- Page 1 CONSOLE SATURN WP User’s Manual 3403.504.02 Version 2.6 Edition February 2020...
- Page 2 Caution and safety precautions Never use any other charger than the supplied or a type approved by Swiss Timing. This could destroy the battery, cause damage to unit, and possible cause personal injury due to fire or/and electrical shock. ...
-
Page 3: Table Of Contents
CONSOLE SATURN WP TABLE OF CONTENTS INTRODUCTION......................1 Set-up ........................... 1 General view ......................... 2 MAIN MENU ......................... 3 [CONSOLE SET] PARAMETERIZATION OF THE CONSOLE ......3 Test ..........................4 Ext Start/Stop – External Start/Stop with 3 point socket ..........4 3.2.1 Start/Stop of play time with Saturn console ............ - Page 4 [Settings] Choose the settings for a sport ............15 [Save] Save the sports settings ................17 [Standard] Change the standard settings for a sport ........... 17 [All Def & Save] Reset the standard settings for all sports ........17 [PLAY] MATCH ....................18 Sports with game time ....................
- Page 5 / CONSOLE SATURN WP 11.1 Version history ......................29 Version 2.6 3403.504.02 Page 5...
-
Page 7: Introduction
CONSOLE SATURN WP INTRODUCTION Swiss Timing offers a selection of Calypso scoreboards which are especially suitable for Waterpolo. The selection of the Calypso scoreboards can be done from one ergonomic console. The keyboard of the console has partially alphanumeric and functional keys. This makes the use for the operator comfortable. This manual is valid for the version of the software mentioned on the title page. -
Page 8: General View
1.2 General view The keyboard consists of three types of keys : The alphanumeric keys. The keys with one function. The keys with more functions. Escapes the function or the menu without validating the Manual horn possible modifications (ESCAPE) Chooses the second function Confirms the application or the... -
Page 9: Main Menu
CONSOLE SATURN WP MAIN MENU When you switch on, the main menu Select appears. It shows the selected sport, the time and date, as well as the main menus: Waterpolo Console set refer to chapter: 3 Time refer to chapter: 4 Select refer to chapter: 5 25/07/12 10:44.54... -
Page 10: Test
3.1 Test This function sends a test program to the scoreboard and appears on the display of the console. Press the ESC key to exit the program. THIS FUNCTION DOESN'T WORK ON ALL TYPES OF SCOREBOARD 3.2 Ext Start/Stop – External Start/Stop with 3 point socket These ports allow releasing the start of the match time and the shot clock with an external trigger. -
Page 11: Start/Stop Of Play Time With External Start/Stop Command
CONSOLE SATURN WP 3.2.2 Start/Stop of play time with external Start/Stop command Sport / Settings / Shotclock Console set Advance Advance Last sec Ver. 1.31 0 Ver. 5.02 0 Advance Shot clock Ver. 5.02 0 Test Test Value in Seconds 30 Ext. -
Page 12: Start/Stop Of Play Time With Saturn Console And Shot Clock 30S/20S Reset With External Start/Stop Command
3.2.3 Start/Stop of play time with Saturn console and Shot clock 30s/20s reset with external Start/Stop command Sport / Settings / Shotclock Console set Advance Advance Last sec Ver. 1.31 0 Ver. 5.02 0 Advance Shot clock Ver. 5.02 0 Test Test Value in Seconds 30... -
Page 13: Start/Stop Of Play Time And Shot Clock 30S/20S Reset With External Start/Stop Command
CONSOLE SATURN WP 3.2.4 Start/Stop of play time and Shot clock 30s/20s reset with external Start/Stop command Console set Sport / Settings / Shotclock Advance Advance Last sec Advance Ver. 1.31 0 Ver. 5.02 0 Shot clock Ver. 5.02 0 Test Test Value in Seconds 30... -
Page 14: Start/Stop Of Play Time With External Start/Stop Command And Shot Clock 30S/20S Reset With A Second External Start/Stop Command
3.2.5 Start/Stop of play time with external Start/Stop command and Shot clock 30s/20s reset with a second external Start/Stop command Sport / Settings / Shotclock Console set Advance Advance Last sec Ver. 1.31 0 Ver. 5.02 0 Advance Shot clock Ver. -
Page 15: Start/Stop Of Play Time With External Start/Stop Command And Start/Stop And Shot Clock 30S/20S Reset With A Second External Start/Stop Command
CONSOLE SATURN WP 3.2.6 Start/Stop of play time with external Start/Stop command and Start/Stop and Shot clock 30s/20s reset with a second external Start/Stop command Sport / Settings / Shotclock Console set Advance Advance Last sec Ver. 1.31 0 Ver. 5.02 0 Advance Shot clock Ver. -
Page 16: External Time Out Set By Trainer
3.2.7 External time out set by trainer Sport / Settings / Time Out Console set Advance AutoClear Advance Advance Ver. 1.31 0 Ver. 5.02 0 On Clock Ver. 5.02 0 Test Test Number: 3 Ext. Auto Ext. Timeout Start / Stop Ext Name Duration: 60 Name... -
Page 17: Advance - Board Configuration
CONSOLE SATURN WP 3.3 Advance - Board configuration This menu allows configuring the message sent to the board according to the model and use. 3.3.1 Bluetooth configuration The "BT" key allows you to select the Bluetooth scoreboards which have to be wireless connected to this console. -
Page 18: Sending The Players Names
3.4.2 Sending the players names If the "Send Player" box is ticked (), the players names will be sent when entering the match (the message "Wait for data transmission" will appear on the screen during a few seconds). Tick this box only if you have the optional modules "Players Names" (not available in Calypso Waterpolo version). -
Page 19: Update The Software
CONSOLE SATURN WP Update the software The SATURN line allows the download of a new software version in case there are rule changes in the different sports. Follow the procedure displayed on the screen: Operating of the console: Connect the console to the serial port RS232 of the computer (Cable Sub-D 9 poles male-female pin to pin [Swiss Timing article No. -
Page 20: Time] Day Time
[TIME] DAY TIME This menu allows you to introduce the date and day time. Only the day time can be transmitted to a SATURN scoreboard. Select the needed function key: For the selection of the date For the selection of the hours selection For the selection of the month minutes... -
Page 21: Select] Games Parameters
CONSOLE SATURN WP [SELECT] GAMES PARAMETERS The selection and back up of the various games parameters (Duration of the period, horn, direction of clock counting) are done in this menu. Choose the required sport with the keys. The scrolling is bigger than the size of the display. Therefore, if you press on the key from the position Waterpolo, other sports will also be... - Page 22 [Shot clock] Selection menu of the ball possession timers' parameters. [Shot clock] Possession timers connected. Possession timers not connected. [Value in Seconds] Duration of the possession in seconds. [No stop] Does not stop the playtime when the possession time reaches 0. Automatically stops the game time when the possession time reaches 0.
