Bavis BavCom One on One Installation And Service Manual

Audio system

Advertisement

Quick Links

201 Grandin Road
Maineville, Ohio 45039
(513) 677-0500
TM
BavCom
One on One Audio System
Installation and Service Manual
Copyright 2020 E. F. Bavis & Associates, Inc.
Revised: 10/29/2020
All Right Reserved
PN: 00607011

Advertisement

loading
Need help?

Need help?

Do you have a question about the BavCom One on One and is the answer not in the manual?

Questions and answers

Summary of Contents for Bavis BavCom One on One

  • Page 1 201 Grandin Road Maineville, Ohio 45039 (513) 677-0500 BavCom One on One Audio System Installation and Service Manual Copyright 2020 E. F. Bavis & Associates, Inc. Revised: 10/29/2020 All Right Reserved PN: 00607011...
  • Page 3: Table Of Contents

    BavCom One on One Audio Table of Contents Features ..........................1 Installation ...........................2 Connecting Cable(s) Diagram .....................4 Adjustments .........................5 Troubleshooting ........................6 Installation & Service Tool List...................7...
  • Page 5: Features

    BavCom™ One on One Audio The BavCom™ One on One audio system lets one inside position talk to one remote position. Features  Full duplex operation  Electret condenser microphone  Proprietary closed back speaker for maximum efficiency and minimum feedback. ...
  • Page 6: Installation

    Installation Console: The console is designed to sit on the counter top. The speaker faces backward. The power comes from a UL Listed transformer supplied with the kit, part number 01521011. Plug the round end of the transformer provided into the round jack at the rear of the console. Plug the transformer into a 120vac outlet.
  • Page 7 Separate speakers are also available in a variety. 50mm with flush mounting plate which features integral grill, part number 09033121. 50mm with adapter plate to replace 4” speaker assembly, part number 02909992 Separate call buttons are available in various types. Call Button Replacement Kit, part number 00353991 Polyester identifying labels, part number 00207012 Composite cable, part number 02910011, is available by the foot.
  • Page 9: Adjustments

    Adjustment It is necessary to disassemble the console to adjust the gain controls. Disassembly of the console is done by removing the four screws on the bottom of the console that secure the top to the bottom. Carefully separate the two halves. For details on the location of the adjustments, see Figure 1.
  • Page 10: Troubleshooting

    Troubleshooting Audio doesn't work Outlet on? Transformer plugged in? Check for 24vac at connector end. No 24vac? Replace transformer. Still doesn't work? Replace console. No incoming (Assumes outgoing audio) Adjust gain. Doesn't work? Replace remote microphone. Doesn't work? Replace console speaker. Doesn't work? Replace audio board.
  • Page 11: Installation & Service Tool List

    Installation and service tool list for audio 1/8” And 3/8” Flathead Screwdrivers #0 And #2 Phillips Screwdrivers 1/16” And 3/32” Allen Wrenches 1/2" Open-End Wrench 1/4", 5/16”, 11/32”, 3/8”, And 1/2" Nut Drivers Wire Cutters Wire Strippers Wire Crimpers Volt Meter Electric Drill Drill Bits Level...
  • Page 12 Revisions: Date 3835 03/28/2003 4061 06/11/2003 8249 02/27/2007 13533 02/27/2012 21533 10/28/2020...
