AsantéTalk Troubleshooting Guide
Package Contents
Most Common Problems & Questions
1) Power up sequence
2) din8 cable versus localtalk connectors
3) Compatible printers
4) Ethernet cables
5) Multiple localtalk devices
6) Appletalk drivers versus serial drivers
7) Filesharing
8) The AsantéTalk versus the Micro AsantéPrint
9) It still does not work!
Basic Configurations
1) One Mac and one printer
2) One Mac and multiple printers
3) The AsantéTalk and an Ethernet hub/switch.

Advertisement

loading

Related Manuals for Asante AsanteTalk

Summary of Contents for Asante AsanteTalk

  • Page 1 AsantéTalk Troubleshooting Guide Package Contents Most Common Problems & Questions 1) Power up sequence 2) din8 cable versus localtalk connectors 3) Compatible printers 4) Ethernet cables 5) Multiple localtalk devices 6) Appletalk drivers versus serial drivers 7) Filesharing 8) The AsantéTalk versus the Micro AsantéPrint 9) It still does not work! Basic Configurations 1) One Mac and one printer...
  • Page 2 AsantéTalk Contents A) The AsantéTalk box: B) A Yellow RJ45 UTP cross-over Ethernet cable: C) A silver RJ45 UTP Ethernet cable: D) A din8 to din8 serial cable:...
  • Page 3 E) Power transformer:...
  • Page 4 Most Common Problems & Questions 1) The AsantéTalk must be the last localtalk device powered up under any configuration. Completely connect and power up all localtalk devices. Now power up the AsantéTalk. Wait at least 30 seconds and then check to see if network resources are available.
  • Page 5 4) The yellow Ethernet cable versus the silver Ethernet cable. The yellow Ethernet cable is a “cross-over” cable. As such it is for use when the AsantéTalk is plugged directly into the Ethernet port of a Mac. The silver Ethernet cable is a “straight through” cable. It is to be employed when connecting the AsantéTalk into an Ethernet hub or switch.
  • Page 6 8) AsantéTalk versus Micro AsantéPrint The Micro AsantéPrint is an older version of the AsantéTalk with some additional features and some limitations. The Micro AsantéPrint is better suited for large networks with Appletalk zones. It includes a software program that allows you to select in which zone the device and its printers appear.

  • Page 7: Basic Configuration Instructions

    Basic Configuration Instructions: 1) 1 Macintosh and 1 printer. 1) Power up the Mac. 2) Take the YELLOW Ethernet cable (B) and connect one end into the Ethernet port of the Mac. Plug the other end into the AsantéTalk (A). 3) Power up the printer.
  • Page 8 6) Wait 30 seconds. 7) On the AsantéTalk, the power and “LI” lights should now be on solid. 8) Go to the Chooser in the Mac. Select the appropriate Appletalk driver for your printer. The window to the right should then show your printer. For questions on which driver should be selected, please contact your printers manufacturer.
