WARNING
To reduce the risk of fire or electric shock, do not expose this product to rain or moisture.
The apparatus shall not be exposed to dripping or splashing and that no objects filled with liquids, such as
vases, shall be placed on the apparatus.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
This symbol indicates "dangerous voltage"
inside the product that presents a risk of
electric shock or personal injury.
Caution: To prevent electric shock, match wide blade of plug to wide slot, fully insert.
Attention: Pour é viter les chocs é lectriques, introduire la lame la plus large de la fiche dans la borne
correspondante de la prise et pousser jusqú au fond.
USE OF CONTROLS OR ADJUSTMENTS OR PERFORMANCE OF PROCEDURES OTHER THAN THOSE
SPECIFIED HEREIN MAY RESULT IN HAZARDOUS RADIATION EXPOSURE. DO NOT STARE INTO
BEAM.
The unit employs a Laser System. To prevent direct exposure to the laser beam, do not try to open the
enclosure. Visible laser radiation when open and interlocks defeated.
Refer to the identification/rating label located on the back panel of your product for its proper operating
voltage.
Caution: Using video games or any external accessory with fixed images for extended periods of time
can cause them to be permanently imprinted on the picture tube (or projection TV picture tubes).
ALSO, some network/program logos, phone numbers, etc. may cause similar damage. This damage
is not covered by your warranty.
Cable TV Installer
This reminder is provided to call your attention to Article 820-40 of the National Electrical Code (Section 54
of the Canadian Electrical Code, Part 1) which provides guidelines for proper grounding and, in particular,
specifies that the cable ground shall be connected to the grounding system of the building as close to the
point of cable entry as practical.
Customer Record
You will find the model number and chassis number of your unit on the back of your unit. Record these
numbers in the spaces provided below. Refer to them whenever you call APEX Digital customer service or
your APEX dealer regarding this product.
Model Number:

PACKING LIST

Parts
TV/DVD Combo

Remote Control

Operation Manual

AAA Alkaline Batteries
Caution: To reduce the risk of electric shock, do not
remove cover (or back). No user serviceable parts
inside. Refer servicing to qualified service personnel.
This
symbol
instructions accompanying the product.
Chassis Number:
QTY
1
1
1
2
1
indicates
important

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GT1417DV and is the answer not in the manual?

Questions and answers

Summary of Contents for Apex Digital GT1417DV

  • Page 1: Operation Manual

    You will find the model number and chassis number of your unit on the back of your unit. Record these numbers in the spaces provided below. Refer to them whenever you call APEX Digital customer service or your APEX dealer regarding this product.
  • Page 2: Important Stand And Base Safety Information

    IMPORTANT SAFETY INSTRUCTIONS 1. Read these instructions. 2. Keep these instructions. 3. Heed all warnings. 4. Follow all instructions. 5. Do not use this apparatus near water. 6. Clean only with dry cloth. 7. Do not block any ventilation openings. Install in accordance with the manufacturer's instructions. 8.
  • Page 3: Notes On Discs

    • DO NOT ATTACH PAPER OR TAPE TO DISCS. • DO NOT TOUCH THE PLAYBACK SIDE OF THE DISC. Note: APEX DIGITAL INC. SHALL NOT BE RESPONSIBLE FOR DAMAGE THAT MAY OCCUR TO A DISC FROM BEING OPERATED IN THE UNIT. Cleaning discs •...
  • Page 4: Table Of Contents

    TABLE OF CONTENTS INTRODUCTION Safety Precautions ...1 Feature Descriptions ...5 Specifications ...5 Front and Rear Unit Profiles ...6 Remote Control Features ...7 INSTALLATION Connecting the Antenna ...9 Installing the Remote Control Batteries ...9 Connecting A/V Equipment ...10 FUNCTIONS & FEATURES Turn On/Off...12 Basic Functions ...12 Function Selection Menus...
  • Page 5: Feature Descriptions

