- Page 1 SUPER QUIET PORTABLE NEBULISER USER MANUAL MODEL: NEB04 Superfine Battery / USB Nebulise Any Time / Atomising Particles Powered Any Place er Manual.indd 1 2020/03/30 16:1...
-
Page 2: Table Of Contents
TABLE OF CONTENTS Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 Intended use . -
Page 3: Introduction
INTRODUCTION The mx™ Portable Nebuliser is a hand held device designed to assist with the treatment of respiratory conditions. The device uses Active Vibrating Mesh Technology, which works by converting medication prescribed by a medical physician into an aerosol of microscopic droplets that can be inhaled into the lungs . -
Page 4: Intended Use
INTENDED USE The mx™ Portable Nebuliser is a hand held device designed to assist with the treatment of respiratory conditions. The device uses Active Vibrating Mesh Medical purpose Technology, which works by converting medication prescribed by a medical physician into an aerosol of microscopic droplets that can be inhaled into the lungs . -
Page 5: Safety Precautions
SAFETY PRECAUTIONS READ ALL WARNINGS AND INSTRUCTIONS BEFORE YOU USE THIS DEVICE. As with any medical device, this product may become unusable due to an electrical outage, battery depletion or mechanical impaction. We recommend that you have spare batteries and a backup device available. When you use electrical products, always follow basic safety precautions. -
Page 6: Classification And Explanation Of Symbols
CLASSIFICATION AND EXPLANATION OF SYMBOLS Symbols Meaning Warning / Caution / Note Class II equipment Type BF equipment Consult instructions for use ON / OFF Button DC Power source (Direct Current) 40°C Operating temperature limits : 10° to 40° 10°C 70°C Storage and delivery temperature limits : -20°... -
Page 7: Package Contents And Overview
PACKAGE CONTENTS Check before use The following items should be included in the box. Please check all parts for visible damage. Replace any damaged parts before you use this device. In case of missing parts, malfunction or damage, please contact the store, or nearest dealer where you made your purchase. - Page 8 Main Unit medication cup. Light indications Green light on: During operation Orange light flash: Low power / Malfunction No light: Malfunction Battery Cover Bottom view (Model no. NEB04) Power Cable Jack Power Cable Jack Cover er Manual.indd 8 2020/03/30 16:1...
-
Page 9: How To Operate With Batteries
HOW TO OPERATE WITH BATTERIES This device can operate on two batteries Clean all parts of your portable nebuliser before use, after each use and after extended storage. 1. Insert the batteries - Turn the unit upside down, - Push back and pull up the battery cover to open it. - Page 10 4. Inhalation - Place the mouthpiece between your teeth, with your lips firmly sealed around the mouthpiece. - Press ON/OFF button on the top to turn on the device (light Indicator turns green). - Breathe in and out slowly ON / OFF Button through your mouth until aerosol formation stops.
-
Page 11: How To Operate With Adapter
HOW TO OPERATE WITH ADAPTER 1. Please choose DC 5V/1A adapter (not included), and the connection jack should match a plug with outer diameter of 3.5mm, interior diameter of 1.35mm, 9.5mm in length and positive polarity. 2. The adapter does not charge batteries. Please remove the batteries before using the adapter. -
Page 12: Cleaning And Disinfection
4. Inhalation - Place the mouthpiece between your teeth, with your lips firmly sealed around the mouthpiece. - Press ON/OFF button on the top to turn on the device (light Indicator turns green). - Breathe in and out slowly ON / OFF Button through your mouth until aerosol formation stops. - Page 13 6. Wash and rinse the medication cup with distilled water. 7. Shake off excess water and allow parts to be fully air dried on a clean, dry towel. 8. Use gauze or clean towel to wipe off stains on the main unit if necessary. 9.
- Page 14 Alcohol is highly flammable. Do not use alcohol in close vicinity of open fire or smoke. The following items are able to be disinfected using boiled water or alcohol Medication cup (with cover) Parts below are NOT to be disinfected using boiled water or alcohol Power adapter Nebuliser unit (The adapter might differ from that shown above.)
-
Page 15: Troubleshooting
TROUBLESHOOTING If any trouble occurs while you are using the device, please check the following lists first. Replace the batteries or use Low battery power the power adapter Stains on the electrode cause Use alcohol to clean a faulty connection electrodes Low atomisation Refer to cleaning and... -
Page 16: Specifications
SPECIFICATIONS Product mx™ Portable (Mesh) Nebuliser Model NEB04 Method of operation Active Vibrating Mesh Technology Power supply AA Battery x 2 and Power Adapter Power consumption <1 .5W** Vibrating frequency Approx. 117 kHz +/- 15% Nebulisation rate U0 .25 ml/min Particle size MMAD <...
