- Page 1 INSTALLATION & OPERATING INSTRUCTIONS B-40/B-41 Modulating Temperature Controller For Raytherm™ Boilers & Water Heaters H2 514-4001 WH2 2100-4001 Catalog No. 5000.70 Effective: 12-21-11 Replaces: NEW P/N 241439 Rev. 1...
-
Page 3: Table Of Contents
CONTENTS The B-40 configuration is for modulating control with- out outdoor reset, and can be used on models H2 514-4001 and WH2 2100-4001. The B-41 configura- Introduction............3 tion adds the air sensor needed for outdoor reset function, and is for use on models H2 514-4001 only. User Interface............. - Page 4 Adjust the View menu, the View segment is displayed. To select the Adjust menu, press and hold all three but- To make an adjustment to a setting in the Controller, tons simultaneously for one second (see Fig. 3). The begin by selecting the Adjust menu by pressing and display then advances to the Adjust menu and the holding simultaneously all three buttons for one Adjust segment is turned on in the display.
-
Page 5: Sequence Of Operation
dIP Switch Setting Modes of Operation (Mode) The Controller allows for eight modes of operation in (A) Factory / Installer order to define the Controller operation and piping arrangement used. The piping arrangement can be categorized into primary or primary/secondary. The The Factory / Installer DIP switch is used to select mode of operation is selected using the MODE item in which items are available to be viewed and / or adjust-... - Page 6 Two Setpoints with Primary/Secondary Piping Mode 2 (Mode = 2) Mode 2 is designed for setpoint operation using Primary/Secondary piping (see Fig. 9). A CFH is avail- able to activate a setpoint for space heating. An indirect DHW override is available to activate a second setpoint for heating an indirect domestic hot water tank.
- Page 7 The outdoor air sensor must be located on the coldest OPTIONAL INTEGRAL PUMP side of the building in a shaded area out of direct sun- BOILER INLET SENSOR BOILER OUTLET light. SENSOR PUMP LOCATION EXTERNAL OPTIONAL INTEGRAL PUMP ON MODELS WITHOUT 0-10 VDC ALTERNATE INTEGRAL PUMP...
- Page 8 Auto differential If Auto Differential is selected, the control automatical- ly determines the best differential as the load changes, thereby improving efficiency. During light loads, the dif- ferential is increased to allow longer on and off times to reduce the potential for short-cycling. During large loads, the differential is narrowed thereby improving comfort in heating spaces by reducing temperature swing.
- Page 9 Heater Minimum (BOIL MIN) Integral compares the operating sensor temperature offset (error) to the heater target temperature over a period of time. The BOIL MIN is the lowest water temperature that the Controller is allowed to use as a heater target temper- Derivative determines how fast or slow the operating ature (e.g.
- Page 10 Mode 2, 5 and 7, and domestic Hot • During a DHW demand the boiler pump contact is closed unless Indirect DHW priority is selected. Water Override (dem 2) During Indirect DHW priority, the boiler pump con- tact is off. A CFH is required whenever heat is needed for the •...
- Page 11 Enable/disable (Modes 2, 5 and 7) Outdoor Start (OUTdR START) A CFH is generated when a voltage of 24 VAC is The OUTDR START temperature is the outdoor air applied across the Enable/Disable terminals (1 and 2). temperature at which the Controller provides the BOIL Once voltage is applied, the Controller turns on the START water temperature to the system.
- Page 12 0-10 VdC or 0-20mA External Input and 10 VDC, the heater target temperature varies lin- (Mode 7) early between 50ºF (10ºC) and 210ºF (99ºC). If a voltage below 1.5 VDC is received the heater target NOTE: Changing the boiler minimum and/or boil- temperature is displayed as “...
-
Page 13: Installation
INSTALLATION direct drive Input Signal An external heater sequencer provides a positive 0-10 The following describes field installation: VDC input signal to the controller +V input (terminal 10). The negative VDC signal is applied to the Com/- For field installation, this controller is shipped inside a input (terminal 9). - Page 14 Fig. 19: Control Box Locations...
-
Page 15: Troubleshooting
Sensor and Unpowered Input CAUTION: The sensor must be disconnected in Connections order to measure the correct ohms. Testing the Sensors (10 kΩ) NOTE: Do not apply power to these terminals as this damages the Controller. In order to test the sensors, the actual temperature at each sensor location must be measured. - Page 16 Sensor Resistance Resistance (Ω) Temperature (° ° ° ° F) 490,813 336,606 234,196 165,180 118,018 Fig. 21: Testing the Controller’s Outputs Testing the Controller’s 85,362 Outputs 62,465 46,218 The Controller has a built-in test routine, which is used to test the main control functions. The test sequence is 34,558 enabled when the button is pressed and held for 3...
-
Page 17: Wiring Connections
WIRING CONNECTIONS Fig. 22: Wiring Diagram Field Installation Field wiring must be connected to the terminal block below the controller inside the control box. Fig. 23: DIP Switch Location... -
Page 18: Controller Settings
CONTROLLER SETTINGS Tables F through S describe the “View” and “Adjust” menus. They also show the default settings as well as any possible adjustment ranges. VIEW MENU MOdE 2 (With default Settings Shown) The View menu items display current operating tem- peratures and system status information. - Page 19 AdJUST MENU MOdE 2 (Page 1 of 2) (With default Settings Shown) The Adjust menu items are the programmable settings used to operate the system. Press and hold all three buttons for one second to enter the Adjust menu, then select the desired item using the Item button.
