¢s range is up to 40°. Seeing drawings below. 2. Hang the TV on the wall. Step1:Assemble 2 nails in the wall horizontally.The width between two nails is 164mm. Step2:Loose 6 screws in the rear cabinet and remove the pedestal. -
Page 10: Installation
INSTALLATION FRONT IR IR Dim:515*320mm( KEYS: 1.MENU: To enter main menu or enter the item where the cursor is. 2.CH+/CH-: Move cursor in the main menu or change channel in TV mode. 3.VOL+/VOL-: Adjust the item you select or adjust volume. 4.AUTO/EXIT: Act as AUTO adjustment hot key when OSD is not displayed. - Page 11 STEPS: 1. Connect Video Cable a. Make sure both the TV and computer are Powered-OFF. b. Connect the video cable to the computer. 2. Connect the Audio cable. 3. Connect power cord Connect the AC ADAPTOR to the TV, then to a properly grounded AC outlet. 4.
- Page 12 INSTALLATION ANTENNA -11-...
-
Page 13: Av Equipment
AV EQUIPMENT This TV provides 1 group of AV input, including one S-Videoand one group (YCbCr) for convenient connection to VCR,DVD or other video equipment. Please refer to the owner’s manual of the equipment to be connected as well. You can use the AV and YCbCr input terminals on TV set rear as follows. To audio with outputs... -
Page 14: Remote Control Description
DESCRIPTION OF REMOTE FUNCTIONS 1.POWER:turn on or off the TV 2.NUMBER BUTTONS 3.VOL+/- :adjust volume 4.CH+/- :change program forward/backward 5.MENU: access main menu 6.BUTTONS : move cursor in main menu 7.BUTTONS : adjust item you selected 8.DISPLAY: recall program number, system etc on the screen 9.RETURN: return to the last viewed program 10.INPUT: select external video source... -
Page 15: Battery Installation (Remote Controller Unit)
BATTERY INSTALLATION (DREMOTE SONCTOLUNIT) Insert Batteries Into the Remote Control 1. Remove the battery cover. 2. Insert the 2 AAA 1.5V batteries making sure the polarity (+ or -) of the batteries matches the polarity mark s Inside the uni t. 3. -
Page 16: Operation Instructions
All MENUs are shown below 1280x1024 1280x1024 1280x1024 1280x1024 OPERATION INSTRUCTIONS PART I (PC) 60Hz 60Hz 60Hz 60Hz -15- 1280x1024 60Hz 1280x1024 60Hz 1280x1024 60Hz 1280x1024 64K 60Hz... - Page 17 1280x1024 60Hz 1280x1024 60Hz 1280x1024 60Hz AUTO CONFIG: OPERATION INSTRUCTIONS PART I (PC) 1280x1024 1280x1024 1280x1024 -16- 60Hz 60Hz 60Hz...
-
Page 18: Operation Of Main Menu
OPERATION OF MAIN MENU There are 12 items listed in the main menu. Step1:Press menu to enter the main menu. Step2:press to select an item. Step3:press menu to enter this item. Step4:press to adjust this item. Item Contrast Brightness H.Position V.Position Clock Focus... -
Page 19: Tuning Procedure
TUNING PROCEDURE STEP 1 Turn on the TV. STEP 2 AUTO MEMORY 1. Press the MENU button on your TV (or remote controller) three times to enter TUNING menu. If it is in VIDEO/S-VEDIO/YCbCr /PC mode, it can't enter TUNING menu. 2. -
Page 20: Adjust Picture
SELECT COLOUR SYSTEM If the colour system setting is incorrect, the colour will be abnormal. 1.According to mentioned steps above, enter SETUP menu. 2.Enter colour system item by COLOUR SYS COLOUR SYS COLOR TEMP COLOR TEMP CC/V-CHIP CC/V-CHIP NOTE :There are 4 options in this item:AUTO,PAL,NTSC,SECAM. ADJUST PICTURE 1.According to mentioned steps above, enter PICTURE menu. -
Page 21: Select Language
SELECT LANGUAGE: 1.According to mentioned steps above, enter SETUP menu. 2.Select the LANGUAGE item to be adjusted by 3.Adjust the language you want by There are 5 languages:ENGLISH and SPANISH,PORTUGUESE,ITALIAN,FRENCH. COLOUR SYS COLOUR SYS COLOR TEMP COLOR TEMP CC/V-CHIP CC/V-CHIP SELECT TEMPERATURE 1.According to mentioned steps above, enter SETUP menu. - Page 22 CCD/VCHIP(CCD and VCHIP are in one menu-VCHIP SETTING menu) COLOR TEMP COLOR TEMP CC/V-CHIP CC/V-CHIP I Setting Closed Caption(CCD) 1.Press button to select Closed Caption item. 2.Press the button to select. You can select the caption data channel (C1/C2/C3/C4), the text service channel (T1/T2/T3/T4) or turn off the Closed Caption (Off).
-
Page 23: Part 2:Mpaa Rating Set-Up
OPERATION INSTRUCTIONS PART 2:MPAA RATING SET-UP To enable V-chip setting, you should set V-CHIP ENABLE to ON in VCHIP SETTING menu. Rating guidelines are provided by broadcast stations. Most television programs and television movies can be blocked by TV Rating and/or Individual Categories. Movies that have been shown at the theaters or direct-to-video movies use the Movie Rating System (MPAA) only. -
Page 24: Operation Instructions
PART 3:TV BLOCKING TV Parental Guidelines may have one or more letters added to the basic rating to let parents know when a show contains higher levels of violence, sex, adult language or suggestive dialogue: 1.Press button to select TV BLOCKING item. 2.Press button to enter into TV BLOCKING sub-menu. -
Page 25: Troubleshooting Guide
TROUBLESHOOTING GUIDE PART I (PC) This LCD TV has pre-adjusted using factory standard VGA timings. Due to the output timing differences among various VGA cards in the market, users may initially experience an unstable or unclear display whenever a new display mode or new VGA card is selected. - Page 26 PART II Incorporated in your TV receiver are the most up-to-date devices to eliminate interference. Local radiation however, can create disturbances which visibly affect your picture. Proper installation and a good aerial are your best safe- guards against these disturbances. Moving ripples across the screen are caused by nearby transmitting or receiving-short-wave radio equipment.
