6
12
1
Screen Protector
2
Waterproof Seal
Charging Port Cover (Water resistant seal when charging)
3
Ambient Light Sensor Opening
4
VESA 100 Port
5
Volume Button
6
Power Button
7
Installation Guide
7
8
10
13
3
9
4
5
11
Camera Opening
8
Audio Port Plug
9
10
MagConnect Port (1/4"-20)
Optional Shoulder Strap Support
11
Rotating Hand Strap
12
13
Rotating Kick Stand
1
2
Advertisement
Related Manuals for aXtion Pro MP
Summary of Contents for aXtion Pro MP
- Page 1 Installation Guide Camera Opening Screen Protector Waterproof Seal Audio Port Plug Charging Port Cover (Water resistant seal when charging) MagConnect Port (1/4"-20) Ambient Light Sensor Opening Optional Shoulder Strap Support VESA 100 Port Rotating Hand Strap Volume Button Rotating Kick Stand Power Button...
- Page 2 Open charging cover with a coin Lift the back of the case from the camera end Place water test paper inside, face down to the front of the case. Check that the O-ring is seated well into the Audio port channel and waterproof audio port plug is tight.
- Page 3 Test under 12" of water for 10 minutes Dry the outer case prior to opening and ensure the water test paper is dry. 12 in 12 in 10 min 30 cm 30cm 2 lb. Inspect the water test paper using the instructions printed onto it.
- Page 4 The Joy Factory expressly disclaims all liability and all warranties, whether expressed or This aXtion Pro case is designed only for the device type listed on the box. Thus it is only implied, for use of an aXtion Pro case that has been damaged for any reason. The case is intended for and only warrantied for proper use with that specific tablet and not for use with...
