- Page 1 HÜNNEBECK EPS Edge protection system User guide...
-
Page 2: Table Of Contents
Content Content Concrete solutions ....................6 Examples of concrete equipment ................7 EPS post an EPS post extra installation guide ............. 8 EPS Post/Extra installation ..................9 EPS Post sizes ......................11 EPS Clamp and EPS Latch installation guide ............12 EPS Clamp installation guide................. 13 EPS Latch installation guide ..................14 EPS Clamp and EPS Latch placement ..............15 EPS Clamp and EPS Latch installation guide ............16... - Page 3 HÜNNEBECK EPS High Visibility Footplate Ballast Bracket installation guide ......42 26.1 Ballast Bracket installation ....................42 26.2 Ballast Block installation.....................44 Free-Standing Footplate installation guide ............45 27.1 Free-standing footplate install ..................46 27.2 Distance from edge ......................48 27.3 Free-Standing Footplate spacing ................... 48 Access solutions .....................
- Page 4 43 Sacrificial Socket installation guide ..............82 43.1 Sacrificial Socket: installation ................... 83 43.2 Sacrificial Sockets spacing ....................84 43.3 Steel Frame Post install ..................... 85 44 Sacrificial Stub installation guide ................. 86 44.1 Sacrificial Stub: installation ....................87 44.2 Sacrificial Socket Spacing ....................88 44.3 Steel Frame Post install ..................... 89 Steel Frame Post installation guide ..............90 45.1 Steel Frame Post installation .....................
- Page 5 HÜNNEBECK EPS Adjustable Stair Rails insatallation guide ............131 58.1 Adjustable handrail installation ..................131 Debris Guards Landing and Stairs installation guide ........134 59.1 Debris Guard installation guide ..................135 60 Debris Guard Connector Bracket / Center Post Clip installation guide ..137 60.1 Debris Guard Connector Bracket ..................138 60.2 Debris Guard installation guide ..................140 General........................
-
Page 6: Concrete Solutions
Concrete solutions Concrete solutions Unless stated otherwise all dimensions are in mm... -
Page 7: Examples Of Concrete Equipment
HÜNNEBECK EPS Examples of concrete equipment Unless stated otherwise all dimensions are in mm... -
Page 8: Eps Post An Eps Post Extra Installation Guide
EPS post an EPS post extra installation guide EPS post an EPS post extra installation guide NA001 NA002 EU001 EU002 EPS Post EPS Post Extra Unless stated otherwise all dimensions are in mm... -
Page 9: Eps Post/Extra Installation
HÜNNEBECK EPS EPS Post/Extra installation WARNING! WARNING Disassembly process must follow the instructions in reverse order. Improper installation or removal could result in serious injury or death. Step 1 With handle held horizontal, raise inner post to contact ceiling. Step 2 Ensure the post is vertical using a magnetic spirit level and that all four points of the top and bottom grab plates are touching the floor/ceiling, push handle closed to fix in place. - Page 10 EPS Post/Extra installation Step 4 Slide safety latch down over locking ring until button pops out. Step 5 Feed zip tag through hole over safety latch. (Optional) ALLATION IMPORTANT: DISASSEMBLY PROCESS MUST FOLLOW THE INSTRUCTIONS IN REVERSE ORDER. IMPROPER INSTALLATION OR REMOVAL COULD RESULT IN SERIOUS INJURY OR DEATH. Step 6 Finished installation.
-
Page 11: Eps Post Sizes
HÜNNEBECK EPS EPS Post sizes WARNING! WARNING Disassembly process must follow the instructions in reverse order. Improper installation or removal could result in serious injury or death. EPS Post EPS Post extra EU001/NA001 EU002/NA002 Unless stated otherwise all dimensions are in mm... -
Page 12: Eps Clamp And Eps Latch Installation Guide
EPS Clamp and EPS Latch installation guide EPS Clamp and EPS Latch installation guide NA020 EU020 EPS clamp NA021 EU021 EPS latch Unless stated otherwise all dimensions are in mm... -
Page 13: Eps Clamp Installation Guide
HÜNNEBECK EPS EPS Clamp installation guide WARNING! WARNING Disassembly process must follow the instructions in reverse order. Improper installation or removal could result in serious injury or death. Step 1 Place clamp around post at specified height (see page 15). RAPID CLAMP INSTALLATION GUIDE RAPID CLAMP INSTALLATION GUIDE Step 2 Close clamp. RAPID CLAMP INSTALLATION GUIDE RAPID CLAMP INSTALLATION GUIDE STEP 1: PLACE CLAMP AROUND POST AT... -
Page 14: Eps Latch Installation Guide
EPS Latch installation guide EPS Latch installation guide WARNING! WARNING Disassembly process must follow the instructions in reverse order. Improper installation or removal could result in serious injury or death. Step 1 Place clamp around post at specified height (see page 15). ION GUIDE RAPID LATCH INSTALLATION GUIDE ION GUIDE RAPID LATCH INSTALLATION GUIDE Step 2 Close clamp. -
Page 15: Eps Clamp And Eps Latch Placement
HÜNNEBECK EPS EPS Clamp and EPS Latch placement WARNING! WARNING Disassembly process must follow the instructions in reverse order. Improper installation or removal could result in serious injury or death. EU002 EU001 Double height Triple height containment containment For panel installation, please see panel installation guide. Unless stated otherwise all dimensions are in mm... -
Page 16: Eps Clamp And Eps Latch Installation Guide
EPS Clamp and EPS Latch installation guide EPS Clamp and EPS Latch installation guide NA005 NA085 EU005 EU085 Half panel 1400 mm Quarter panel 12 Kg 655 mm 9.5 Kg NA003 EU003 Full panel 2900 mm 21.5 Kg To conform to Ansi/Asse a 10.18-2007, Post centers for the full panel must not exceed 2200 mm. Unless stated otherwise all dimensions are in mm... -
