Melec ML-MSL8-W Manual

Solar area lights
Mirage series solar area lights
Product information
The Mirage series is the latest generation of high powered solar
area lights from M-Elec. With up to 100% brighter output and
an impressive 200lm/W efficacy across the range, the Mirage
series features true LiFePO4 battery technology and advanced
PWM solar charging to deliver continuous shining performance
from dusk till dawn. The smart remote allows effortless set up of
motion and dimming operation modes to maximise performance.
Mirage solar area lights also include a fully adjustable 80 x 150
degree beam and slip fit pole mount bracket making installation
fast and final adjustments easy.
Features and benefits
- 200lm/W efficacy
- LiFePO4 battery technology
- Built in solar panel with advanced PWM solar charging
- Programmable operating modes via remote
- Adjustable light module & mounting bracket
-Integrated motion sensor
Technical details
Colour temperature:
5000K
CCT:
Single CCT
CRI:
70+
Efficacy:
200lm/W
Beam angle:
80 x 150 (H x V)
Charge time:
7 hrs
Dimmable:
Yes, via remote
Warranty:
2 Year warranty + 1 PLI*
Life:
50000hrs** (LED), up to 2000 cycles (battery)
LED chip brand:
Lumileds 5050
Body:
Black
ML-MSL8-W
Total power consumed: 8W
Power supply:
17W Solar panel, 5.8AH LiFePO4 battery
Run time (full power):
7 hrs
Lumen output:
1600lm
Dimensions: L 500mm | W 290mm | H 80mm
Net weight:
6.6kg
754mm
500mm
80mm
www.melec.com.au
Due to our policy of continuous product improvement, we reserve the right to discontinue or update product specifications
876mm
660mm
or designs at any time without notice. Please visit www.melec.com.au for the latest information on our products.
Mounting method:
45-64mm slip fit adjustable pole mount
Light module tilt:
± 40°
Temperature range:
0° to 65°C
IP rating:
IP65
LED tests:
LM80
Accessories:
Additional remote (ML-MSLRM)
Material type:
Cast aluminium body, pc lens, stainless fittings
CISPR15 (EMC), UN38.3, Level 12 wind test, EN
Compliance:
60598-2-3:2003 + A1:2011
Kit includes:
Solar light, instructions, remote control,
slip fit adjustable bracket
*LiFePO4 solar battery & remote - 1 year warranty
**Average life is calculated on expected average lifespan
ML-MSL20-W
20W
36W Solar panel, 17.4AH LiFePO4 battery
9 hrs
4000lm
L 660mm | W 420mm | H 94mm
11kg
100mm
2
year warranty
ML-MSL30-W
30W
54W Solar panel, 29AH LiFePO4 battery
10 hrs
6000lm
L 900mm | W 420mm | H 94mm
14.8kg
1154mm
900mm
120mm
DESIGN | FUNCTION | TRUST