-
Page 23: Save] Save The Sports Settings
CONSOLE SATURN WP [Setting Horn] Selection and duration of the horn at the end of a period, pause and timeout. Duration in seconds of the horn (on the board) at the end of [Period: x] each period (introduce 0 if no horn is wished at the end of each period). -
Page 24: Play] Match
[PLAY] MATCH This menu allows you to start a game. You must first select the sport you want in the menu [Select]. Arrange the keys on the sport you want and press . The Saturn software is now activated in the main menu and the image of the selected sport is displayed in the middle of the screen. -
Page 25: Start The Period
CONSOLE SATURN WP Modify the period Modify the Game Time during the game B. Display of the home team (HOME or a name introduced in the console’s settings). C. Display of the visitors team (VISITOR or a name introduced in the console’s settings). Home Visitor Description... -
Page 26: Introduction Of A Fault
6.1.3 Introduction of a fault As soon as a player receives a penalty, it is possible to introduce all the team penalties, as well as the amount of personal penalties (depending on the settings selection). Press the key (Home or Visitor), to increase the team penalties. ... -
Page 27: Introduction Of A Time Out
CONSOLE SATURN WP 6.1.5 Introduction of a Time Out In the time out settings [Time out] of [Settings] Choose the settings for a sport, you can choose your parameters. To display a time out during a game, the START/STOP switch must be on STOP; then press the function key (Home) or (Visitor). -
Page 28: Modification Of The Period
6.1.8 Modification of the period The period is not automatically increased at the end of a game in order to have the possibility to modify the score or any other setting before starting the next period. To go to the next period or to modify its value: ... -
Page 29: End Of Period
CONSOLE SATURN WP 6.1.10 End of period When the period finished, the following display appears: Move switch in off position ! Turn the switch on to Stop. If necessary, adjust score or other events that could have occurred. Press the key to go to the next period. -
Page 30: End Of Game
6.1.12 End of game When the last period is finished, press on the key ; a screen will ask you if you wish an extra period: Extra period ? Answers to end the play. The console will show GAME OVER and it will not be possible to start the game time again. -
Page 31: Scoreboard Applications
CONSOLE SATURN WP SCOREBOARD APPLICATIONS 7.1 CALYPSO HORIZONTAL 7.2 CALYPSO VERTICAL Version 2.6 3403.504.02 Page 25... -
Page 32: Piccolo
7.3 PICCOLO PROPERTIES 8.1 Dimensions and weight Dimension of the console WP : Hx90/Wx285/Dx205 Case weight: 1.2 kg 8.2 Maintenance 8.3 Storage The console Saturn must be kept in a clean and dry place. The storage temperature is -10°C to +60°C whereas the working temperature is 0°C to +45°C. Page 26 3403.504.02 Version 2.6... -
Page 33: Default Values
CONSOLE SATURN WP DEFAULT VALUES Console Set – Ext. Start/Stop Autorised values Default values Ext. Timeout Ext. Poss. Ext. S/S Select / Settings Autorised values Default values Number period 1 - 9 4 + 2EP Setting period & pause 1 – 9/0 - 59 Setting period EP1/3 0 –... -
Page 34: Electrical Properties
10 ELECTRICAL PROPERTIES ATTENTION : When the console is equipped with the internal BlueTooth option, TX (pin 1 and 2 of Scoreboard connector) IS NOT AVAILABLE. It is so recommended to always connect the scoreboards on pin 3 and 4 of the Scoreboard connector. -
Page 35: Appendix
CONSOLE SATURN WP 11 APPENDIX 11.1 Version history Version Modifications since last version Initial version Second version (Waterpolo version) Connector pinning table corrected Pictures console WP updated Reset 30s/20s Shotclock Examples of scoreboard applications External Time out set by trainer chapter added External Time out configuration added in chapter 3.2.7 &... - Page 36 NOTES Page 30 3403.504.02 Version 2.6...
- Page 37 SWISS TIMING LTD P.O. Box 138, rue de l'Envers 1 Phone +41 32 488 36 11 2606 Corgémont, Switzerland www.swisstiming.com info@swisstiming.com SWISS TIMING LTD...