Page 17: Single Panel Installation Guide
HÜNNEBECK EPS Single Panel installation guide For double height panels or higher, please see overleaf. WARNING! WARNING Disassembly process must follow the instructions in reverse order. Improper installation or removal could result in serious injury or death. 11.1 Panel placement: EPS Post and Extra SINGLE PANEL INSTALLATION GUIDE SINGLE PANEL INSTALLATION GUIDE SINGLE PANEL INSTALLATION GUIDE... -
Page 18: Panel Placement: Standard Support Post
Single Panel installation guide 11.3 Panel placement: Standard Support Post ION GUIDE ON GUIDE ON GUIDE IMPORTANT: DISASSEMBLY PROCESS MUST FOLLOW THE INSTRUCTIONS IN REVERSE ORDER. IMPORTANT: DISASSEMBLY PROCESS MUST FOLLOW THE INSTRUCTIONS IN REVERSE ORDER. IMPORTANT: DISASSEMBLY PROCESS MUST FOLLOW THE INSTRUCTIONS IN REVERSE ORDER. TION GUIDE TION GUIDE ION GUIDE... -
Page 19: Double Height Installation Guidelines
HÜNNEBECK EPS Double height installation guidelines For double height or higher, EPS Latches and EPS Clamps must first be installed on EPS Posts, see EPS Latch and EPS Clamp installation guide. WARNING! WARNING Disassembly process must follow the instructions in reverse order. Improper installation or removal could result in serious injury or death. DOUBLE HEIGHT INSTALL GUIDELINES DOUBLE HEIGHT INSTALL GUIDELINES DOUBLE HEIGHT INSTALL GUIDELINES Step 1... -
Page 20: Dual Purpose Stand Installation Guide
Dual Purpose Stand installation guide Dual Purpose Stand installation guide NA007 EU007 Dual Purpose Stand Unless stated otherwise all dimensions are in mm... -
Page 21: Dual Purpose Stand Installation
HÜNNEBECK EPS 13.1 Dual Purpose Stand installation WARNING! WARNING Disassembly process must follow the instructions in reverse order. Improper installation or removal could result in serious injury or death. Step 1 Drill 2no. holes 115 mm deep to accept an Øm16 x 100mm bolt (thunderbolt or e quivalent), to manufacturers specification. Step 2 Screw 2no. Øm16 x 100 mm bolt (thunderbolt or equivalent) into holes and ensure they are tight. Unless stated otherwise all dimensions are in mm... -
Page 22: Slab Grab Installation Guide
Slab Grab installation guide Slab Grab installation guide NA008 EU008 Adjustable Slab Grab Adjustable from 100 mm to 375 mm Unless stated otherwise all dimensions are in mm... -
Page 23: Slab Grab Installation
HÜNNEBECK EPS 14.1 Slab Grab installation WARNING! WARNING Disassembly process must follow the instructions in reverse order. Do not remove by lifting standard support post. Close off working area below slab grab installation. Improper installation or removal could result in serious injury or death. Step 1 Place open Slab Grab over slab edge. SLAB GRAB INSTALLATION SLAB GRAB INSTALLATION SLAB GRAB INSTALLATION... -
Page 24: Slab Grab Spacing
Slab Grab spacing IMPORTANT: DISASSEMBLY PROCESS MUST FOLLOW THE INSTRUCTIONS IN REVERSE ORDER. DO NOT REMOVE BY LIFTING STANDARD SUPPORT POST. CLOSE OFF WORKING AREA BELOW SLAB GRAB IMPROPER INSTALLATION OR REMOVAL COULD RESULT IN SERIOUS INJURY OR DEATH. INSTALLATION. SLAB GRAB BRACKETS ARE ADJUSTABLE... -
Page 25: Standard Support Post Installation
HÜNNEBECK EPS Standard Support Post installation WARNING! WARNING Disassembly process must follow the instructions in reverse order. Improper installation or removal could result in serious injury or death. Step 1 Place post in slab grab socket. STANDARD SUPPORT POST INSTALL STANDARD SUPPORT POST INSTALL STANDARD SUPPORT POST INSTALL Step 2 Push EPS Pin through Slab Grab socket and post. -
Page 26: Curb Grab Installation Guide
Curb Grab installation guide Curb Grab installation guide NA009 EU009 Curb Grab Adjustable from 150 mm to 620 mm WARNING! WARNING Disassembly process must follow the instructions in reverse order. Improper installation or removal could result in serious injury or death. Step 1 Place fully extended Curb Grab over “curb”. CURB GRAB INSTALLATION CURB GRAB INSTALLATION Step 2 Remove the EPS Pin. - Page 27 HÜNNEBECK EPS STEP 1: STEP 2: Step 3 Move clamp foot into position nearest “curb''. STEP 1: STEP 2: PLACE FULLY EXTENDED CURB GRAB OVER REMOVE THE RAPID PIN. PLACE FULLY EXTENDED CURB GRAB OVER REMOVE THE RAPID PIN. Step 4 Insert EPS Pin.
-
Page 28: Curb Grab Spacing
Standard support post install 17.1 Curb Grab spacing Curb Grab brackets should be set out at no more than 1100 mm centres for half panels and 2700 mm centres for full panels. 2700 mm max. 1100 mm max. Standard support post install WARNING! WARNING Disassembly process must follow the instructions in reverse order. Improper installation or removal could result in serious injury or death. Step 1 Place post in Slab Grab socket. -
Page 29: Concrete Socket Base Intallation Guide
HÜNNEBECK EPS STEP 1: STEP 2: PLACE POST IN CURB GRAB SOCKET. Step 3 Rotate EPS Pin into locked position. STEP 3: IMPORTANT NOTE: ROTATE RAPID PIN INTO LOCKED THE RAPID PIN HAS A RED "LOCK" STICKER. THIS STICKER SHOULD BE HIDDEN WHEN PIN IS CORRECTLY INSTALLED. POSITION. -
Page 30: Concrete Socket Base Installation
Concrete Socket Base installation 20 Concrete Socket Base installation WARNING! WARNING Disassembly process must follow the instructions in reverse order. Improper installation or removal could result in serious injury or death. Step 1 Drill hole to accept 1no. Øm16 x 50 mm wedge anchor, to manufacturers specification. 200 mm Dimensions shown from edge are manufacturers minimum requirements, always refer to local building code when setting out edge protection. - Page 31 HÜNNEBECK EPS Step 3 Fit wedge anchor into hole with manufacturer approved equipment as specified. Step 4 Fix concrete socket base into anchor. Step 5 Ensure concrete socket base is tight using socket base wrench. Unless stated otherwise all dimensions are in mm...
