SB10000PW OWNER'S MANUAL
Medora Corp • 3225 Hwy 22• Dickinson, ND 58601
Ph +1 701 225 4495 • +1 866 437 8076 • Fax +1 701 225 0002 • www.medoraco.com
© 2017 Medora Corp. • Dickinson, ND
507_20161212
Contents
Safety Instructions ...............................
Introduction ..........................................
Operation and Features .......................
Troubleshooting....................................
Specifications .......................................
Model Drawing .....................................
Parts Identification ...............................
Warranty Statement .............................
1
4
5
14
23
26
29
30
31
32
33
