3 c
o n n e c t I o n s
Identification of connections:
Connecting element
SAT inputs
Terrestrial input
Equipotential bonding (min. 4 mm
Receiver outputs
The outputs are selected by receivers control signals 14/18 V (Vertical/Hori-
zontal) , 0/22 kHz (Low-, High-Band). Selecting the Satellite position by
SDSP 9/12/17xx is done by DiSEqC signals from the SAT-receiver.
Please check the input levels of the SAT-lines: They should be nearly equal.
Connect the PE connection terminal
plied by customer) using a PE wire with at least 4mm².
Not used receiver outputs
can be terminated (reduc-
es the terrestrial signal
ripple).
Example of a house in-
stallation using SDC 912
and SDSP 908:
a n d c o n t r o l s
Symbol
Horizontal High
Vertical High
Horizontal Low
Vertical Low
)
2
- 3 -
to a potential equalisation rail (sup-
CH 999
Receiver
Potential equalisation rail
SDSP 506 ... SDSP 1732
