Page 1: Instruction Manual
Stereo - AT2002S, AT2402, AT2702S AT S TEREO OLOR ELEVISIONS INSTRUCTION MANUAL Stereo Series - AT2002S, AT2402S, AT2702S Please read this manual carefully before operation. - Page 2 APEX Digital,Inc. 2919 E. Philadelphia Avenue Ontario, California 91761 909-930-1239 FOR SERVICE CALL: 800-4-APEX-INC...
-
Page 3: Table Of Contents
Instruction Manual INTRODUCTION Safety Precautions ...2 Specifications ...5 Feature Content ...6 Front and Rear Unit Profiles AT2002S ...8 AT2402S ...9 AT2702S ...10 Remote Control Features ...11 INSTALLATION Connecting the Antenna ...12 Installing the Remote Control Batteries ...12 Connecting A/V Equipment From Device to TV...13... -
Page 4: Before You Begin
This damage is not protected by your warranty as it is the result of misuse. Should you wish to use your Apex Television to display still images, it is always advisable to reduce brightness and contrast settings. -
Page 5: Important Safety Instructions
Instruction Manual BEFORE YOU BEGIN... (continued) Important Safety Instructions CAUTION PLEASE READ THESE INSTRUCTIONS, KEEP THESE INSTRUCTIONS AND HEED ALL WARNINGS. FOLLOW ALL INSTRUCTIONS. Electrical energy can perform many useful functions. This TV set has been engineered and manufactured to assure your personal safety. However improper use can result in potential electrical shock or fire hazards. -
Page 6: Antenna Setup
Damage Requiring Service - Refer ALL servicing to qualified service personnel. Please disconnect your TV set from the wall and contact your local APEX service agent immediately if any of the following conditions are met: a. lf the power cord or plug is damaged or frayed. -
Page 7: Fcc Warning
Instruction Manual BEFORE YOU BEGIN... (continued) FCC Warning Class B Computing Device Information to User This equipment has been tested and found to comply with the limits for a Class B Digital Device pursuant to part 15 of FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. -
Page 8: Feature Descriptions
AV Input (Side) AV Output (Rear) AV Stereo Sound Channel Recall Closed Caption Full Feature Remote On/Off Timer Parental Control RF Antenna Input S-Video Input Screen Size Picture Modes Trilingual OSD AT2002S AT2402S 20” 24” Stereo - AT2002S, AT2402, AT2702S AT2702S 27”... -
Page 9: Front And Rear Unit Profiles
Instruction Manual Front and Rear Unit Profiles AT2002S Front panel MENU SELECT TV/VIDEO SELECT Rear panel MAIN POWER SWITCH INFRARED SENSOR POWER LED VOLUME CHANNEL DOWN/UP DOWN/UP RF ANTENNA IN See the right figure. AV IN on the side panel... -
Page 10: At2402S
SELECT Rear panel See the figure at right. MAIN POWER SWITCH INFRARED SENSOR POWER LED MENU SELECT CHANNEL VOLUME DOWN/UP DOWN/UP AV OUT AV1 IN AV2 IN AV3 IN RF ANTENNA IN Stereo - AT2002S, AT2402, AT2702S S-VIDEO LEFT RIGHT... -
Page 11: At2702S
Instruction Manual Front and Rear Unit Profiles (continued) AT2702S Front panel VIDEO Front - set AV IN Rear panel See the right figure. ANTENNA IN INFRARED SENSOR MAIN POWER POWER INDICATOR SWITCH See the following figure. VIDEO - VOL + MENU R-AUDIO-L VOLUME DOWN/UP... -
Page 12: Remote Control Features
(p. XX) Sound Selects various Sound modes (p. XX) Mute Mutes or restores the TV volume (p. 11) Video Cycles through the Video/Air modes (p. XX) Stereo - AT2002S, AT2402, AT2702S FUNCTION 100+ TIMER ARROWS SCAN PICTURE RECALL STANDBY KEYPAD... -
Page 13: Installation
Instruction Manual INSTALLATION - Please read the safety instructions in this manual completely before installation. - Install your TV in an area where direct sunlight will not fall upon the screen. - Soft, indirect light is best for television viewing. - Allow enough space (at least 4 in.) between the TV and any wals or enclosures for proper ventilation. -
Page 14: From Device To Tv
With S - VIDEO Terminal VIDEO Yellow AUDIO White VIDEO Yellow AUDIO White Stereo - AT2002S, AT2402, AT2702S ANTENNA IN ANTENNA IN Yellow White Actual back of TV may vary. Please see pgs. 9-12 for your TV’s back panel illustration. Yellow White... -
Page 15: Functions And Features
Instruction Manual FUNCTIONS & FEATURES Power On/Off 1. Power On Plug in the supply cord, and press the MAIN POWER SWITCH on the front of the TV to turn the power on. A channel number will appear on the upper right corner of screen. -
Page 16: Picture Menu
If a signal is detected, that channel will be added. If there is no signal detected then the channel will not be added. Use the right arrow key to start the process; use the left arrow key to stop the process. (continued) Stereo - AT2002S, AT2402, AT2702S Picture Tint Brightness... -
Page 17: Timer Menu
Instruction Manual FUNCTIONS & FEATURES (continued) Timer Menu From the Main Menu screen, press the “Menu” key on the remote control until “Timer” on the main screen is highlighted in red. Press the left or right arrow key to enter this menu. Time This feature allows you to set the clock on the TV. -
Page 18: System Menu
Closed Captions will be displayed at either the top or bottom of the screen. With the Text mode selected, our APEX television will decode and display any teletext signal that is being transmitted with the TV program. This information is usually not related to the program itself. -
Page 19: Parental Guide
Instruction Manual FUNCTIONS & FEATURES (continued) System Menu (continued) Parental Guide This feature allows parents to block certain programs from being viewed, based on the programs’ rating. In order to access this menu, you must first enter a pass code. The factory default is 6688. With “Parental Guide” highlighted in red, use the numeric keypad to enter the pass code. -
Page 20: Other Useful Features
Check Add/Erase feature, as channel may have been erased during set up. Closed Caption to Text feature may be active. Batteries may be weak. Replace batteries. Make sure remote sensor is not blocked including deflection from curved glass cabinet. Stereo - AT2002S, AT2402, AT2702S... -
Page 21: Limited United States Warranty
Depending on the type of repair required, the service will either be performed in your home or the set will be taken to the Authorized Apex Digital, Inc. Service Center' s repair facility for repair and then returned to your home at no cost to you.