-
Page 32: Standard Support Post Installation
Standard Support Post installation Standard Support Post installation Step 1 Place post into socket base. Step 2 Push EPS pin through socket base and post. Step 3 Rotate EPS Pin into locked position. Step 4 The EPS Pin has a red “lock” sticker. This sticker should be hidden when pin is correctly installed. -
Page 33: Universal Facemount Bracket - Concrete Installation Guide
HÜNNEBECK EPS 22 Universal Facemount Bracket - concrete installation guide NA043 EU043 Universal Facemount Bracket 22.1 Universal Facemount Bracket install WARNING! WARNING Disassembly process must follow the instructions in reverse order. Improper installation or removal could result in serious injury or death. Step 1 Drill 2no. Holes 115 mm deep to accept an Øm16 x 100 mm bolt (thunderbolt or e quivalent), to manufacturers specification. -
Page 34: Universal Facemount Bracket Spacing
Universal Facemount Bracket - concrete installation guide Step 2 Hold Facemount Bracket in place and screw 2no. Øm16 x 100 mm bolt (thunderbolt or equivalent) into holes and ensure are tight. Step 3 To adjust socket base, hold nut in place and unscrew socket base with wrench. Step 4 Adjust concrete socket base to suit slab. Step 5 Tighten concrete socket base with socket base wrench. 22.2 Universal Facemount Bracket spacing Universal Ffacemount Brackets should be set out at no more than 1100 mm centres for half panels and 2700 mm centres for full panels. -
Page 35: Standard Support Post Intall
HÜNNEBECK EPS 23 Standard Support Post intall WARNING! WARNING Disassembly process must follow the instructions in reverse order. Improper installation or removal could result in serious injury or death. STANDARD SUPPORT POST INSTALL STANDARD SUPPORT POST INSTALL STANDARD SUPPORT POST INSTALL Step 1 Place post in socket base. -
Page 36: Standard Support Post Installation Guide
Standard Support Post installation guide 24 Standard Support Post installation guide NA011 EU011 Standard Support Post Unless stated otherwise all dimensions are in mm... -
Page 37: Standard Support Post Install
HÜNNEBECK EPS 24.1 Standard Support Post install WARNING! WARNING Disassembly process must follow the instructions in reverse order. Improper installation or removal could result in serious injury or death. STANDARD SUPPORT POST INSTALL STANDARD SUPPORT POST INSTALL STANDARD SUPPORT POST INSTALL Step 1 Place post into socket base. -
Page 38: Steel Frame Post Installation
Standard Support Post installation guide 24.2 Steel Frame Post installation T INSTALL STEEL FRAME POST INSTALLATION ST INSTALL STEEL FRAME POST INSTALLATION Step 1 Lace post into socket. Step 2 Push EPS Pin through socket and Steel Frame Post. STEP 1: STEP 2: PLACE POST INTO SOCKET. -
Page 39: High Visibility Footplate Intallation Guide
HÜNNEBECK EPS 25 High Visibility Footplate intallation guide For use as demarcation only WARNING! WARNING Disassembly process must follow the instructions in reverse order. Improper installation or removal could result in serious injury or death. NA035 EU035 High Visibility Footplate HI-VISIBILITY FOOTPLATE INSTALL 25.1 High Visibility Footplate install Step 1... -
Page 40: Distance From Edge
High Visibility Footplate intallation guide Step 2 Screw concrete socket base into High Visibility Footplate. Step 3 Ensure concrete socket base is tight using socket base wrench. 25.2 Distance from edge When used for demarcation, footplates must be set a minimum of 2000 mm from any edge to ensure compliance with class a requirements of BS EN 13374:2013. 2000 mm 2000 mm 25.3 High Visibility Footplate spacing... -
Page 41: Standard Support Post Installation
HÜNNEBECK EPS 25.4 Standard Support Post installation Step 1 Place post in socket base. Step 2 Push EPS Pin through socket base and post. Step 3 Rotate EPS Pin into locked position. NOTE NOTE The EPS Pin has a red “lock” sticker. This sticker should be hidden when pin is correctly installed. -
Page 42: High Visibility Footplate Ballast Bracket Installation Guide
High Visibility Footplate Ballast Bracket installation guide 26 High Visibility Footplate Ballast Bracket installation guide For use as demarcation only NA093 EU093 Ballast Bracket WARNING! WARNING Disassembly process must follow the instructions in reverse order. Improper installation or removal could result in serious injury or death. 26.1 Ballast Bracket installation BALLAST BRACKET INSTALLATION Step 1... - Page 43 HÜNNEBECK EPS STEP 1: PLACE NARROW END OF BALLAST BRACKET INTO HI-VIS FOOTPLATE BENEATH SOCKET BASE. Step 2 Lower broad end of Ballast Bracket into High Vis Footplate. LLATION LLATION Step 3 Turn clamping bolt anti-clockwise until the Ballast Bracket is held firmly within the frame STEP 2: LOWER BROAD END OF BALLAST BRACKET INTO HI-VIS FOOTPLATE. of the High Vis Footplate.
-
Page 44: Ballast Block Installation
High Visibility Footplate Ballast Bracket installation guide BALLAST BLOCK INSTALLATION BALLAST BLOCK INSTALLATION BALLAST BLOCK INSTALLATION 26.2 Ballast Block installation Step 5 Place Ballast Block onto Ballast Bracket. STEP 5: PLACE BALLAST BLOCK ONTO BALLAST BRACKET. STEP 5: PLACE BALLAST BLOCK ONTO BALLAST BRACKET. Installation complete. -
Page 45: Free-Standing Footplate Installation Guide
HÜNNEBECK EPS 27 Free-Standing Footplate installation guide WARNING! WARNING Disassembly process must follow the instructions in reverse order. Improper installation or removal could result in serious injury or death. Unless stated otherwise all dimensions are in mm... -
Page 46: Free-Standing Footplate Install
Free-Standing Footplate installation guide 27.1 Free-standing footplate install Step 1 Place the Free-Standing Footplate onto the ground. FREE-STANDING FOOTPLATE INSTALL FREE-STANDING FOOTPLATE INSTALL FREE-STANDING FOOTPLATE INSTALL FREE-STANDING FOOTPLATE INSTALL Step 2 Place a DPS (as above) on the footplate over the Øm16 nuts. (Europe - m16) STEP 1: PLACE THE FREE-STANDING STEP 1: PLACE THE FREE-STANDING STEP 2: PLACE A DPS (AS ABOVE) ON THE STEP 2: PLACE A DPS (AS ABOVE) ON THE Step 3... - Page 47 HÜNNEBECK EPS ATE INSTALL FREE-STANDING FOOTPLATE INSTALL ATE INSTALL ATE INSTALL FREE-STANDING FOOTPLATE INSTALL FREE-STANDING FOOTPLATE INSTALL Step 5 Lift the hinged bracket so that the 25kg ballast weights can be added as shown below. ACE A DPS (AS ABOVE) ON THE STEP 5: LIFT THE HINGED BRACKET SO THAT THE 55lb/25kg BALLAST WEIGHTS CAN BE ADDED AS SHOWN ABOVE.
-
Page 48: Distance From Edge
Free-Standing Footplate installation guide 27.2 Distance from edge EPS recommends that any free-standing edge protection should be set a minimum of 2000 mm from any edge. 2000 mm 2000 mm 27.3 Free-Standing Footplate spacing Footplates should be set out at no more than 1100 mm centres for half panels and 2700 mm centres for full panels. -
Page 49: Access Solutions
HÜNNEBECK EPS 28 Access solutions Unless stated otherwise all dimensions are in mm... -
Page 50: Examples Of Access Solutions
Examples of access solutions 29 Examples of access solutions Unless stated otherwise all dimensions are in mm... -
Page 51: Elevator Gate / Lift Shaft Gate Installation Guide
HÜNNEBECK EPS 30 Elevator Gate / Lift Shaft Gate installation guide NA040 EU040 Elevator Shaft Gate Unless stated otherwise all dimensions are in mm... -
Page 52: Elevator / Lift Shaft Gate Installation
Elevator / Lift Shaft Gate installation Elevator / Lift Shaft Gate installation WARNING! WARNING Disassembly process must follow the instructions in reverse order. Improper installation or removal could result in serious injury or death. Step 1 Install EPS post or EPS post extra as set out in the EPS post and EPS post extra installation guide. - Page 53 HÜNNEBECK EPS Step 4 Place and install another EPS post or EPS post extra into open scaffold clamps at opposite side of gate. Step 5 Close and tighten scaffold clamps. GATE INSTALL IMPORTANT: DISASSEMBLY PROCESS MUST FOLLOW THE INSTRUCTIONS IN REVERSE ORDER. Step 6 Ensure door is left closed and locked with the key removed when not in use. IMPROPER INSTALLATION OR REMOVAL COULD RESULT IN SERIOUS INJURY OR DEATH.
