- Page 1 ZEPHYR INSTRUCTION MANUAL...
- Page 2 Pilot’s Lounge area of our website at www.prismkites.com for a broad range of tips and instructional tools. The Zephyr is beautifully balanced, as comfortable floating on its back as it is in a stall. The same hand-wrapped graphite spars we use in our top-end competition kites give you a masterful touch.
-
Page 3: Parts Diagram
Removable Balance Weight + Leechline Wingtip Nock INCLUDED EQUIPMENT LIST SPECIFICATIONS Zephyr Kite Skill level: Intermediate - Competition Upper Spreader: 5 mm pultruded carbon tube Wing Span: 92.5” (235 cm) Female Lower Spreader – SkyShark 3PT Wind Range: 1 - 17 mph (1.6 - 27 kmh) Male Lower Spreader –... - Page 4 ASSEMbLY Assemble your Zephyr for flight as you would a typical sport kite: 1. Unfold the sail and lay it out on a flat surface face up. 2. Slide the upper and lower leading edge spars together at the ferrule hidden inside the leading edge pocket. The male ferrule is glued into the upper leading edge spar, and the lower leading edge slides onto it.
- Page 5 Adding weight also tames the kite in stronger winds (10+ mph) because the wind has to do more work to keep it flying. With weight, your Zephyr will fly slower and pull less hard as the breeze comes up, a nice bonus that lets you fly one kite in a wider wind range.
-
Page 6: Tuning Tips
YO-YO STOPPERS The Yo-Yo is an advanced trick in which you flip the kite on its back and then all the clipped on your leading edge between the upper and lower spreader elbows act as way around so that the lines are wrapped one or more times around the kite. Many hooks to catch your lines in a position that lets you steer the kite around in a rolled-up other radical combinations are possible based on the yo-yo. -
Page 7: Care And Repair
At Prism our warranty is pretty simple: if you’re not happy, we’re not happy, and we’ll do what it takes to make things right. If the retailer from whom you purchased is unable to help, drop us a line and we’ll get things sorted out. Damage due to normal wear and tear (or those occasional moments of stupidity) can almost always be repaired for a reasonable charge. - Page 8 PRIsM dEsIGNs INC. 4214 24TH AVE W. sEATTLE, WA 98199...