    SPECIFICATIONS MODEL Mid Band (A-8~A-1, A~I); Hyper Band (AA~ZZ, AAA, BBB) Ultra Band (65~94, 100~125) 14.80 x 15.08 x 16.77 in. GT1417DV NTSC-M VHF 2-13, UHF 14~69 Super Band (J~W) 75 ohm (unbalanced) 11.22 x 8.43 in. 285 x 214 mm 1W + 1W <7%...
  • Page 6: Front And Rear Unit Profiles

    Instruction ManualManual Front and Rear Unit Profiles Front panel INFRARED SENSOR DVD TRAY DVD TRAY POWER INDICATOR STOP OPEN/CLOSE CHANNEL DOWN/UP MENU SELECT TV/DVD SELECT PLAY/PAUSE VOLUME DOWN/UP TV/VIDEO SELECT Rear panel ANTENNA IN...
  • Page 7: Remote Control Features

    Remote Control Features Programming the Remote Control 1. Set the TV/DVD/VCR switch to the device you want to control. 2. To program the remote control 1) Press and hold the SET key for over 3 seconds until the LED indicator on the remote control lights up. The remote control is now in the PROGRAMMING mode.
  • Page 8: Remote Control Features

    Remote Control Features The keys marked with * have composite functions and the key in boldface type function for DVD only as shown below. Button VIDEO (SETUP) PICTURE D_MENU /ENTER CH+/CH- DISPLAY F+VOL-/F+VOL+ F+MUTE MTS/SAP (SUB_T) CC (AUDIO) SLOW TV/DVD/VCR switch MENU SOUND VOL+/VOL-...
  • Page 9: Installation

    INSTALLATION - Please read the safety instructions in this manual completely before installation. - Install your TVan area where direct sunlight will not fall upon the screen. - Soft, indirect light is best for television viewing. - Allow enough space (at least 4 in.) between the TV and any walls or enclosures for proper ventilation. - Optimum television viewing distance is 3-5 times the screen's size.
  • Page 10: Connecting A/V Equipment

    INSTALLATION (continued) Connecting A/V Equipment The following are diagrams showing basic instructions for attaching external equipment, like a VCR or DVD player, to your unit. Please refer to operation manuals of external audio/video equipment that will be connected to your set for additional instructions. PLEASE TURN OFF ALL POWER BEFORE CONNECTING DEVICES TOGETHER.
  • Page 11 DTS programming can deliver surround sound with five discrete full range channels plus a sixth channel for a subwoofer. You can enjoy your APEX unit with a DTS Digital Surround Sound System. All you need is to connect your unit to a DTS receiver with an external decoder.
  • Page 12: Functions And Features

    FUNCTIONS & FEATURES Turn On/Off 1. Turn On Plug in the power cord, and the TV should enter into Standby mode. Pressing STANDBY key will turn on the TV and its power indicator light. 2. Standby (Soft Off) While the TV is on, press the STANDBY key will put the TV in Standby or off mode. The power indicator light on the TV set will turn off.
  • Page 13: Tuner Menu

    FUNCTIONS & FEATURES Tuner Menu Note: This menu is only accessible while the TV is in Tuner mode. Channel: This feature allows you to change the channel displaying on screen. Press </> or the numeric keypad to change the channel. Add/Erase: This feature allows you to add or remove the channel currently display on screen to the "active channel list"...
  • Page 14 FUNCTIONS & FEATURES (continued) System Menu (continued) Parental Guide This feature allows parents to block certain programs from being viewed, based on the programs' rating. In order to access this menu, you must first enter a pass code. The factory default is 6688. Enter the pass code while the Parental Guide is highlighted.
  • Page 15: Useful Remote Control Features

    FUNCTIONS & FEATURES (continued) Useful Remote Control Features DISPLAY This key allows you to display the current information of the TV screen on the upper right hand corner of the screen. (channel, antenna mode, time, video, etc.) SCAN Press the SCAN key twice, and the TV will begin to scan through all active channels. To stop the Scan, pressing any key can interrupt scanning.
  • Page 16: Dvd Funtions