-
Page 54: Typical Elevator Gate/Lift Shaft Gate & Panel Set Ups
Typical elevator gate/lift shaft gate & panel set ups 32 Typical elevator gate/lift shaft gate & panel set ups 33 Typical elevator gate/lift shaft gate enclosure set up Please note that elevator enclosures can be erected using EPS posts or EPS post extras on floor to ceiling heights up to 4.3 m. -
Page 55: Eps Gate Socket Base And Top Fix Installation Guide
HÜNNEBECK EPS 34 EPS Gate Socket Base and Top Fix installation guide NA053 NA054 EU050 EU051 EPS Gate EPS Gate Socket base Top fix The EPS Gate Socket Base can be used with most EPS products. Please contact EPS for details. 34.1 EPS Gate Socket Base install Step 1 Place EPS Gate into socket bases. -
Page 56: Eps Gate - Top Fix Install
EPS Gate Socket Base and Top Fix installation guide Step 3 Rotate EPS Pin into locked position. Step 4 Socket bases used to hold the EPS Gate should be set at 980 mm centres. 980 mm 34.2 EPS Gate - Top Fix install Step 1 Place EPS Gate a minimum of 60 mm back from the floor edge. Step 2 Fix EPS Gate using 4no.Ø8 x 80 mm heco-topix screw. Unless stated otherwise all dimensions are in mm... -
Page 57: Correct Hünnebeck Pin Installation
HÜNNEBECK EPS 34.3 Correct HÜNNEBECK Pin installation NOTE NOTE The EPS Pin has a red “lock” sticker. This sticker should be hidden when the pin is correctly installed. NOTE NOTE When properly installed, the base of the access gate should sit below slab level. Unless stated otherwise all dimensions are in mm... -
Page 58: Steel Frame Solutions
Steel frame solutions 35 Steel frame solutions Unless stated otherwise all dimensions are in mm... -
Page 59: Examples Of Steel Equipment
HÜNNEBECK EPS 35.1 Examples of steel equipment Unless stated otherwise all dimensions are in mm... -
Page 60: Webfix Bracket Intallation Guide
Webfix bracket intallation guide 36 Webfix bracket intallation guide NA042 EU087 EU089 EU042 300 mm 425 mm 560 mm Webfix Webfix Webfix EU088 EU090 EU086 300 mm” 425 mm 560 mm Rotated Rotated Rotated Webfix Webfix Webfix 36.1 Webfix bracket installation guide WARNING! WARNING Disassembly process must follow the instructions in reverse order. Improper installation or removal could result in serious injury or death. WEBFIX BRACKET INSTALLATION GUIDE Step 1 Drill Ø22 mm holes in web. (Unless pre-drilled steel) - Page 61 HÜNNEBECK EPS STEP 1: DRILL Ø22mm/ " HOLES IN WEB. Step 2 Bolt bracket to beam using m20 nuts and bolts, length to suit application. (UNLESS PRE-DRILLED STEEL) LATION GUIDE IMPORTANT: DISASSEMBLY PROCESS MUST FOLLOW THE INSTRUCTIONS IN REVERSE ORDER. IMPROPER INSTALLATION OR REMOVAL COULD RESULT IN SERIOUS INJURY OR DEATH.
-
Page 62: Webfix Bracket Spacing
STEP 3: FINISHED INSTALLATION. Webfix bracket intallation guide WEBFIX BRACKET SPACING WEBFIX BRACKETS SHOULD BE SET OUT AT NO MORE THAN 1100mm/3'6" CENTERS FOR HALF PANELS AND 2700mm/9' CENTERS 36.2 Webfix bracket spacing FOR FULL PANELS. Webfix brackets should be set out at no more than 1100 mm centres for half panels and 2700 mm centers for full panels. 1100 mm 2700 mm 36.3 Steel Frame Post installation Step 1... -
Page 63: Webfix Bracket Indexing Guide
HÜNNEBECK EPS 37 Webfix bracket indexing guide 37.1 Webfix bracket indexing guide WEBFIX BRACKET INDEXING GUIDE WEBFIX BRACKET INDEXING GUIDE Step 1 Remove EPS Pins & loosen wing nuts. Step 2 Adjust vertical and horizontal positions to suit. STEP 1: STEP 2: STEP 1: STEP 2: REMOVE RAPID PINS &... - Page 64 Webfix bracket indexing guide STEP 1: STEP 1: STEP 2: STEP 2: Step 3 Replace EPS Pins and tighten wing nuts. ADJUST VERTICAL AND HORIZONTAL ADJUST VERTICAL AND HORIZONTAL REMOVE RAPID PINS & LOOSEN WING REMOVE RAPID PINS & LOOSEN WING Step 4 Finished installation.
-
Page 65: Indexing Settings
HÜNNEBECK EPS 37.2 Indexing settings Vertical holes set 50 mm apart Horizontal holes set 25 mm apart Unless stated otherwise all dimensions are in mm... -
Page 66: Webfix Extension Bracket Installation Guide
Webfix Extension Bracket installation guide 38 Webfix Extension Bracket installation guide NA094 EU091 200 mm Extension Bracket NA092 EU092 400 mm Extension Bracket 38.1 Extension Bracket installation WARNING! WARNING Disassembly process must follow the instructions in reverse order. Improper installation or removal could result in serious injury or death. Step 1 Drill Ø22 mm holes in web (unless pre-drilled steel). - Page 67 HÜNNEBECK EPS Step 2 Bolt Extension Bracket to beam using m20 nuts & bolts, length to suit application. Step 3 Bolt Webfix Bracket to the extension bracket using m20 bolts. Step 4 Adjust vertical and horizontal positions to suit. NOTE NOTE Extension Brackets: a maximum of 1000 mm of extra overhang can be c reated using 2 x 400 mm & 1 x 200 mm Webfix Extensions brackets. Subject to application. Please contact EPS before use.
