Page 1: How To Use Your Dishwasher
How to use your dishwasher 1905, DW 955 AU/NZ Printed on paper friendly to the environment. -
Page 2: Table Of Contents
Contents How to use the machine The parts of the machine Loading the baskets Detergent Technical data How to use the Model 1905 6–7 Which programme should I use? Energy saving Options Reprogramming Display window Indicating lamps Fault tracing program... - Page 3 Open the door by pulling the handle forwards and upwards. Press the main on/off switch. Programme panel See pages 6–7 1905 Main on/off switch Knife basket (Not all models) Upper basket Lamp Lower basket Cutlery basket Detergent com- partment for...
-
Page 4: Loading The Baskets
Load the baskets Be careful when washing items made of certain materials (see page 12). Upper basket Load glasses, cups, bowls, small plates, saucers, long items of cutlery and carving knives into the upper basket. (Take care that sharp edges do not damage the plastic of the baskets.) The upper basket has two hinged racks. -
Page 5: Detergent
Check that the spray arms can rotate freely. How much detergent? Cutlery basket Load cutlery with the The amount of detergent required depends on the programme used and the water handles downwards and hardness (see below). as spread out as possible. Make sure that spoons do not 'nest' with each other. -
Page 6: Model 1905
How to use your Model 1905 Your Model 1905 is a dishwasher which is particularly convenient to use. It remembers the programme that was last used (programme 1–3), so you need only press the Start pushbutton to use it again. -
Page 7: Energy Saving
• Press the Start button The machine will start and work through the selected programme automatically. • Want to change your mind? If you want to change programme after you have started the machine, press Stop for 3 seconds. Then select a new programme by pressing the appropriate symbol. -
Page 8: Programme Options
Programme options Eco/Bio-function By pressing this button you lower the temperature in the pre-wash and main wash to 50° C and pro-longs the main wash by 15 minutes (programme 1–4) . In this way you lower the energy consumption. Use this button, when you use detergents with enzymes. -
Page 9: Reprogramming
NOTE: When you select an option ( • To activate and save an option, you must start a programme. The reason for this is to prevent children playing with the pushbuttons and changing the temperature etc.. By re-programming (extra rinse etc.) •... -
Page 10: Display Window
Too little water in the machine? The water level is correct when it reaches up to the marking of the lower spray pipe bearing, see picture. If there is insufficient water in the machine, it may be because the supply pressure is too low. -
Page 11: Indicating Lamps
The indicating lamps . . . The indicating lamps serve several purposes: besides showing the selected programme , they are also used if you need to trace a fault in the machine..display programme contents T indicating lamps show what a selected programme contains. For Normal wash, for example, the following lamps would be lit: . -
Page 12: Wash These Items With Care
Wash these items with care: Some items must not be machine-washed. There are several reasons: some materials cannot withstand the high temperature, while others can be damaged by the detergent used. China/porcelain marks Modern china or porcelain may be marked underneath with a code that indicates its suitability for machine washing. -
Page 13: Adjusting The Salt Dispenser
Dishwashers with water softeners: Topping up with salt The salt container in machines fitted with water softeners must be prefilled with water then salt before the machine is used for the first time. Use coarse salt or salt specially intended for use in dishwasher water softeners. The indicating lamp on the panel flashes if the machine is out of salt. -
Page 14: Care Of The Machine
Care of the machine The interior of the machine is manu- factured from stainless steel, which is kept clean through normal use. It may, however, be necessary to clean the strainers and spray arms at intervals. Fine filter Food residues caught by the fine strainer are flushed away automatically each time the machine is used. -
Page 15: If The Machine Won't Work
If the machine does not work If the machine does not work, check to see whether there is some simple fault that you can rectify your- self. Follow the instructions below. Aslo check page 11, Fault-tracing programme. Problem The machine will not start Water remains in the machine If the machine should overfill with water, the outlet pump... -
Page 16: Safety
Safety Door switch The machine has a door switch which turns off the power and stops the machine if the door should be opened while the machine is in use. The programme will continue when the door is closed. Note: If the door is open for more than 2 minutes during drying, the programme will be terminated. -
Page 17: Installation
Do as follows Load the baskets and fill with deter- gent. Choose the right programme Intensive wash Strong wash Normal wash Light wash Quick/Delicate wash Rinse programme Rinse & Hold Plate heating We reserve the right to make changes. Check that the .
