E U R O D E S K S Y S T E M
Either desk can be enhanced with optional accessories such as a drawers,
keyboard tray, trolleys and bookcases.
Levenger Euro Desks are made with solid cherry legs and thick, high-
quality cherry veneer tops.
1
Parts list
Unpack and lay the parts on a clean, flat surface. You will need an
additional straight screwdriver. Check that you have all the parts shown in
the diagram below.
1
1 pc
3
1 pc
B U I L D I N G Y O U R S Y S T E M
The Levenger Euro Desk system is
designed to provide both computer
and traditional desk space. Euro
Desks are sized for use at home or in
the office. They can wrap around you
to the left, right, or on all sides,
conforming to the size and space in
your room.
2
1 pc
4
1 pc
A
8 pcs
B
2 pcs
C
2 pcs
D
2 pcs
E
15 pcs
F
4 pcs
G
H