-
Page 68: Steel Frame Post Installation
Webfix Extension Bracket installation guide 38.2 Steel frame post installation Step 1 Place post in Webfix socket base. Step 2 Push EPS Pin through Webfix socket base and Steel Frame Post. Step 3 Rotate EPS Pin into locked position. NOTE NOTE The EPS Pin has a red “lock” sticker. This sticker should be hidden when pin is correctly installed. Unless stated otherwise all dimensions are in mm... -
Page 69: I-Beam Clamp Installation Guide
HÜNNEBECK EPS 39 I-Beam Clamp installation guide NA024 EU024 I-Beam Clamp Clamp adjustment 125 mm - 310 mm 39.1 I-Beam Clamp installation guide WARNING! WARNING Disassembly process must follow the instructions in reverse order. Improper installation or removal could result in serious injury or death. I-BEAM CLAMP INSTALLATION GUIDE I-BEAM CLAMP INSTALLATION GUIDE Step 1... -
Page 70: I-Beam Clamp Spacing
I-Beam Clamp installation guide STEP 1: STEP 1: STEP 2: STEP 2: Step 3 Slide clamp hook over flange. ENSURE CLAMP HAS SUFFICIENT ENSURE CLAMP HAS SUFFICIENT MOVE CLAMP ONTO BEAM, HOOK POST MOVE CLAMP ONTO BEAM, HOOK POST Step 4 Tighten clamp with wing nuts. CLEARANCE TO FIT OVER BEAM. -
Page 71: Steel Frame Post Install
HÜNNEBECK EPS 39.3 Steel Frame Post install Step 1 Place post into I-Beam Clamp socket base. Step 2 Push EPS pin through I-Beam Clamp socket base and standard support post. Step 3 Rotate EPS Pin into locked position. NOTE NOTE The EPS Pin has a red “lock”... -
Page 72: Beam Clamp Indexing Guide
I-Beam Clamp indexing guide 40 I-Beam Clamp indexing guide Unless stated otherwise all dimensions are in mm... -
Page 73: I-Beam Clamp Indexing Guide
HÜNNEBECK EPS 40.1 I-Beam Clamp indexing guide Step 1 Un-tighten wing nut and remove EPS Pin. I BEAM CLAMP INDEXING GUIDE I BEAM CLAMP INDEXING GUIDE I BEAM CLAMP INDEXING GUIDE I BEAM CLAMP INDEXING GUIDE Step 2 Move sliding post into desired position. STEP 1: STEP 1: STEP 2:... -
Page 74: Indexing Settings
I-Beam Clamp indexing guide 40.2 Indexing settings I-Beam holes set 50 mm apart Unless stated otherwise all dimensions are in mm... -
Page 75: Bolt On Steel Socket Installation Guide
HÜNNEBECK EPS Bolt on Steel Socket installation guide NA103 EU103 Bolt on Steel Socket Unless stated otherwise all dimensions are in mm... -
Page 76: Bolt On Steel Socket Installation
Bolt on Steel Socket installation guide 41.1 Bolt on Steel Socket installation WARNING! WARNING Disassembly process must follow the instructions in reverse order. Improper installation or removal could result in serious injury or death. Step 1 Drill 2 x Ø22 mm holes in top flange (Unless pre-drilled steel) Unless stated otherwise all dimensions are in mm... -
Page 77: Bolt On Socket Spacing
HÜNNEBECK EPS Step 2 Bolt socket to beam using m2o nuts and bolts, length to suit application. 41.2 Bolt on Socket spacing Bolt on sockets should be set out at no more than 1100 mm centres for half panels and 2700 mm centres for full panels. 1100 mm 2700 mm 41.3 Steel Frame Post installation Step 1 Place post in steel socket. Step 2 Push EPS Pin through steel socket and Steel Frame Post. - Page 78 Bolt on Steel Socket installation guide Step 3 Rotate EPS pin into locked position. NOTE NOTE The EPS Pin has a red “lock” sticker. This sticker should be hidden when pin is correctly installed. Unless stated otherwise all dimensions are in mm...
-
Page 79: Blind Bolts Installation Guide
HÜNNEBECK EPS 42 Blind Bolts installation guide Blind Bolt Unless stated otherwise all dimensions are in mm... -
Page 80: Blind Bolt Installation - Face Fix
Blind Bolts installation guide 42.1 Blind Bolt installation - face fix Step 1 Hold component in place against steel and insert Blind Bolts into the 22 mm holes with cam rotated so that bolt will fit. Step 2 Rotate bolt through 180° so that cam falls into the locked position. Step 3 Bolt component to the hollow section using blind bolt washers & nuts. Unless stated otherwise all dimensions are in mm... -
Page 81: Blind Bolt Installation - Top Fix
HÜNNEBECK EPS 42.2 Blind Bolt installation - Top Fix Step 1 Place product on the hollow section and insert blind bolts into the 22 mm holes with cam rotated so that bolt will fit. Step 2 Ensure that the cam falls into the locked position. Step 3 Bolt product to the hollow section using blind bolt washers & nuts. Unless stated otherwise all dimensions are in mm... -
Page 82: Sacrificial Socket Installation Guide
Sacrificial Socket installation guide 43 Sacrificial Socket installation guide Unless stated otherwise all dimensions are in mm... -
Page 83: Sacrificial Socket: Installation
HÜNNEBECK EPS 43.1 Sacrificial Socket: installation WARNING! WARNING Disassembly process must follow the instructions in reverse order. Improper installation or removal could result in serious injury or death. Step 1 Weld Sacrificial Socket to beam. SACRIFICIAL SOCKET: INSTALLATION SACRIFICIAL SOCKET: INSTALLATION SACRIFICIAL SOCKET: INSTALLATION SACRIFICIAL SOCKET: INSTALLATION Step 2 Install edge protection. -
Page 84: Sacrificial Sockets Spacing
TALLATION SACRIFICIAL SOCKET: REMOVAL Sacrificial Socket installation guide TALLATION SACRIFICIAL SOCKET: REMOVAL TALLATION SACRIFICIAL SOCKET: REMOVAL Step 5 Remove edge protection. Step 6 Remove socket at desired level. STEP 5: STEP 6: E PROTECTION. REMOVE EDGE PROTECTION. REMOVE SOCKET AT DESIRED LEVEL. SACRIFICIAL SOCKETS SPACING SACRIFICIAL SOCKETS SHOULD BE SET OUT AT NO MORE THAN STEP 5: STEP 6:... -
Page 85: Steel Frame Post Install
HÜNNEBECK EPS 43.3 Steel Frame Post install Step 1 Place post into Sacrificial Socket. Step 2 Push EPS Pin through Sacrificial Socket and Steel Frame Post. Step 3 Rotate EPS Pin into locked position. NOTE NOTE The EPS Pin has a red “lock” sticker. This sticker should be hidden when pin is correctly installed. -
Page 86: Sacrificial Stub Installation Guide
Sacrificial Stub installation guide 44 Sacrificial Stub installation guide Unless stated otherwise all dimensions are in mm... -
Page 87: Sacrificial Stub: Installation
HÜNNEBECK EPS 44.1 Sacrificial Stub: installation WARNING! WARNING Disassembly process must follow the instructions in reverse order. Improper installation or removal could result in serious injury or death. Step 1 Weld Sacrificial Stub to beam. SACRIFICIAL STUB: INSTALLATION SACRIFICIAL STUB: INSTALLATION SACRIFICIAL STUB: INSTALLATION SACRIFICIAL STUB: INSTALLATION Step 2 Install edge protection. -
Page 88: Sacrificial Socket Spacing
Sacrificial Stub installation guide LLATION SACRIFICIAL STUB: REMOVAL Step 5 Remove edge protection. ALLATION SACRIFICIAL STUB: REMOVAL LLATION SACRIFICIAL STUB: REMOVAL Step 6 Strike stub with hammer until stub is folded into socket base/removed. STEP 5: STEP 6: E PROTECTION. REMOVE EDGE PROTECTION. STRIKE STUB WITH HAMMER UNTIL STUB IS FOLDED INTO SOCKET BASE/REMOVED. SACRIFICIAL SOCKET SPACING STEP 5: STEP 6:... -
