Task Force Tips MASTER FOAM Instructions For Safe Operation And Maintenance page 10

60
3% FOAM AT 250 GPM AND 100 PSI
50
40
30
20
10
0
0 20
60
3% FOAM AT 350 GPM AND 100 PSI
50
40
30
20
10
0
0 20
60
3% FOAM AT 500 GPM AND 100 PSI
50
40
30
20
10
0
0 20
60
3% FOAM AT 750 GPM AND 100 PSI
50
40
30
20
10
0
0 20
• Approximate Effective Stream Trajectory At 30 Degree Elevation In No Wind Conditions. Distance To Last Foam Drop
Approximately 10% Farther.
• Trajectories Shown Are For 3% Foam. Effective Reach With Water Is Approximately 10% Further
• Tail Or Head Winds Of 20 Mph May Increase Or Decrease The Range Approximately 30%.
©Copyright Task Force Tips, Inc. 2003 - 2011
40 60 80
HORIZONTAL DISTANCE (FEET)
40 60 80
HORIZONTAL DISTANCE (FEET)
40 60 80
HORIZONTAL DISTANCE (FEET)
40 60 80
HORIZONTAL DISTANCE (FEET)
Fig 2.5.4 Approximate Master Foam Stream Trajectory
A= TFT MASTER FOAM
B= TFT MASTER FOAM WITH FOAMJET LX
B A
100 120 140
A= TFT MASTER FOAM
B= TFT MASTER FOAM WITH FOAMJET LX
B
100 120 140
A= TFT MASTER FOAM
B= TFT MASTER FOAM WITH FOAMJET LX
B
100 120 140
A= TFT MASTER FOAM
B= TFT MASTER FOAM WITH FOAMJET LX
100 120 140
10
160 180 200
A
160 180 200
A
160 180 200
A
B
160 180 200
LIZ-030 September 27, 2011 Rev07
220
220
220
220
