- Page 1 UPM/EC Manual del Usuario User manual Code: 1276550 www.sodeca.com Doc. Num: 0000021532 (11/06/2020)
- Page 2 Fig. 1 Fig. 2 Fig. 3 Rotate the tabs and remove the filter...
- Page 3 Fig. 5 Fig. 4 Fig. 7 Fig. 6...
- Page 4 Power Model Power supply Filtros Filtros Filtros Filtros (r/min) dB(A) (kg) (F7+F9) (F7+H14) (F7+F9) (F7+H14) 200-240V 50/60Hz UPM/EC-310 1920 1450 200-240V 50/60Hz UPM/EC-400 1550 2200 1300 380-480V 50/60Hz UPM/EC-500 1250 1150 2990 3250 ¹ Recommended surface with 3 meters high local ²...
-
Page 5: Product Definition
All the documentation in this manual is the property of the manufacturer, and its total or partial reproduction is prohibited. 2. Product Definition UPM/EC: Mobile air purifying units, designed for cleaning and purifying indoor air and eliminating odours in any type of room. -
Page 6: Installation And Assembly
6. Installation and Assembly This equipment may only be installed by a qualified technician who is familiar with the installation, monitoring and maintenance of this type of equipment, and uses suitable tools. Mechanical • Prior to starting up the unit, make sure the following checks are carried out: Ensure the wheels are blocked and the unit is immobilised (Fig. - Page 7 Time programming setup: MODE is used to select the item you want to modify (day / period / setpoint) and UP and DOWN are used to modify the applicable value (time/setpoint). To disable the period, set the time to value --:--.
- Page 8 Operating status on/off (manual mode). Current time (programming mode). - In parameters mode indicates the value of the parameters. - In time programming mode indicates the time programmed to start-up or stop. Operating hours (HF + operating time): ...
- Page 9 Configurable parameters of the regulator To access the parameter mode, in normal operation press MODE continuously (approx. 2 s) until the user menu is displayed on the screen (time setting, time programming, identifier, parameters, operating time reset and regulator reset). The UP and DOWN keys are used to select par and press MODE to access the parameters mode at that very instant.
- Page 10 Time programming mode displays:...
-
Page 11: Maintenance
Time programming example: Start-up • After starting up the motor, it is important to check that the motor is rotating correctly, without vibrations, or unusual noises. • A check must be made to ensure that the motor's actual power consumption does not exceed the level stated on the equipment's label and that it does not heat up excessively. - Page 13 HEADQUARTERS Sodeca, S.L.U. Pol. Ind. La Barricona Carrer del Metall, 2 E-17500 Ripoll Girona, SPAIN Tel. +34 93 852 91 11 Fax +34 93 852 90 42 General sales: comercial@sodeca.com Export sales: ventilation@sodeca.com...