Page 89: Steel Frame Post Install
HÜNNEBECK EPS 44.3 Steel Frame Post install Step 1 Place post into Sacrificial Socket. Step 2 Push EPS Pin through Sacrificial Socket and Steel Frame Post. Step 3 Rotate EPS Pin into locked position. NOTE NOTE The EPS Pin has a red “lock” sticker. This sticker should be hidden when pin is correctly installed. -
Page 90: Steel Frame Post Installation Guide
Steel Frame Post installation guide 45 Steel Frame Post installation guide SF011 Steel Frame Post Unless stated otherwise all dimensions are in mm... -
Page 91: Steel Frame Post Installation
HÜNNEBECK EPS 45.1 Steel Frame Post installation WARNING! WARNING Disassembly process must follow the instructions in reverse order. Improper installation or removal could result in serious injury or death. Step 1 Place post into socket. Step 2 Push EPS Pin through socket & steel frame post. Step 3 Rotate EPS Pin into locked position. -
Page 92: Extension Post Installation Guide
Extension Post installation guide 46 Extension Post installation guide EU012 Extension Post Unless stated otherwise all dimensions are in mm... -
Page 93: Extension Post Installation Guide
HÜNNEBECK EPS EXTENSION POST INSTALLATION GUIDE 46.1 Extension Post installation guide WARNING! WARNING Disassembly process must follow the instructions in reverse order. Improper installation or removal could result in serious injury or death. Step 1 Remove cap from steel frame or standard support post. EXTENSION POST INSTALLATION GUIDE EXTENSION POST INSTALLATION GUIDE EXTENSION POST INSTALLATION GUIDE... - Page 94 Extension Post installation guide LATION GUIDE IMPORTANT: DISASSEMBLY PROCESS MUST FOLLOW THE INSTRUCTIONS IN REVERSE ORDER. LATION GUIDE IMPROPER INSTALLATION OR REMOVAL COULD RESULT IN SERIOUS INJURY OR DEATH. IMPORTANT: DISASSEMBLY PROCESS MUST FOLLOW THE INSTRUCTIONS IN REVERSE ORDER. Step 5 Place panel so that the top of the panel frame sits on the top hook of the extension IMPROPER INSTALLATION OR REMOVAL COULD RESULT IN SERIOUS INJURY OR DEATH.
-
Page 95: Extension Post Installation
HÜNNEBECK EPS 46.2 Extension Post installation Step 1 Place post in Steel Frame Post. Step 2 Push EPS Pin through extension post and Steel Frame Post. Step 3 Rotate EPS Pin into locked position. NOTE NOTE The EPS Pin has a red “lock” sticker. This sticker should be hidden when pin is correctly installed. -
Page 96: Timber Frame Solutions
Timber frame solutions 47 Timber frame solutions Unless stated otherwise all dimensions are in mm... -
Page 97: Examples Of Timber Equipment
HÜNNEBECK EPS 47.1 Examples of timber equipment Unless stated otherwise all dimensions are in mm... -
Page 98: Dual Purpose Stand Timber Installation Guide
Dual Purpose Stand timber installation guide 48 Dual Purpose Stand timber installation guide NA007 EU007 Dual Purpose Stand Unless stated otherwise all dimensions are in mm... -
Page 99: Dual Purpose Stand: Timber
HÜNNEBECK EPS 48.1 Dual Purpose Stand: timber WARNING! WARNING Disassembly process must follow the instructions in reverse order. Improper installation or removal could result in serious injury or death. Cross laminated timber (CLT) Step 1 Place Dual Purpose Stand at least 170 mm back from the edge of the CLT slab. Unless stated otherwise all dimensions are in mm... - Page 100 Dual Purpose Stand timber installation guide Step 2 Screw 4no. Ø8 x 80 mm Heco-Topix wood screws through the smaller holes. Unless stated otherwise all dimensions are in mm...
-
Page 101: Timber Socket Base Installation Guide
HÜNNEBECK EPS 49 Timber Socket Base installation guide NA010-TRI EU010-TRI Timber Socket Base Triangular NA010-SQU EU010-SQU Timber Socket Base Square Unless stated otherwise all dimensions are in mm... -
Page 102: Timber Socket Base Installation - Floor
Timber Socket Base installation guide 49.1 Timber Socket Base installation - Floor WARNING! WARNING Disassembly process must follow the instructions in reverse order. Improper installation or removal could result in serious injury or death. Step 1 Place center of Timber Socket Base 60 mm back from the floor edge. Step 2 Fix Timber Socket Base using 4no. Ø8/3 8 x 80 mm heco topix screws. Unless stated otherwise all dimensions are in mm... -
Page 103: Timber Socket Base Installation - Stair
HÜNNEBECK EPS 49.2 Timber Socket Base installation - Stair Step 1 Place center of Timber Socket Base 60 mm back from the floor edge with the “arrow” shape pointing outwards. Step 2 Fix Timber Socket Base using 3no. Ø8/3 8 x 80 mm heco topix screws. Unless stated otherwise all dimensions are in mm... -
Page 104: Standard Support Post Install
Timber Socket Base installation guide 49.3 Standard support post install Step 1 Place post into socket base. Step 2 Push EPS Pin through socket base & post. Step 3 Rotate EPS Pin into locked position. Unless stated otherwise all dimensions are in mm... -
Page 105: Adapter Faceplate Timber Installation Guide
HÜNNEBECK EPS 50 Adapter faceplate timber installation guide NA041 EU041 Adapter Faceplate Unless stated otherwise all dimensions are in mm... -
Page 106: Adapter Faceplate: Timber
Adapter faceplate timber installation guide 50.1 Adapter Faceplate: timber WARNING! WARNING Disassembly process must follow the instructions in reverse order. Improper installation or removal could result in serious injury or death. ADAPTER FACEPLATE: TIMBER ADAPTER FACEPLATE: TIMBER ADAPTER FACEPLATE: TIMBER Step 1 ADAPTER FACEPLATE: TIMBER Hold Adapter Faceplate in place against CLT edge. -
Page 107: Universal Facemount Bracket - Timber Installation Guide
HÜNNEBECK EPS Universal facemount bracket – timber installation guide EU043 Universal Facemount Bracket Unless stated otherwise all dimensions are in mm... -
Page 108: Universal Facemount Bracket Installation
Universal facemount bracket – timber installation guide 51.1 Universal Facemount Bracket installation WARNING! WARNING Disassembly process must follow the instructions in reverse order. Improper installation or removal could result in serious injury or death. Step 1 Hold Facemount Bracket in place against CLT edge. Step 2 Screw 5no. Ø8 mm x 140 mm Heco-Topix wood screws. -
Page 109: Uni. Facemount Bracket Spacing
HÜNNEBECK EPS Step 4 Adjust socket base to suit. Step 5 Tighten socket base with socket base wrench. 51.2 Uni. Facemount Bracket spacing Universal facemount brackets should be set out at no more than 1100 mm centres for half panels and 2700 mm centres for full panels. 1100 mm 2700 mm 51.3 Standard support post install Step 1 Place post in socket base. Step 2 Push EPS Pin through socket base and Standard Support Post. - Page 110 Universal facemount bracket – timber installation guide Step 3 Rotate EPS Pin into locked position. NOTE NOTE The EPS Pin has a red “lock” sticker. This sticker should be hidden when pin is correctly installed. Unless stated otherwise all dimensions are in mm...