- Page 20 AdJUST MENU MOdE 2 (Page 2 of 2) (With default Settings Shown) Item Field Access Description Range Settings MODULATION DELAY 10 to 230 seconds Select the rate at which the modulation signal Factory changes from the Minimum Modulation setting Default = 16 seconds to the Maximum Modulation setting.
- Page 21 VIEW MENU MOdE 3 (With default Settings Shown) The View menu items display current operating tem- peratures and system status information. Use the Item button (see Fig. 4) to view items in this menu. BOILER TARGET Factory – – –, 35 to 226°F, OFF The boiler target is the temperature the control is currently trying to maintain at the boiler supply sensor or the boiler Installer...
- Page 22 AdJUST MENU MOdE 3 (Page 1 of 2) (With default Settings Shown) The Adjust menu items are the programmable settings used to operate the system. Press and hold all three buttons for one second to enter the Adjust menu, then select the desired item using the Item button.
- Page 23 AdJUST MENU MOdE 3 (Page 2 of 2) (With default Settings Shown) Item Field Access Description Range Settings MODULATION DELAY 10 to 230 seconds Select the rate at which the modulation signal Factory changes from the Minimum Modulation setting Default = 16 seconds to the Maximum Modulation setting.
- Page 24 VIEW MENU MOdE 5 (With default Settings Shown) The View menu items display current operating tem- peratures and system status information. Use the Item button (see Fig. 4) to view items in this menu. OUTDOOR Factory -60 to 190°F Current outdoor air temperature as measured by the outdoor (-51 to 88°C) Installer sensor.
- Page 25 AdJUST MENU MOdE 5 (Page 1 of 2) (With default Settings Shown) The Adjust menu items are the programmable settings used to operate the system. Press and hold all three buttons for one second to enter the Adjust menu, then select the desired item using the Item button.
- Page 26 AdJUST MENU MOdE 5 (Page 2 of 2) (With default Settings Shown) Item Field Access Description Range Settings 70 to 220°F DHW BOILER TARGET (21 to 104°C) Factory Select the boiler target temperature while heating Default = 180°F an indirect DHW tank. (82°C) DHW MODE Select no priority (1) or priority (2) of indirect DHW...
- Page 27 VIEW MENU MOdE 7 (With default Settings Shown) The View menu items display current operating tem- peratures and system status information. Use the Item button (see Fig. 4) to view items in this menu. BOILER TARGET Factory – – –, 35 to 226°F, OFF The boiler target is the temperature the control is currently (–...
- Page 28 AdJUST MENU MOdE 7 (Page 1 of 2) (With default Settings Shown) The Adjust menu items are the programmable settings used to operate the system. Press and hold all three buttons for one second to enter the Adjust menu, then select the desired item using the Item button.
- Page 29 AdJUST MENU MOdE 7 (Page 2 of 2) (With default Settings Shown) MODULATION DELAY 10 to 230 secodns Select the rate at which the modulation signal Factory changes from the Minimum Modulation setting to Default = 16 seconds the Maximum Modulation setting. Modulation START MODULATION 0 to 50%...
- Page 30 VIEW MENU MOdE 8 (With default Settings Shown) The View menu items display current operating tem- peratures and system status information. Use the Item button (see Fig. 4) to view items in this menu. BOILER OUTLET Factory 14 to 266°F Current boiler outlet water temperature as measured by the (-10 to 130°C) Installer...
- Page 31 AdJUST MENU MOdE 8 (With default Settings Shown) The Adjust menu items are the programmable settings used to operate the system. Press and hold all three use the or ▼ button to make the adjustment (see buttons for one second to enter the Adjust menu, then Fig.
- Page 32 ALL MOdES ERROR MESSAGES (Page 1 of 2) The control was unable to read a piece of information from its EEPROM memory. The control will stop operation until all settings in the Adjust menu have been checked by the user or installer. To clear the error message, set Access Level DIP Switch A to Factory (on position), then check all Adjust menu items.
- Page 33 ALL MOdES ERROR MESSAGES (Page 2 of 2) OUTDOOR SENSOR SHORT CIRCUIT The control is no longer able to read the outdoor sensor due to a short circuit. In this case the control assumes an outdoor temperature of 32°F (0°C) and continues operation. Test the outdoor sensor and related wiring.
-
Page 34: Technical Data
TECHNICAL dATA qUICK START SET-UP & PROGRAMMING TIPS (Controller only) 1. Determine piping arrangement and mode number Microprocessor PID control; This is Controller as depicted on pages 5 through 7. not a safety (limit) control Enclosure Enclosure D, black Noryl plastic 2. - Page 36 www.raypak.com Raypak, Inc., 2151 Eastman Avenue, Oxnard, CA 93030 (805) 278-5300 Fax (805) 278-9725 Litho in U.S.A.
