WSC 304 01
Smoke control unit
Operating manual / Technical information
Table of contents:
Safety information
Operating elements and fuse review
Technical function description
Technical data
Installation
Cable lengths table
Cable plan
Standard wiring diagram
Various wiring diagrams
Commisioning
Maintenance
Advertisement
Related Manuals for Window Master WSC 304 01
Summary of Contents for Window Master WSC 304 01
- Page 1 WindowMaster Control Systems Ltd. Kettering Parkway Wellingborough Road Kettering Northants NN15 6XR United Kingdom Tel.: +44 (0) 1536 510990 Fax: +44 (0) 1536 526321 WSC 304 01 install WMa 200547 0611-UK ©WindowMaster 2005, 2011 ®Windowmaster is a registered trademark used under licence by WindowMaster Group...
- Page 2 The devices have been inspected and manufactured in accordance with the European directives. A corresponding manufacturer's declaration is available. You are only authorised to use the devices if a conformity declaration is issued for the entire system. Smoke control unit - WSC 304 01...
- Page 3 Operating elements and fuse review WSC 304 01 ____________________________________________________________________________ Smoke control unit - WSC 304 01...
- Page 4 A malfunction in the cascaded smoke control units is detected via the 2 wire BUS cable. The malfunction is only displayed in the corresponding smoke control unit and in the break glass unit connected to the master smoke control unit. Smoke control unit - WSC 304 01...
- Page 5 Smoke control systems must be maintained by the builder at least once per year. The maintenance and check of the system must be documented in a test placard in the smoke control unit as well as in a logbook. Smoke control unit - WSC 304 01...
- Page 6 Display: The red alarm LED in the smoke control unit and the red LED in the break glass unit are lit. An alarm in the break glass unit (actuators “OPEN“ ) has priority over an ASV CLOSE signal. Smoke control unit - WSC 304 01...
- Page 7 Motor circuit (yellow) Flashes when Check motor end module and the motor interrupted, after approx. fuse Battery/load control See battery diagnosis See battery diagnosis (yellow) Smoke control unit - WSC 304 01...
- Page 8 Automatic closing in the ventilation mode according to preselected time (1 min. to 30 min.) after ventilation OPEN was actuated. Installation information: Fit the break glass units at a height of approx. 1.40 m of FF top edge. Smoke control unit - WSC 304 01...
- Page 9 Connect the connection cables in accordance with the terminal plan. Ensure that the connections are made correctly. Incorrect clamping, mixing up numbers or colours could lead to malfunctions of the central control or of the external components. Smoke control unit - WSC 304 01...
-
Page 10: Cable Lengths Table
(I) in amps x 2 Permissible cable length for the break glass unit supply cable when using..4x2x0.8mm: up to 200m The motor connection cable length to the junction box (or control module) must not exceed 10 m. Smoke control unit - WSC 304 01... -
Page 11: Cable Plan
Cable plan ____________________________________________________________________________ Smoke control unit - WSC 304 01... -
Page 12: Standard Wiring Diagram
Standard wiring diagram __________________________________________________________________________ Smoke control unit - WSC 304 01... -
Page 13: Various Wiring Diagrams
Various wiring diagrams ____________________________________________________________________________ Smoke control unit - WSC 304 01... - Page 14 Various wiring diagrams ____________________________________________________________________________ Smoke control unit - WSC 304 01...
- Page 15 The red alarm LED (also in the control unit) and the signal generator are OFF. Break glass unit (secondary) a) Check as described under 5). „Operation“, „Malfunction“ and the acoustic signal are missing! Smoke control unit - WSC 304 01...
- Page 16 If the start-up was unsuccessful (error with one of the test run processes), please refer to the chapter Function description Operating elements and fuse review . If necessary, check the wiring in accordance with the wiring diagram Smoke control unit - WSC 304 01...
- Page 17 All batteries coming with the smoke control unit as standard, have to be subjected to regular checks. Within the framework of the service, they have to be replaced after the specified 4 year operating period. Adhere to the laws governing the disposal of hazardous substances (e.g. batteries). Smoke control unit - WSC 304 01...
