- Page 1 INSTRUCTION MANUAL Cordless Jig Saw JV143D JV183D Read before use.
-
Page 2: Specifications
SPECIFICATIONS Model JV143D JV183D Length of stroke 18 mm 18 mm Strokes per minute (min 0 - 2,900 0 - 2,900 Blade type B type B type Max. cutting capacities Wood 65 mm 65 mm Mild steel 6 mm 6 mm... -
Page 3: Ec Declaration Of Conformity
Vibration Avoid body contact with earthed or grounded The vibration total value (tri-axial vector sum) deter- surfaces, such as pipes, radiators, ranges and mined according to EN62841-2-11: refrigerators. There is an increased risk of elec- Work mode : cutting boards tric shock if your body is earthed or grounded. - Page 4 Always wear protective goggles to protect When using the tool, do not wear cloth work your eyes from injury when using power tools. gloves which may be entangled. The entangle- The goggles must comply with ANSI Z87.1 in ment of cloth work gloves in the moving parts may the USA, EN 166 in Europe, or AS/NZS 1336 result in personal injury.
- Page 5 MISUSE or failure to follow the safety also void the Makita warranty for the Makita tool and rules stated in this instruction manual may cause charger. serious personal injury.
-
Page 6: Functional Description
Battery protection system FUNCTIONAL DESCRIPTION The tool is equipped with a battery protection system. This system automatically cuts off power to the motor to extend battery life. CAUTION: The tool will automatically stop during operation if the tool and/or battery are placed under one of the following •... - Page 7 Switch action CAUTION: • Always clean out all chips or foreign matter adhering to the blade and/or blade holder. Failure to do so may cause insufficient tightening of the blade, resulting in a serious personal injury. • Do not touch the blade or the workpiece imme- diately after operation; they may be extremely hot and could burn your skin. •...
-
Page 8: Dust Cover
Dust cover Bevel cutting ► 1 . Dust cover CAUTION: • Always be sure that the tool is switched off and CAUTION: the battery cartridge is removed before tilting • Always wear safety goggles even when operat- the base. ing the tool with the dust cover lowered. •... -
Page 9: Dust Extraction
► 1 . Dust cover 2. Hose Clean cutting operations can be performed by connect- ing this tool to a Makita vacuum cleaner. Insert the hose of the vacuum cleaner into the hole at the rear of the tool. Lower the dust cover before operation. - Page 10 2. Circular cuts Rip fence (optional accessory) When cutting circles or arcs of 170 mm or less in radius, install the rip fence as follows. CAUTION: • Always be sure that the tool is switched off and the battery cartridge is removed before installing or removing accessories.
-
Page 11: Optional Accessories
Only use accessory or attachment for its stated purpose. If you need any assistance for more details regard- ing these accessories, ask your local Makita Service Center. • Jig saw blades ► 1 . Aluminum base 2. Anti-splintering device •... - Page 12 Makita Europe N.V. Jan-Baptist Vinkstraat 2, 3070 Kortenberg, Belgium Makita Corporation 3-11-8, Sumiyoshi-cho, Anjo, Aichi 446-8502 Japan 885275A226 www.makita.com 20181115...
