M-ELEC |
ML-ROX-100-5K-BK
Product information
With high output and low energy costs M-Elec introduces ROX 100W
road way luminar. Featuring a spigot mount adapter for multiple
installations in one and allowing for an easy access for termination and
future maintenance. With adjustable dimmable driver the ROX is perfect
for remote locations and industrial parks.
7
year warranty
TECHNICAL DETAILS
Product dimensions
Total Power Consumed
Input Current
Dimmable
Power Factor
Efficacy
Lumen Output
Colour Temperature
Impact Rating
Temperature Range
IP Rating
CRI
Beam Angle
Average Life
Power Supply
Warranty
Kit Includes
T. 1300 222 445 | www.melec.com.au
L: 606.2mm x W: 235.3mm x H: 90.5mm
100W
1.2A
Yes (Isolated 1-5V/1-10V/10V PWM/3-Timer-Modes Dimmable)
>0. 9
130lm/W
130001lm
5000K
IK10
-20°C~ + 40°C
IP65
>70
TYPE III(80x140°)
50000 hours
Inventronics Dimming built-in driver
7 Years
1 x ROX,1 x Adjustable spigot bracket, 1 x user manual,1x1m flex
For further information about our Warranties please go to: melec.com.au/legal/warranties
Advertisement
Table of Contents
Related Manuals for Melec ROX
Summary of Contents for Melec ROX
- Page 1 50000 hours Power Supply Inventronics Dimming built-in driver Warranty 7 Years Kit Includes 1 x ROX,1 x Adjustable spigot bracket, 1 x user manual,1x1m flex T. 1300 222 445 | www.melec.com.au For further information about our Warranties please go to: melec.com.au/legal/warranties...
- Page 2 Secure the back cover ensuring all gaskets and seals are in place (Fig.7). FIG 1 FIG 2 FIG 3 FIG 4 FIG 5 FIG 6 FIG 7 T. 1300 222 445 | www.melec.com.au For further information about our Warranties please go to: melec.com.au/legal/warranties...
- Page 3 Damage by corrosion will not be honoured as a material defect claim. It is the user’s responsibility to provide suitable protection against corrosive agents such as moisture, condensation and other harmful elements T. 1300 222 445 | www.melec.com.au For further information about our Warranties please go to: melec.com.au/legal/warranties...
