- Page 1 3-12 AS20015, Rev. 3 COMMUTER SPRAYER Page 1...
-
Page 2: Table Of Contents
Thank you for purchasing a Demco sprayer. We feel you have made a wise choice and hope you are completely satisfied with your new piece of equipment. If you have any questions regarding applications of certain solutions or chemicals, contact your chemical supplier and follow chemical manufacturer recommendations as well as all licensing and use restrictions or regulations. -
Page 3: Safety, Signal Words
If you have questions not answered in this manual , require additional copies, or if your manual is damaged, please contact your dealer or Demco, P.O. Box 189, 4010 320th Street, Boyden, IA 51234 ph: (712) 725-2311 or (712) 725-2302 Toll Free: 1-800-543-3626 Fax: (712) 725-2380 http://www.demco-products.com... -
Page 4: Equipment Safety Guidelines
SAFETy...yOu CAN LIvE WITH IT EquIPMENT SAFETy GuIDELINES Every year many accidents occur which could have been avoided by a few seconds of thought and a more careful approach to handling equipment. You, the operator, can avoid many accidents by observing the following precautions in this section. To avoid personal injury, study the following precautions and insist those working with you, or you yourself, follow them. -
Page 5: Safety Sign Locations
SAFETy SIGN LOCATIONS Types of safety sign and locations on equipment are shown in the illustration below. Good safety requires that you familiarize yourself with various safety signs, type of warning, and area or particular function related to that area, that requires your SAFETY AWARENESS. This decal is located near the sprayer lid. -
Page 6: Safety Sign Care
SAFETy SIGN CARE • Keep safety signs clean and legible at all times. • Replace safety signs that are missing or have become illegible. • Replacement parts that displayed a safety sign should also display current sign. • Safety signs are available from your distributor, dealer parts department, or factory. How to install safety signs: •... -
Page 7: During Operation
• Move wheels on the utility vehicle to the widest recommended settings to increase stability. • Do not allow anyone to stand between tongue or hitch and utility vehicle when backing up to sprayer. DuRING OPERATION • Beware of bystanders, PARTICuLARLy CHILDREN! Always look around to make sure that it is safe to start engine of utility vehicle or move sprayer. -
Page 8: Following Operation
FOLLOWING OPERATION • Following operation, or when unhitching, stop utility vehicle, set brakes, disengage PTO and all power drives, shut off engine and remove ignition key. • Store unit in an area away from human activity. • Do not park equipment where it will be exposed to livestock for long periods of time. Damage and livestock injury could result. -
Page 9: Performing Maintenance
REMEMbER Your best assurance against accidents is a careful and responsible operator. If there is any portion of this manual or function you do not understand, contact your local authorized dealer or manufacturer. PERFORMING MAINTENANCE • Good maintenance is your responsibility. Poor maintenance is an invitation to trouble. •... -
Page 10: Bolt Torque
bOLT TORquE TORquE DATA FOR STANDARD NuTS, bOLTS, AND CAPSCREWS. Tighten all bolts to torques specified in chart unless otherwise noted. Check tightness of bolts periodically, using bolt chart as guide. Replace hardware with same grade bolt. NOTE: Unless otherwise specified, high-strength Grade 5 hex bolts are used throughout as- sembly of equipment. -
Page 11: Sm110 & Sm150 Parts Breakdown And Parts List
SM110 & SM150 PARTS bREAKDOWN NOTE: Hose Reel and mounting parts are optional. TANKS P110 24 110 Gallon Tank, 24” Dia. P110 24A 110 Gallon Tank, 24” Dia., w/ Agitation P150 30 150 Gallon Tank, 30” Dia. P150 30A 150 Gallon Tank, 30” Dia., w/ Agitation SM110 &... -
Page 12: Roller Pump Plumbing Parts Breakdown And Parts List
ROLLER PuMP PLuMbING PARTS bREAKDOWN 3 Section Control valve (AA171) *49 *50 To boom To Hose Reel (Optional) Page 12... - Page 13 ROLLER PuMP PLuMbING PARTS LIST 09275-10 Control Valve Mount REF. PART qTy. DESCRIPTION 00214 1/4” Flatwasher EL114 34 1-1/4” MPT x 3/4” Elbow 02772 1/4”-20 UNC Nylon Insert Locknut b12H 10 1” SS Gear Clamp 23340PP Pressure Relief Valve 340Rb 3/4”...
-
Page 14: Electric Pump Plumbing Parts Breakdown And Parts List
ELECTRIC PuMP PLuMbING PARTS bREAKDOWN 3 GPM Pump Option ELECTRIC PuMP PLuMbING PARTS LIST REF. PART QTY. DESCRIPTION P110 24 REF. PART 110 gal. Poly Tank, 24” Diameter QTY. DESCRIPTION P150 30 150 gal. Poly Tank, 30” Diameter A1238 1/2” MPT x 3/8” Hose Barb PL5A Cover for tank A1438... -
Page 15: Boom Mounting Parts Breakdown And Assembly
12’ & 18’ bOOM (Db12 & Db18) PARTS bREAKDOWN Db12 & Db18 PARTS LIST REF. PART QTY. PART QTY. REQD REQD DESCRIPTION Db12 Db18 1 12’ & 18’ Boom Assembly 00004 00004 4 5/16” Flatwasher 00009 00009 2 Cotter Pin (1/8” x 1”) 00059 00059 8 3/8”... -
Page 16: Roller Pump Parts Breakdown And Parts List
TRuSS-T bOOM PARTS bREAKDOWN TRuSS T bOOM PARTS LIST REF. PART qTy. DESCRIPTION 04347-70 Boom Mounting Brackets 02529 3/8”-16 UNC x 1-3/8” Round U-bolt 02678-95 Boom Mounting Plate 00059 3/8” Flatwasher 02592 3/8”-16 UNC Nylon Insert Locknut 00909 5/16”-18 UNC x 1-3/8” Sq. U-bolt 00004 5/16”... -
Page 17: Direct-O-Valve Parts Breakdown And Parts List
(6b1) DIRECT-O-vALvE PARTS bREAKDOWN (6b1) DIRECT-O- vALvE PARTS LIST REF. PART DESCRIPTION 36301Ny Handle (Nylon) 36308SS Groove Pin (Stainless Steel) 36302PP Body Insert (Polypropylene) 7717 2 108vI O-ring (Viton) 36307SS Washer (Type 316, Stainless Steel) 7717 2 209vI O-ring (Viton) 36306SS Spring (Type 316, Stainless Steel) 36305... -
Page 18: Notes
NOTES Page 18... - Page 19 NOTES Page 19...
-
Page 20: Sprayer Checklist
Water rinse and dry tips before storing. Be sure all bolts are tightened. REPLACEMENT PARTS NOTE: DEMCO does not and will not make any recommenda- Replace all worn or damaged parts. tions concerning application of various chemicals or solutions. These recommendations relate to either amount or procedure of materials applied.
