Portable Kerosene Heater
Owner's Manual for SX-B22A
APPEARANCE
STRUCTURE
Wick guide ring
Wick guide
Wick guide packing
Wick sleeve
Wick
Hook
Fixed tank
GENERAL SPECIFICATIONS:
Model
Heating Output
Fuel Consumption
Tank Capacity
Ignition
Size: (H)×(W)×(D)
Weight: (empty)
Ignition heater
Ignition device
Oil pin
Battery case
Oil pan
Fuel sign
Pendulum
Anti shock automatic
shut-off device
SX-B22A
2.24 kW (1,930 kcal/h)
0.218 L/h
4.0 liters
2.8V ignition plug: 2 "D" size dry cell batteries, 1.5V each
475 × 452 × 324 mm
7.2 kgs
1
Fuel feeding cap
Fuel gauge
FUEL TANK
Glass burner cylinder
Burner base
BURNER CHIMNEY
Lever

Advertisement

loading
Need help?

Need help?

Do you have a question about the SX-B22A and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for CORONA SX-B22A

  • Page 1 Portable Kerosene Heater Owner’s Manual for SX-B22A APPEARANCE STRUCTURE Wick guide ring Fuel feeding cap Ignition heater Wick guide Fuel gauge Ignition device Wick guide packing Wick sleeve Wick FUEL TANK Oil pin Hook Battery case Oil pan Fixed tank...
  • Page 2 12. Do not use the top of the heater for cooking or boiling water as it will affect the operation of the heater. Fuel tank Oil pin 2. Assembling your CORONA Heater Fixed fuel tank 1. Open the guard grille and Packing material...
  • Page 3 6. Adjusting the Wick During Operation The fuel contained in the tank will be totally gone after about in a few hours. 1. Adjustment of flame can be done by the wick con- trol dial: [When fuel level is high] [When fuel level is low] By watching condition of flame and red glow, adjust by the wick control dial.
  • Page 4 Portable Kerosene Heater Manufactured in Japan by CORONA CORPORATION Printed in Japan...
