- Page 1 CineEye II User Manual v1.0...
-
Page 2: Product Features
Product Features High reliability dual band (2.4G and 5G) transmission Transmission range of up to 2000 feet Very low latency (<0.06 seconds) HDMI in and HDMI loop out High quality audio transmission Supports transmission to up to 4 receivers Camera Control supported Professional monitoring App for iOS and Android 1.3 inch OLED display DC and battery power supply supported... - Page 3 In the Box Transmitter x1 Receiver x1 Antenna x9 User manual x1 Hot/Cold shoe mount adapter x2...
- Page 4 CineEye 2 Pro Transmitter ① ② ⑨ ⑤ ⑥ ③ ⑦ ④ ⑩ ⑧ ⑪ ⑫ ⑬ ① 1/4 Screw ② Group Knob ③ Battery Lock ④ Camera Control Interface ⑤ 1.3 Inch OLED ⑥ Left Key ⑦ Right Key ⑧...
- Page 5 CineEye 2 Pro Receiver ① ② ⑨ ⑤ ⑥ ③ ⑦ ④ ⑩ ⑧ ⑪ ⑫ ④ EXI-IF ① 1/4 Screw ② Group Knob ③ Battery Lock ⑤ 1.3 Inch OLED ⑥ Left Key ⑦ Right Key ⑧ Menu/OK Key ⑨...
-
Page 6: Typical Application
Typical Application Diagram HDMI In HDMI Out Camera Transmitter Receiver Monitor Diagram HDMI Out Receiver Monitor HDMI In Camera Transmitter Mobile Devices Mobile Devices Mobile Devices... - Page 7 Typical Application Diagram HDMI Out Receiver Monitor HDMI Out Receiver Monitor HDMI In Transmitter Camera HDMI Out Receiver Monitor HDMI Out Receiver Monitor...
- Page 8 Operation Instructions Install Instructions 1. Install the antennas as demonstrated. 2. Use the hot/cold shoe mount adapter to install the CineEye 2 Pro onto the camera or camera cage. 3. Use a NP-F970/F750/F550 battery or DC source to power the CineEye 2 Pro. 4.
- Page 9 Operation Instructions OLED Display ① ④ ① Input video info ② Input audio info ② ⑤ ③ Current group setting ④ Battery level/DC input ③ ⑤ Connection status ⑥ Current 5G WiFi channel ⑥ Connection Status： Transmitter: The connection status indicates how many devices are connected, if no devices are connected the unit will display “0”.
- Page 10 Operation Instructions Channel Setting 1. Only the transmitter has the “Channel Setting” menu. 2. The default setting is “Auto” which means the transmitter will select a channel with the least interference automatically after power on. 3. If users want to select a channel manually, please follow below steps: Click “Menu” button to enter “Channel Setting”...
- Page 11 “12345678”. 3. Monitoring Return to Accsoon Go and ensure CineEye 2 Pro is selected, click “Monitor” to enter the monitoring page and you will be able to monitor the live feed of the camera. Note: CineEye 2 Pro has two WiFi signals, one is 2.4G and another is 5G, the 2.4G WiFi name is “CineEye2-Pro-GroupX”, please don’t connect to this WiFi.
-
Page 12: Specification
Specification Transmitter Receiver Video Input HDMI None Video Output HDMI HDMI 1080p 23.98/24/25/29.97/30/50/59.94/60fps 1080i 50/59.94/60fps Video Input Format 720p 50/59.94/60fps 480p 59.94/60fps Audio 44.1KHz/48KHz 16bit/24bit PCM Antenna Connector 4 RP-SMA Male Latency <0.06 seconds(Camera latency not included) OLED 1.3 inch OLED Transmission Power 17~20dBm Transmission Range... -
Page 13: Warranty
2. The warranty period for transmitter and receiver units is one year. Within the warranty period, if under the usage of instruction manual for any product problem Accsoon will offer repair service for free. - Page 14 Q&A 一.质保期限 Receive won’t connect to transmitter 接收机与发射机无法连接 1.Please make sure the transmitter and receiver have the same group setting. 2.Please check that all antennas are tightened well. 一.质保期限 No video displayed 不能显示图像 接收机与发射机无法连接 1.Please ensure the HDMI cable is plugged into the "HDMI In" port of the transmitter 2.Please check if the output format of the camera is compatible with the CineEye 2 Pro input formats and check if the camera has video output enabled via the HDMI port.
- Page 15 QC Inspector： More details about the product please visit www.accsoon.com This document is subject to change without notice. Accsoon is a trademark of Accsoon Technology Co., Ltd. Copyright 2020 Accsoon. All rights reserved...
- Page 16 Website:www.accsoon.com E-mail:support@accsoon.com Chengdu Accsoon Technology Co.,Ltd...
