Multiva 300C Operation And Maintenance Manual

Seeding drills
Hide thumbs

Advertisement

Quick Links

Download this manual
SEEDING DRILLS

Advertisement

loading
Need help?

Need help?

Do you have a question about the 300C and is the answer not in the manual?

Questions and answers

Related Manuals for Multiva 300C

Summary of Contents for Multiva 300C

  • Page 1 SEEDING DRILLS...
  • Page 3 CONTENTS 7.10...
  • Page 5 1 FOREWORD Use in accordance with the regulations...

  • Page 6: Ec Declaration Of Conformity

    2 EC DECLARATION OF CONFORMITY...
  • Page 7 3 RESPONSIBILITIES...

  • Page 8: Terms Of Warranty

    4 TERMS OF WARRANTY ’ ’...

  • Page 9: Safety Instructions

    5 SAFETY INSTRUCTIONS Warning decals...
  • Page 11 Hydraulics Protect yourself against oil and grease. Waste oil Accidents Cleaning the drill...

  • Page 12: Technical Data

    6 TECHNICAL DATA Model 300 C 400 C 300 DS 400 DS Working width cm Transport width cm Filling height cm Weight kg 4400 S 500 4400 5500 Hopper volume litres 3500 4800 3500 4800 Coulter weight kg 50-175 50-175 50-200 50-200 Tyre size...
  • Page 13 7 ADJUSTMENT AND OPERATION OF THE DRILL Seeding position DS ’...
  • Page 14 Seeding position C –...
  • Page 15 Adjusting the seeding depth of the precision coulter Precision coulter.
  • Page 16 Notches for depth adjustment.
  • Page 17 DS-model C-model Adjusting the C-coulter's seeding depth Seeding depth adjustment 0-7 cm...
  • Page 18 Performing a calibration test – – Disengagement of transmission. Protective cover for the transmission. Performing the calibration test.
  • Page 19 ’...
  • Page 20 Adjustment wheels of screw type Correct order and joining together of the calibration test trays.
  • Page 21 Performing a calibration test: remote control for fertiliser(OPTION)
  • Page 23 Position of the bottom flap Adjustment of bottom flap Notched scale for adjustment lever Metering units Verifying the seeding depth...
  • Page 24 7.10 Steerability of the tractor...

  • Page 25: Maintenance

    8 MAINTENANCE Preparations before the maintenance work Transmission Transmission chain...
  • Page 26 Transmission...
  • Page 27 ’ Module gears should be adjusted in lower position.The gas spring should not press the wheels to each other.

  • Page 28: Lubrication Points

    Lubrication points Lubricating the machine Precision coulter The joints of the precision coulter must be lubricated at intervals of 50 ha. During lubrication, check that the grease nipple is open and press the grease in until it extrudes from the joint. Wipe off the surplus grease.
  • Page 29 Joint sleeve for cover wheel. C-coulter The pivot points of the C-coulter must be lubricated at intervals of 50 ha. During lubrication, check that the grease nipple is open and press the grease in until it extrudes from the joint. Wipe off the surplus grease. The bearings of the disc coulters and the cover wheel are lubed-for-life, so they do not need to be lubricated.
  • Page 30 ’ Rear axle joint of the drill. Coulter weight shaft, precision coulter. Coulter weight shaft, Classic coulter Drawbar joint. Drawbar joint.
  • Page 31 Gearbox Check the gearbox oil level at least once during the operating season. The correct level is approx. 2 cm below the filler cap. Oils should be replaced at least every five years, so that the condensed water is pressed out of the gearbox. Right filling volume is approx. 1.3 liters. Use ISO VG32 grade hydraulic oil. Outside of the season adjust the gearbox control to the minimum position.
  • Page 32 Removing the coulter, side-wheel and disc coulter, and replacing their bearings ’...
  • Page 33 Side-wheel and disc coulter. Disc coulter and cover wheel. The side-wheel (part 4.1) and its arm (part 4.2) must be removed before the disc coulter on the left-hand side (part 4.3) can be removed. Remove the attachment bolt for the side-wheel arm (part 4.4) and pull the arm loose from the coulter frame.
  • Page 34 Removing the coulter from the C-model machine...
  • Page 36 Disconnecting the rear wheel set Removing the wheel set.
  • Page 37 Dismantling the wheel set for mending the tyre Dismantling the wheel set (left one). Dismantling the wheel set.
  • Page 38 Tyre pressure 8.10 Tightness of the bolts 8.11 Storing the drill...
  • Page 39 9 ACCESSORIES Front harrow Rear following harrow Disc-type tramline marker Front levelling board...
  • Page 40 Front disc harrow Centre-line marker Electric remote control for feeding of fertilizer Front packer...
  • Page 41 Level guards in the hopper 9.10 Hayseed hopper 9.11 Electric valve 3/8 9.12 Outer coulter tine 9.13 Inner coulter tine...
  • Page 42 10 RDS200 Drill control system Electromagnetic Compatibility (EMC) This product complies with Council Directive 2004/108/EEC when installed and used in accordance with the relevant instructions. IMPORTANT! READ THIS BEFORE USING THE RDS 200 SYSTEM The RDS 200 installation is a part of the Precision Farming System ("the System").
  • Page 43 10.1 Instrument...

  • Page 44: Main Screen

    10.2 MAIN screen...
  • Page 45 10.3 Tramlining status/functions Tramlines 10.4 Advancing the bout number...
  • Page 46 10.5 Holding the bout number 10.6 RATE screen...
  • Page 47 10.7 Setting /overriding the target rate 10.8 INFO screen...
  • Page 48 10.9 Tramlining 10.10 Metering Roll Status...
  • Page 49 10.11 Calibration of the remote control for fertiliser (OPTION)
  • Page 50 10.12 Alarm settings 10.13 Setting the feeding rate step in % for the remote control for fertiliser...
  • Page 51 10.14 Alarm Codes...
  • Page 53 11 Hydraulic schematic 300 DS / C...
  • Page 55 12 Hydraulic schematic 400 DS / C...

  • Page 57: Electrical Schematic

    13 Electrical schematic...
