OWNERS MANUAL
www.herkules.us
Website:
info@herkules.us
E-mail:
This manual contains important information concerning the
installation and operation of the gun washers listed above.
Read manual thoroughly and keep for future reference
Herkules Equipment Corporation
2760 Ridgeway Court
Walled Lake, MI 48390-1662 USA
Page 1 of 12
Part# 1004422-02
Made in USA
800-444-4351
Toll Free:
248-960-7100
Phone:
248 960-7109
Fax:
9/1/2020
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Hercules R500
Summary of Contents for Hercules R500
- Page 1 Part# 1004422-02 9/1/2020 Made in USA This manual contains important information concerning the OWNERS MANUAL installation and operation of the gun washers listed above. Read manual thoroughly and keep for future reference Herkules Equipment Corporation 800-444-4351 www.herkules.us Toll Free: Website: 2760 Ridgeway Court 248-960-7100 Phone:...
-
Page 2: Table Of Contents
Table of Contents Warranty ………………………………………………………………………………………………………………....3 Model Information ……………………………………………………………………………………………………………. 4 Warnings ……………………………………………………………………………………………………………………… 5 - 6 Installation ………………………………………………………………………………………………………………….. 7 Operation ……………………………………………………………………………………………………………………. 8 Preventative Maintenance ………………………………………………………………………………………………………. 9 Troubleshooting ……………………………………………………………………………………………………………… 9 Drawings with Part Lists …………………………………………………………………………………………………… 10-12 Herkules Equipment Corporation A U.S.-based manufacturer, Herkules Equipment Corporation offers a diverse line of products that support multiple industries by improving efficiency, productivity, ergonomics, comfort, and safety in the work environment. -
Page 3: Warranty
Warranty IMPORTANT NOTICE: if you have a problem with your Herkules product, DO NOT RETURN TO PLACE OF PURCHASE Contact Herkules: by phone 1-800-444-4351; by email, info@herkules.us; or on the web at herkules.us/contact-us. At Herkules we take great pride in the construction of our American-made products, and we stand behind their reliability. Our limited liability warranty coverage for Paint Gun Washers warranties the unit for a period of 12 months. -
Page 4: Model Information
Model Information NOTE: Dimensions listed are overall measurements. Model Description Weight Dimensions in./(mm) lbs/(kg) 39.7 16.2 20.5 20.4 R500 (1009) (411) (521) (516) Waterborne Recycler Manual (20) Warning Symbol Caution Symbol CAUTION WARNING This symbol alerts you to the possibility of serious This symbol alerts you to the possibility of damage to injury or death if you do not follow the instructions. -
Page 5: Warnings
WARNING EQUIPMENT MISUSE HAZARD Equipment misuse can cause the equipment to rupture, malfunction, or start unexpectedly and result in serious injury. • This equipment is for professional use only. • Read all instruction manuals, tags, and labels before operating the equipment. •... - Page 6 WARNING FIRE AND EXPLOSION HAZARD Improper grounding, poor air ventilation, open flames, or sparks can cause a hazardous condition and result in fire or explosion and serious injury. • Ground the equipment. See Installation for grounding procedure. • Provide fresh air ventilation to avoid the build up of fumes. •...
-
Page 7: Installation
Installation Installing the Recycler Place recycler on a level surface in a properly ventilated paint mixing room or paint booth. Grounding the Recycler Connect the ground wire on the Recycler’s lid to a true earth ground. Ground all equipment used or located in the Recycler area. -
Page 8: Operation
Operation Filtering dirty water Pour the dirty paint mixture to be recycled into the tank. Do not exceed the 5 gallon capacity of the tank. Add flocculant / coagulant to the dirty paint mixture. (Herkules CoAgent P/N CA01 recommended. NOTE: Herkules CoAgent recycling coagulant along with inner and outer filter bags can be purchased online at www.herkules.us If using Herkules CoAgent P/N CA01, add 1 tablespoon per 5 gallons of dirty paint mixture. -
Page 9: Preventative Maintenance
Preventative Maintenance To keep your machine working efficiently and effectively, please follow these directions. Drain water from regulator weekly if you do not have quality dry air. Filter / Regulator (#11345) Replace Filter/Regulator yearly. (#11345) Change cleaning solution / water mixture when objects being cleaned become tacky to the touch. -
Page 10: Drawings With Part Lists
R500 Parts Layout Page 10 of 12... - Page 11 Sticker Front Recycler GWR 1004425 Sticker Agitator/Off Toggle 1004423 Sticker Top Lid Recycler GWR 1004400 Decal Herkules R500 Brand Tube 5/32 Nylon Blue 1002644 Bulkhead 1 - Brass Washer 1-1/2 x 1 Nylon Reducer 1/2 NPT X 3/8 NPT Ball Valve...
- Page 12 R500 Stand Assembly Part # Description Quantity 1002546 Screw BHSC 10-24 x 1/2 2 EA Adaptor 1/4 NPT Brass 1 EA 11345 Filter / Regulator 1 EA Fitting PTC 90 Degree Swivel 5/32 T x 1/4 NPT 1 EA Flat Washer 1/2 SAE Zinc...
