E U R O D E S K S Y S T E M
Either the large or medium desk can be enhanced with optional accessories
such as drawers, keyboard tray, and 3-drawer storage trolley.
Levenger Euro Desks are made with solid wood legs and thick, high-quality
cherry veneer tops.
E U R O D E S K A S S E M B LY
1
Parts list
Unpack and lay the parts on a clean, flat surface. Check that you have all the
parts shown in the diagram below. You will need an additional flat-head
screwdriver.
1
1 pc
3
1 pc
A
8 pcs
The Levenger Euro Desk
system is designed to
provide both computer
and traditional desk
space. Euro Desks are
sized for use at home or
in the office. They can
wrap around you to the
left, right, or on all sides,
conforming to the size
and space in your room.
1 pc
1 pc
3
1 pc
1 pc
8 pcs
A
8 pcs
B
2 pcs
2 pcs
C
2 pcs
C
2 pcs
D
2 pcs
2
1 pc
D
2 pcs
E
15 pcs
15 pcs
F
4 pcs
1 pc
G
F
4 pcs
H
4
1 pc
G
3
1 pc
2
Building the frame
Locate the left leg assembly (3). Insert two wood dowels (A) into the upper
and lower holes in the side of the leg. Insert a cam lock screw (B) into the
middle hole. Be sure that the slot in the screw is parallel to the floor when
fully tightened.
Locate the back apron (2). Insert a cam lock nut (C) into the hole on the
inside of the apron. Be sure that the openings in the
sides of the nut are parallel with the floor. Carefully slip
the leg assembly into the holes on the side of the apron,
so that the cam lock screw slides into the cam lock nut.
Insert a cam lock set screw (D) into the nut and tighten.
Repeat for the right side leg (4).
1 pc
1 pc
Slot parallel to the floor
3
1 pc
4
4
1 pc
4
1 pc
A
8 pcs
2 pcs
C
2 pcs
3
Attaching the top
D
2 pcs
Locate the desk top (1). Insert 4
15 pcs
wood dowels (A) into the holes
at the corners. Set the leg
F
4 pcs
assembly on top of the dowels.
G
Insert the 15 long bolts (E) into
the holes on the underside of
the assembly, and fully tighten.
C
Insert leg levelers (F) into each
1 pc
leg. Adjust each until the desk
sits at a level position.
4
1 pc
2
1 pc
4
1 pc
G
E E
E
E
F
A
2
4
A
A
1
2
F
C
3
F
F
A
B
C
D
C
G
C
3
A
F
F
F
F
