INDEX 一、PRODUCT INTRODUCTION .................... 2 1-1 A ........................2 PPLICATIONS 1-2 P ..............3 OWER CONTROL AND MONITORING DIAGRAM 1-3 P ......................4 RODUCT EATURES 1-4 C ....................5 ONTROL AND INDICATORS 1-5 S ......................6 PECIFICATIONS 1-6 P ......................6 ACKAGE CONTENTS 1-7 I .................... -
Page 3: 一、Product Introduction
Product Introduction Congratulations on your purchase of our Smart Remote Power Manager Series product. Our IP-P2 model is a web-based SNMP power control device integrated with versatile functions including power control, power operation scheduling, remote web administration, power event alerts and so on into one single unit, which helps system administrators or IT personnel to monitor and control their connected equipment and take preventive measures when needed. -
Page 4: Power Control And Monitoring Diagram
1-2 Power Control and Monitoring Diagram - 3 -... -
Page 5: Product Features
1-3 Product Features Professional IP-addressable power distribution unit with built-in web server with 2 power outlets. Control power equipment remotely via the Internet without the presence of service personnel. Amazing power distribution unit equipped with an intelligent current-meter (True RMS) to indicate the total power consumption of a power strip. Manual power on/off button to override the existing power status and gain immediate control from local access. -
Page 6: Control And Indicators
1-4 Control and Indicators Main Power Switch & Breaker Power Switch Indicating Light Protector Reset Indicating Light Power Input Power Indicating Light Power Switch Socket RJ45 Network Connect Port - 5 -... -
Page 7: Specifications
1-5 Specifications Power Socket NEMA-15R Max. Main Output Current 12 Amp Power Input 85~240VAC 47~63Hz Power Frequency 50 - 60 HZ Operating Temp. 0 – 40C Shape Size 153 x 123 x 44 mm (W x D x H) Machine Net Weight 0.75 KG Consumption Efficiency 4.5 W... -
Page 8: Installation And Setup
1-7 Installation and Setup 1-7-1 Hardware Installations 1. Connect the power cord to the power inlet on IP-P2 model first. 2. Plug the power equipment into the output receptacles. 3. Connect the Ethernet cable to the Ethernet port. 4. Turn the push button on the power switch to the ON position. -
Page 9: Setup Procedure
Select “Off” and then confirms by clicking the “OK” button in the Windows Firewall setup. Launch the IP Search Utility program from the supplied cd disc. Click on the “Refresh” button to search for all of the IP-P2 model remote power switch in your local area network.. - 8 -... -
Page 10: 二、Webpage Operation
Click on IP-P2 to configure the internal local IP address, the gateway and the subnet and then click on the Configure button twice. You will see the IP address, the Gateway and the NetMask (Subnet) for the selected power switch connected in the list change. -
Page 11: Network Setup
• After login, you will proceed to see the complete web administration screen as the screen shot shown below. 2-2 Network Setup Click on【System】tab from the menu bar of the web screen and then click on【Network】next for configuring the IP address and network info of this device. - 10 -... - Page 12 Note: Ethernet Card Speed – Auto, 100M, 10M. User define according to requirement. ICMP Echo Responses – If disabled this function, IP-P2 will not respond to ping. - 11 -...
-
Page 13: Time Synchronization
2-3 Time Synchronization The time zone that our IP-P2 model adopts is 24-hour basis so you must set up the timer schedule on this basis to the switch can perform accordingly. When accessing this unit for the first time, you can have three time sync options to choose from. By clicking the【Time Sync】... -
Page 14: Power Monitor
* When you finish the date/time setup for the above step, always remember to press the「Save」button on the web control panel to save all the setting data in the system. 2-4 Power Control Monitor Configuration You can set up each individual power outlet on the switch accordinly with advanced features by clicking on the【Monitor】tab from the Web control panel as illustrated in the following paragraph. -
Page 15: Power Switch Operation
2-4-2 Power Switch Operation Move your mouse over to this section and left click on the mouse button twice to manually open or close any particular outputlet’s power from the web control panel at your networked computer terminal. Move your mouse over to each power outlet button icon and left click on the mouse button twice to manually open or close any particular outputlet’s power from the web control panel at your networked computer terminal. -
Page 16: Power Monitor
3. Advanced Setup This chapter is mainly to explain the advanced operation in the web control panel. You may learn about all the advanced features and functions of Power Monitor, System Setup, Account Management, Time Synchronization and Even Log. 3-1 Power Monitor The first main category from the top menu bar of the web control panel is “Monitor”. -
Page 17: Network Detect
minutes before startup. Shutdown Delay Time：Just like the above the start delay time, this column allows users to have each power device connected shut down at different moments instead of all shutting down at the same time. 3-1-3 Power Operation Scheduling You may program this remote power switch with timer schedule for action of switching the power equipment ON or OFF or reboot in this section. -
Page 18: System Setup
Re-Ping Time：Users can set the power switch to re-detect the connected web equipment here with preset time period in minutes. 3-2 System Setup In this section you may learn to set up web/network, email server and message services. 3-2-1 Network Setup IP network information data entry: Address：Assign the Network IP address for the power switch. -
Page 19: Message Server Setup
3-2-2 Email Server Setup When there is a triggered warning from the setup of this power switch, this device will send out an alert message to the preset email accounts. SMTP Server Address：Enter your SMTP server address here. SMTP Port：Enter your SMTP port number here. The preset value is 25. Sender Mail Address：This section displays where the alert email is sent from. -
Page 20: Snmp Setup
value is 2500. Equipment Name：When the receiver gets the text message sent by the SMS server, this portion will display the source of the SMS alert event. Account：Enter the user id of your SMS server if available. Password：Enter the password of your SMS server if available. Send SMS：Check here if SMS service needs to be activated for operation setup. -
Page 21: Other Setups
3-2-5 Other Setups Other system-related settings will be set up under this page. Language: Support English, Simplified Chinese, and Traditional Chinese. System Timeout: The time to log out system automatically. Time Format: Change time format. MQTT Host: MQTT server IP address. MQTT Port: Port number of MQTT IP. -
Page 22: Delete An User Account
Administrator or system manager of this power switch can also assign the access levels for each user account. For example manager can assign user A to access either all 2 power outlets on the switch or just a particular one outlet is allowed for access. 3-3-2 Delete An Use Account 1. -
Page 23: Time Syncronization
3-4 Time Synchronization Equipment Date：The system date of the remote power switch. Equipment Time：The system time of the remote power switch. Sync with PC：If you choose this item, the equipment time of the remote power switch will be the same as the computer system. Date：... - Page 24 3-5 Event Log In this section, you may check the log of all the power operations and warning events in the recent 7 days. You can find out what power action occurred on what outlet and at what time by access remotely or locally from the web panel. At the same time, if the power switch can not operated normally, it will produce warning case.
- Page 25 Attachment (A): How to reset this remote power switch to the initial default value ? Answer: In case that user forgot the password for the web network access to the power switch, user can always reset the power switch back to manufacturer’s default setting. Locate the “RESET”...
