AMX PS2.8 Specifications

NOTICE: This drawing is the UNLESS OTHERWISE SPECIFIED:
property of AMX Corporation.
TOLERANCE ON DECIMAL DIMENSIONS: XX = .010
All information contained herein
XXX = .005
that is not generally known
TOLERANCE ON HOLE DIAMETERS:
shall be confidential except UNDER .250 ú = +/- .005
.250 TO .500 = +.006 -.005
to the extent the information
OVER .500 = +.008 -.005
has been previously established.
FRACTIONAL DIMENSIONS INCLUDING HOLES: +/- 1/64
ANGLES: +/- 1.0°
This drawing may not be copied,
SURFACE FLATNESS .003 TIR PER LINEAR INCH.
reproduced, or used as the basis
ALL DIMENSIONS IN INCHES.
for manufacture or sale without
DO NOT SCALE THIS DRAWING.
written permission.
REV ECN
5268 RELEASE TO PRODUCTION
A
5566 REMOVE NOTE
B
REL APPR REL DATE REV APPR
NOTICE: This drawing is the
DRAWN DAS 7/30/03
property of AMX Corporation.
All information contained herein
DB
ENGR SERV DB 8/4/03
that is not generally known
PL 8/4/03 PL
ENGINEER
shall be confidential except
to the extent the information KZ
PROD ENGR KZ 8/1/03
has been previously established.
KL 8/1/03 KL
MATL SUP
This drawing may not be copied,
AK
AK 8/1/03 SIZE
reproduced, or used as the basis QUALITY
for manufacture or sale without
THIRD ANGLE
written permission.
PROJECTION
95-0423-05-B
REVISIONS
DESCRIPTION DATE APPROVED
8/5/03
11/4/03
TM
PICTORIAL,
PS2.8 POWER SUPPLY
13.5VDC 2.8A
SHOWN USING A 5MM PHOENIX CONNECTOR
SCALE DWG. NO. REV.
95-0423-05
B FULL B
1 OF 1
SHEET