-
Page 111: Standard Support Post Installation Guide
HÜNNEBECK EPS 52 Standard Support Post installation guide NA011 EU011 Standard Support Post Unless stated otherwise all dimensions are in mm... -
Page 112: Standard Support Post Install
Standard Support Post installation guide 52.1 Standard Support Post install WARNING! WARNING Disassembly process must follow the instructions in reverse order. Improper installation or removal could result in serious injury or death. Step 1 Place post into socket base. Step 2 Push EPS Pin through socket base & post. Step 3 Rotate EPS Pin into locked position. -
Page 113: Stair Protection
HÜNNEBECK EPS 53 Stair protection Unless stated otherwise all dimensions are in mm... -
Page 114: Examples Of Stair Equipment
Stair protection 53.1 Examples of stair equipment Unless stated otherwise all dimensions are in mm... -
Page 115: Newel Post Installation Guide
HÜNNEBECK EPS 54 Newel Post installation guide NA029 NA028 NA030 EU029 EU028 EU030 Newel Post Newel Post Newel Post Left hand Right hand Unless stated otherwise all dimensions are in mm... -
Page 116: Adjustable Handrail Installation
Newel Post installation guide 54.1 Adjustable handrail installation WARNING! WARNING Disassembly process must follow the instructions in reverse order. Improper installation or removal could result in serious injury or death. To ensure proper installation of standard Newel Posts, the anti-luce fittings must face away from the external edge. On flat surfaces, handrails and debris guards must always be installed facing away from the edge. Unless stated otherwise all dimensions are in mm... - Page 117 HÜNNEBECK EPS Right handed Newel Post: where uppermost anti-luce fitting Is facing north, lower anti-luce fitting faces west. Standard Newel Post: all anti-luce fittings aligned. Left handed Newel Post: where uppermost anti-luce fitting is facing north, lower anti-luce fitting faces east. To install Newel Posts to internal corners, working on the left hand side of a flight, at a corner, use a right handed Newel Post, then alternate thereafter until back onto a straight flight.
-
Page 118: Newel Post Installation
Newel Post installation guide 54.2 Newel Post installation Step 1 Place post in socket base. Step 2 Push EPS Pin through socket base and Newel Post. Step 3 Rotate EPS Pin into locked position. NOTE NOTE The EPS pin has a red “lock” sticker. This sticker should be hidden when pin is correctly installed. -
Page 119: Stair Clamp Installation Guide
HÜNNEBECK EPS 55 Stair clamp installation guide NA031 EU031 Stair clamp Unless stated otherwise all dimensions are in mm... -
Page 120: Stair Clamp Installation
Stair clamp installation guide 55.1 Stair Clamp installation WARNING! WARNING Disassembly process must follow the instructions in reverse order. Improper installation or removal could result in serious injury or death. STAIR CLAMP INSTALLATION STAIR CLAMP INSTALLATION Step 1 Rotate bracket to match stair. STAIR CLAMP INSTALLATION STAIR CLAMP INSTALLATION Step 2 Place bracket over stair. -
Page 121: To Reverse Stair Clamp Socket
HÜNNEBECK EPS 55.2 To reverse Stair Clamp Socket Step 1 Remove wing bolt & washer. TO REVERSE STAIR CLAMP SOCKET TO REVERSE STAIR CLAMP SOCKET TO REVERSE STAIR CLAMP SOCKET Step 2 Remove pivoting socket base. TO REVERSE STAIR CLAMP SOCKET TO REVERSE STAIR CLAMP SOCKET TO REVERSE STAIR CLAMP SOCKET Step 3... -
Page 122: Standard Newel Post Install
Stair clamp installation guide 55.3 Standard Newel Post install Step 1 Place post into clamp socket. Step 2 Push EPS Pin through socket and Newel Post. Step 3 Rotate EPS Pin into locked position. NOTE NOTE The EPS pin has a red “lock” sticker. This sticker should be hidden when pin is correctly installed. -
Page 123: Landing Post Installation Guide
HÜNNEBECK EPS 56 Landing Post installation guide NA061 EU059 Landing Post Unless stated otherwise all dimensions are in mm... -
Page 124: Landing Post Installation Guide
Landing Post installation guide 56.1 Landing Post installation guide WARNING! WARNING Disassembly process must follow the instructions in reverse order. Improper installation or removal could result in serious injury or death. Step 1 LANDING POST INSTALLATION GUIDE Rotate bracket to match slab edge. LANDING POST INSTALLATION GUIDE Step 2 Place bracket over slab. - Page 125 HÜNNEBECK EPS Step 3 Tighten clamp to slab. ATION GUIDE ATION GUIDE IMPORTANT: DISASSEMBLY PROCESS MUST FOLLOW THE INSTRUCTIONS IN REVERSE ORDER. IMPORTANT: DISASSEMBLY PROCESS MUST FOLLOW THE INSTRUCTIONS IN REVERSE ORDER. Step 4 Strike with hammer to ensure clamp is tight. IMPROPER INSTALLATION OR REMOVAL COULD RESULT IN SERIOUS INJURY OR DEATH.
