- Page 1 Newline Chromebox A10 Commercial Computing Device Model: TCB-AC2 User Guide Doc Version Date Mar. 2020...
-
Page 2: Table Of Contents
2. Packing List ......................2-1. Standard Accessories 3. Product Introduction ........... 10 ............10 3-1. Getting started ............12 External View 3-2.............. 14 3-3. Dimensions ...... 15 Knowing your Newline Chromebox A10 3-4. 4. Contact Information............. 21 ……………………………………………………….. 5. Chrome care... -
Page 3: Disposal Instructions
Disposal Instruction (US) For conservation purposes, please do not throw this electronic device into the municipal trash bin when discarding. To minimize pollution of our environment, please recycle this product. 廃棄上の指示 より良い地球保護のために、電子機器を廃棄処分にする時は、ゴミ箱に捨てないで下さい。汚染 を最小限に抑え、地球環境の最大限の保護のために、製品をリサイクルして下さい。 廢棄及回收處理 為了保護環境，請勿將本產品當作一般廢棄物處理。為減少環境污染，維護地 球資源，本產品報廢時，請回收本產品。 FCC caution Non-modification Statement: Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. - Page 4 Instruktion til bortskaffelse (Danish) Af hensyn til vores miljø bedes De ikke bortskaffe denne elektroniske enhed i en almindelig affaldsspand. For at mindske forurening og sikre beskyttelse af miljøet bedes De genbruge produktet. Verwijderingsinstructie (Dutch) Om mogelijke schade aan het milieu of de menselijke gezondheid door ongecontroleerde afvalverwijdering te voorkomen, moet u dit elektronisch product scheiden van andere soorten afval en op een verantwoorde manier recyclen.
- Page 5 Istruzioni per lo smaltimento (Italian) Per una migliore salvaguardia del nostro pianeta, si prega di non gettare questo dispositivo elettronico nei normali rifiuti al momento dell'eliminazione. Per ridurre al minimo l'inquinamento ed assicurare la massima protezione dell'ambiente, si prega di riciclare il prodotto.
-
Page 6: Copyright
Copyright Copyright of this publication belongs to Newline. Newline reserves the right to change the content of this publication without obligation to notify any party of such changes or revisions. No part of this publication may be reproduced, transcribed, transmitted, translated into any... -
Page 7: Safety Instructions
1. Safety Instructions 1. Please read these safety instructions carefully. 2. Please keep this User's Manual for reference. 3. Please disconnect this device from its power source before cleaning. Do not use liquid or sprayed detergent for cleaning. Use a lightly moistened sheet or cloth for cleaning. -
Page 8: Energy Star Certification
ENERGY STAR is a U.S. Environmental Protection Agency voluntary program that helps businesses and individuals save money and protect our climate through superior energy efficiency. Newline products that have the ENERGY STAR logo complies with the ENERGY STAR standard. The monitor and computer are automatically set to sleep after 8 and 30 minutes of user inactivity. -
Page 9: Risk Of Overheating
Do not install Newline Chromebox A10 in an enclosed space. b. Be sure the heat sink that is on the top and both side of the Newline Chromebox A10 has at least 5cm of clear space for heat dissipation. -
Page 10: Packing List
2. Packing List 2-1. Standard Accessories 1. Newline Chromebox A10 x 1 2. Power adaptor x 1 3. Power cord x 1 4. Dual Band Antenna x2 5. DC-in jack holder x 1 6. HDMI cable holder x 2 7. Wall mount holder 8. -
Page 11: Product Introduction
3. Product Introduction 3-1 Getting started Connect the AC power cord to your power adapter • Connect the DC plug into your Newline Chromebox A10 DC input • port. Plug the AC power cord into a 100 V~240 V power source. - Page 12 NOTE: Power adapter information: • Input voltage: 100-240 Vac • Input frequency: 50-60 Hz • Rating output current: 3.42A / 65W, 4.74A / 90W • Rating output voltage: 19 V WARNING! The power adapter may become hot when in use. Do not cover the adapter and keep it away from your body.
-
Page 13: External View
3-2. External View Front View Side View 1. Kensington Lock 2. Wall Mounting Kit Screw Hole 3. Recovery Button... - Page 14 Rear View...
-
Page 15: Dimensions
3-3. Dimensions Unit: mm... -
Page 16: Knowing Your Newline Chromebox A10
3-4. Knowing Your Newline Chromebox A10 Power Button The power button allows you to turn the Newline Chromebox A10 on or off. You can use the power button to put your Newline Chromebox A10 to sleep mode or hold the clip in the power button for four (4) seconds to force shutdown the device. - Page 17 Recovery button If you need to invoke the Newline Chromebox A10 into Recovery mode, you can insert a paper clip and press the RECOVERY BUTTON and press the Power button. Release the RECOVERY BUTTON after a second. IMPORTANT! Performing a recovery on your Newline Chromebox A10...
- Page 18 Notice do not use the antenna reverse operation. Ethernet Wake on LAN (WOL) The WOL function on Newline Chromebox A10 thru Ethernet RJ45 connector is enabled by default for Sleep Mode, when the system is operating on AC mains power. (S5 power off not supported)
- Page 19 Note : The default WOL function will be restored after reboot. External Power Switch The external power switch at rear side of Newline Chromebox A10 allows you to extend the power switch base your demand, and you can decide your own switch specification and cable length depends on the...
- Page 20 The design of external power switch is a screw-less type spring clamp pluggable terminal block, you can insert a wire by press the button on the terminal, please refer to the procedure below. Step 1 Please prepare a pin or rod that hard enough for pushing the button on the terminal block Step 2 Push the button in the end and hold it Step 3 Insert the wire into the hole and make sure the stripped portion is...
- Page 21 DC-In Jack Holder & HDMI cable holder The DC-In jack holder & HDMI cable holder allows you to fix the DC-in jack & HDMI cable holder firmly on the Newline Chromebox A10, for various environment and location where the Newline Chromebox A10 be used, to prevent the DC-in &...
-
Page 22: Contact Information
5. Contact Information HEADQUARTERS (TX, USA) +1 888 233 0868 info@newline-interactive.com ASIA PACIFIC OFFICE (Taipei, Taiwan) +886 2 8228 2089 info_ap@newline-interactive.com EUROPE OFFICE (Madrid, Spain) +34 911169178 info_eu@newline-interactive.com INDIA OFFICE (Chennai) 1 800 419 0309 info.in@newline-interactive.com KOREA OFFICE (Seoul, South Korea) +82 2 2638 5140 koreainfo@newline-interactive.com... -
Page 23: Chrome Care
6. Chrome Care Please contact your authorized reseller or authorized distributor in the first instance for all warranty queries. For direct Newline Care in regard to Newline chrome products please see below: HEADQUARTERS (TX, USA) +1 888 233 0868 info@newline-interactive.com... - Page 24 Part No.: Doc. No.:...
