OPENING THE MOCKMILL

If the Mockmill is not operating
properly, or if heavy soiling is
suspected, it makes sense to
open the Mockmill. Then the
milling chamber can be cleaned
thoroughly. Please follow the
instructions below.
1
1 a
12
FURTHER
QUESTIONS?
info @ mockmill.com
Turn the adjustment dial
past the coarsest setting until
you feel resistance,
then turn it some more.
Now the dial can be removed.
Lift the adjustment dial away
from the Mockmill.
Stand the Mockmill on the three
2
springs and pull the outer casing
down around it.
Remove the casing sleeve
2 a
completely.
Holding the flange as shown in
3 your left hand, turn the inner
body to the right until it stops.
