- Page 1 USER MANUAL MAGNETIC - INDUCTIVE FLOWMETER Please read this manual before first use. The manufacturer reserves the right to make changes without prior notice. MIE Rev. 1.4, © ELA, spol. s r.o. www.elabrno.cz...
- Page 2 Notes …………………………………………………………………………………………………………………… …………………………………………………………………………………………………………………… …………………………………………………………………………………………………………………… …………………………………………………………………………………………………………………… …………………………………………………………………………………………………………………… …………………………………………………………………………………………………………………… …………………………………………………………………………………………………………………… …………………………………………………………………………………………………………………… …………………………………………………………………………………………………………………… …………………………………………………………………………………………………………………… …………………………………………………………………………………………………………………… …………………………………………………………………………………………………………………… MIE Rev. 1.4, © ELA, spol. s r.o. www.elabrno.cz...
-
Page 3: Table Of Contents
Connection and assembly .............................6 Magnetic – induction sensors ..........................6 Tolerance of built-in lengths..........................7 Signal cable (connection between sensor and converter of the MIE-S) ..............7 Sensor location and its position in piping......................8 Recommended positions for sensor installation ....................8 Recommendations for installation ........................9 Sensor grounding ..............................9... -
Page 4: Introduction
Introduction MIE magnetic-inductive flowmeters (compact version: MIE-C, separated version: MIE-S) are precise measuring devices intended for the measurement of liquid flow of electrically conductive media. The meters may be used for measurements, registration, dosing, mixing, etc. Applications Water management, drinking and waste water measurement ... -
Page 5: Technical Conditions
Technical conditions Measurement conditions Measurement is independent up on: Liquid temperature and pressure Liquid density and viscosity Solids contents Usual level of magnetic field interference For maintaining the MQI accuracy and reliability, it is necessary to meet the following conditions: ... -
Page 6: Main Unit Option
Main unit option Control and evaluation electronics is assembled into robust aluminium housing with IP67 protection, or in case of remote version, protection of sensor is IP68. Additional option (customer request): Multi-point calibration of the measuring range. The flowmeters are usually calibrated in 3 points. On the customer‘s request, the number of calibration points can be increased. -
Page 7: Tolerance Of Built-In Lengths
Tolerance of built-in lengths: DN 10 ÷ DN 150 → A ± 5 mm, DN 200 ÷ DN 1000 → A ± 10 mm Signal cable (connection between sensor and converter of the MIE-S): Signals which are transmitted from a sensor electrode circuit to the converter will be in a range of millivolts. -
Page 8: Sensor Location And Its Position In Piping
It is recommended that the flow direction should follow the arrow on the sensor cover; the converter is also preset for this direction. On the operating meter, it is possible to adjust the reverse flow direction by changing the MIE converter parameter. ... -
Page 9: Recommendations For Installation
Recommendations for installation To avoid any measurement errors which are caused by air bubbles or failures on the lining, pay attention to the following recommendations: During assembling correctly seat the sensor, tighten screws uniformly and move on a diagonal one after another. -
Page 10: Electrodes
Tightening all cable connection clamps and plug in all connectors. For MIE-S verify the completeness of the shipped set according to the serial numbers of sensor and converter. Verify proper supply voltage; see the label on the converter. -
Page 11: Packing And Transport
The delivery can be carried out by a public carrier, the transport of the customer or the import by the production organization. The costs are paid by the customer. Connection Sensor connection Control unit communication (compact version MIE – C) connection White Screen Connect the main unit to the Ethernet network... -
Page 12: Modbus Protocol
8 data bits, even parity, one stop bit. Each MIE register takes two MODBUS registers, i.e. each MIE register is 32 bits long. These 32 bits are interpreted as an integer with or without a sign or as a floating point number with single precision. Double precision floating point numbers are stored in eight bytes, so they are transmitted in four MODBUS registers. -
Page 13: Modbus Register
Modbus registers All registers are read only. For security reasons writing to registers is a bit more complex than reading, so the manufacturer provides configuration software which is free to charge. Address Type Name Unit Description [dec] [hex] 0064 unsigned int Slave address Slave device address in range from 1 to 247. -
Page 14: Declaration Of Conformity
Declaration of conformity Product: MQI 99 - C/S - SMART, MQU 99 - C/S - SMART, MHU 99 - C/S -SMART, MI, MIA, MIE, ESONIC, PU, CU Manufacturer: ELA, spol. s r.o. Headquarter: Mikulovská 1, 628 00 Brno Office, workshop: Sokolova 32, 619 00 Brno... -
Page 15: Specification
Specifications Option compact version separated version (sensor instalated under ground or under liquid level), fixed cable, cable length according to the order (max. 50 m) Nominal sizes flange DN 10 ÷ 1000 mm, without flanges DN 10 ÷ 100 mm Insulation class of excitation coils class E Connection... - Page 16 Headquarters / Service ELA, spol. s r. o. Sokolova 32 619 00 Brno Czech Republic Billing address ELA, spol. s r.o. Mikulovská 1 628 00 Brno Czech Republic IČO:46969063 DIČ:CZ46969063 More on: www.elabrno.cz/contacts...