    Set the AUDIO OUTPUT to ANALOG from the SETUP MENU display if you don't have the necessary equipment to enjoy Dolby Digital or DTS surround sound. (1) A disc may be damaged if not correctly placed on the guides in the disc tray. This may also cause the DVD player to malfunction.
  • Page 17: Using The On-Screen Display

    DVD FUNCTIONS(continued) Playing Back a Disc (continued) 8. Resuming playback from the same location This DVD player allows you to stop playback and continue playback later from the same location on the disc. 1) Press the STOP key. This will interrupt the playback and the DVD player will memorizes the location where you stopped playback. 2) Press the PLAY or RESUME key.
  • Page 18: Locating A Specific Title, Chapter Or Track

    DVD FUNCTIONS(continued) Locating a Specific Title, Chapter or Track THE DVD VIDEO DISCS ARE NORMALLY DIVIDED INTO TITLES. THE TITLES ARE SUB-DIVIDED INTO CHAPTERS. MOREOVER, AUDIO CD and MP3 CD ARE DIVIDED INTO TRACKS. YOU CAN CONVENIENTLY LOCATE ANY SPECIFIC TITLE, CHAPTER, OR TRACK WITH THIS UNIT. Chapter1 Chapter2 Chapter3 TITLE 1...
  • Page 19: Selecting Subtitles

    DVD FUNCTIONS(continued) Selecting Subtitles THIS UNIT ALLOWS YOU TO DISPLAY THE SUBTITLES FROM THOSE INCLUDED ON THE DISC, ON TO YOUR TV SCREEN. How to display subtitles You have the option to select a preferred subtitle from those included on the DVD video disc.
  • Page 20: Wma/Mp3 Operation

    DVD FUNCTIONS(continued) WMA/MP3 Operation 1. Insert a WMA/MP3 CD, the DVD player will initialize the disc when the tray is closed and the directory (folder) will be shown in the MENU on screen. 2. Press to select and highlight the PLAY MODE.
  • Page 21: Playing Your Jpeg Files

    DVD FUNCTIONS(continued) Playing Your JPEG Files 1. Normal Slide Show Presentation When a JPEG disc is loaded into the player, a menu will appear on screen. From the Play Mode shown on the menu, select the "FOLDER" option using your direction keys. Each picture in the current directory will be displayed consecutively in a slideshow presentation and will be seated to the most of your TV screen.
  • Page 22: Customizing The Function Settings

    Customizing the Function Settings THIS UNIT ALLOWS YOU TO CUSTOMIZE THE PERFORMANCE TO YOUR PERSONAL PREFERENCES. GENERAL SETUP Displaying the setup menu screen The SETUP MENU screen asks you to select a setting category from General Setup, Speaker Setup, Audio Setup, and Preferences. The selected category will provide you the setting details on-screen. SETUP MENU - - MAIN PAGE GENERAL SETUP SPEAKER SETUP...
  • Page 23: Troubleshooting Guide

    TROUBLESHOOTING GUIDE Check the following guide for a possible correction to a problem before contacting customer service. Check FAQ at our website: www.apexdigitalinc.com Symptoms No power No picture No sound No TV signal Stripe or purple interference appears in the screen Picture becomes snowy.
  • Page 24: Tv/Dvd Combo Warranty Information

    Apex Digital, Inc. warrants this product and its parts against defects in material or workmanship for a period of ninety (90) days after the date of original retail purchase. During this period Apex Digital, Inc. will repair or replace a defective part or product at their option, with a new or refurbished part or product, without charge to you.You must deliver the entire product...
  • Page 25 APEX Digital, Inc. Ontario, CA 91761 FOR SERVICE CALL: 866-4-APEX-INC http://www.apexdigitalinc.com...