-
Page 126: Stair Rail Connector Installation
Landing Post installation guide 56.2 Stair Rail Connector installation Step 1 Place Stair Rail Connector around post. Step 2 Close clamps around post. STAIR RAIL CONNECTOR INSTALL STAIR RAIL CONNECTOR INSTALL STAIR RAIL CONNECTOR INSTALL Step 3 Tighten clamp nuts. STAIR RAIL CONNECTOR INSTALL STAIR RAIL CONNECTOR INSTALL STAIR RAIL CONNECTOR INSTALL... -
Page 127: Stair Rail Connector Installation Guide
HÜNNEBECK EPS 57 Stair Rail Connector installation guide NA034 EU034 Stair Rail Connector Unless stated otherwise all dimensions are in mm... -
Page 128: Stair Rail Connector Install
Stair Rail Connector installation guide 57.1 Stair Rail Connector install WARNING! WARNING Disassembly process must follow the instructions in reverse order. Improper installation or removal could result in serious injury or death. Step 1 Place Stair Rail Connector around post. Step 2 Close clamps around post. - Page 129 HÜNNEBECK EPS Step 6 Tighten wing bolts. EPS Posts should be installed a minimum of 75 mm back from the edge of the l anding. Position post 83 mm back from intended handrail position before sliding arm out. Unless stated otherwise all dimensions are in mm...
-
Page 130: Eps Post And Stair Rail Connector Placement
Stair Rail Connector installation guide 57.2 EPS Post and Stair Rail Connector placement Stair Rail Connector can be rotated to suit left or right handed flights Step 1 Turn Stair Rail Connector over. Step 2 Firmly twist anti-luce fittings upright. Step 3 Stair Rail Connector ready for use. Stair Rail Connector can be extended from 190 mm to 335 mm. Set centre of upper handrail at 1000 mm high. Unless stated otherwise all dimensions are in mm... -
Page 131: Adjustable Stair Rails Insatallation Guide
HÜNNEBECK EPS 58 Adjustable Stair Rails insatallation guide SR0 (EU078/NA078) - 280 mm - 300 mm SR1 (EU060/NA060) - 390 mm - 440 mm SR2 (EU072/NA072) - 440 mm - 500 mm SR3 (EU073/NA073) - 500 mm - 590 mm SR4 (EU074/NA074) - 590 mm - 720 mm SR5 (EU033/NA033) - 720 mm - 930 mm SR6 (EU061/NA075) - 930 mm - 1300 mm SR7 (EU032/NA032) - 1300 mm - 2000mm SR8 - (EU062/NA062) - 1900 mm - 3000 mm 58.1 Adjustable handrail installation WARNING! WARNING Disassembly process must follow the instructions in reverse order. Improper installation or removal could result in serious injury or death. Step 1 Open anti-luce fitting. - Page 132 Adjustable Stair Rails insatallation guide Step 3 Place handrail over anti-luce fittings. Step 4 Close anti-luce fittings. Step 5 Secure the handrails with tie wraps through the anti-luce fittings. Step 6 To place lower handrail, repeat steps 1 to 5. Unless stated otherwise all dimensions are in mm...
- Page 133 HÜNNEBECK EPS Handrails and panels must be secured on the inside of the staircase. Anti-luce fittings on newel posts must face into the stairs. Unless stated otherwise all dimensions are in mm...
-
Page 134: Debris Guards Landing And Stairs Installation Guide
Debris Guards Landing and Stairs installation guide 59 Debris Guards Landing and Stairs installation guide DGL1 (EU047 / NA047) - 390 mm - 560 mm DGL2 (EU075 / NA079) - - 560 mm - 900 mm DGL3 (EU076 / NA076) - 900 mm - 1580 mm DGL4 (EU077 / NA077) - 1580 mm - 2890 mm DGS1 (EU064 / NA064) - 1320 mm - 1960 mm DGS2 (EU045 / NA080) - 1820 mm - 2940 mm DGS3 (EU067 / NA067) - 2820 mm - 4940 mm Unless stated otherwise all dimensions are in mm... -
Page 135: Debris Guard Installation Guide
HÜNNEBECK EPS 59.1 Debris Guard installation guide WARNING! WARNING Disassembly process must follow the instructions in reverse order. Improper installation or removal could result in serious injury or death. Step 1 Extend Debris Guard in place. Step 2 Place Debris Guards onto Debris Guard Connector Brackets. Step 3 Place pin through hole in Debris Guard Connector Bracketst. - Page 136 Debris Guards Landing and Stairs installation guide Where debris guards cover from landing to stair, 2 debris guard connector brackets are required at the junction newel post. Unless stated otherwise all dimensions are in mm...
-
Page 137: Debris Guard Connector Bracket / Center Post Clip Installation Guide
HÜNNEBECK EPS 60 Debris Guard Connector Bracket / Center Post Clip installation guide NA071 EU071 Centre Post Clip NA070 EU070 Debris Guard Connector Bracket Unless stated otherwise all dimensions are in mm... -
Page 138: Debris Guard Connector Bracket
Debris Guard Connector Bracket / Center Post Clip installation guide 60.1 Debris Guard Connector Bracket WARNING! WARNING Disassembly process must follow the instructions in reverse order. Improper installation or removal could result in serious injury or death. DEBRIS GUARD CONNECTOR BRACKET DEBRIS GUARD CONNECTOR BRACKET DEBRIS GUARD CONNECTOR BRACKET DEBRIS GUARD CONNECTOR BRACKET... - Page 139 HÜNNEBECK EPS Step 5 Open “gate” on Centre Post Clip. TOR BRACKET TOR BRACKET TOR BRACKET CENTRE POST CLIP INSTALLATION CENTRE POST CLIP INSTALLATION CENTRE POST CLIP INSTALLATION TOR BRACKET CENTRE POST CLIP INSTALLATION Step 6 Place Centre Post Clip over Newel Post. STEP 1: STEP 1: STEP 1: STEP 2:...
-
Page 140: Debris Guard Installation Guide
Debris Guard Connector Bracket / Center Post Clip installation guide 60.2 Debris Guard installation guide WARNING! WARNING Disassembly process must follow the instructions in reverse order. Improper installation or removal could result in serious injury or death. Step 1 Extend Debris Guard in place. Step 2 Place Debris Guards onto Debris Guard Connector Brackets. -
Page 141: General
HÜNNEBECK EPS General EPS-Edge Protection System (EPS) has been designed for quick installation of edge protection to buildings under construction. The EPS Post system precludes the need to drill the concrete slab and bolt post anchors in position. Installation time is cut dramatically, as is the removal when finished. EPS Posts can be fixed in place in seconds. EPS Post will fit between Slabs from 2000 mm to 3400 mm and EPS Post Extra will fit between Slabs from 2900 mm to 4300 mm. - Page 142 Notes Unless stated otherwise all dimensions are in mm...
- Page 143 HÜNNEBECK EPS Unless stated otherwise all dimensions are in mm...
- Page 144 Hünnebeck Deutschland GmbH Rehhecke 80 D-40885 Ratingen +49 2102 9371 info_de@huennebeck.com www.huennebeck.com The copyright in these instructions for assembly and use belongs to BrandSafway. All the trademarks named in these instructions for assembly and use are the property of BrandSafway, unless marked as third- party rights or identifiable as such in another way.
Need help?
Do you have a question about the Edge Protection system and is the answer not in the manual?
Questions and answers
