Grundig GSS.conect SDSP 506 Assembly Instruction page 2

1 I
m p o r t a n t
• Assembly and servicing should be carried out by electricians.
• Check the system for short circuits in the coaxial cables before starting up.
• Only install the system when it is not connected to the mains supply.
• Mount the multiswitch...
- on a non-flammable background (wall),
- in a dust-free, dry environment,
- in such a manner that it is protected from moisture, fumes, splashing water
and dampness,
- somewhere protected from direct sunlight,
- not within the immediate vicinity of heat sources,
• Make sure the input levels of the SAT stages are as equal as possible.
• Beware of short circuits!
• Earth the unit via the equipotential bonding connector (screws
• No liability is accepted for any damage caused by faulty connections or
inappropriate handling.
• Observe the relevant standards, regulations and guidelines on the installation and
operation of antenna systems.
• The standards IEC/EN/DIN EN 61319-1, IEC/EN/DIN EN 60065 and
IEC/EN/DIN EN 60728 must be observed.
Electronic devices should never be disposed of in the household rubbish. In accordance
with directive 2002/96/EC of the European Parliament and the European Council from
January 27, 2003 which addresses old electronic and electrical devices, such devices
must be disposed of at a designated collection facility. At the end of its service life,
please take your device to one of these public collection facilities for proper disposal.
2 t
e c h n I c a l
a
p p l I c at I o n
This multiswitch is used for distribution of 4 SAT-IF-polarisations (SDSP 5xx;
e.g. ASTRA or EUTELSAT), 2 x 4 SAT-IF-polarisations (SDSP 9xx; e.g. ASTRA
and EUTELSAT), 3 x 4 SAT-IF-polarisations (SDSP 13xx) or 4 x 4 SAT-IF-polari-
sations (SDSP 17xx) and terrestrial signals (active).
The SDSP 5xx and SDSP 9xx ranges are equipped with an internal 22 kHz
generator, in order to support QUAD LNBs. The signals of the terrestrial input
will be active routed to the outputs (low insertion loss). Dependent on the typ,
6, 8,12,16,24 or 32 subscribers/receivers can be connected.
p
ow e r
Power supply is be done via the internal power supply unit.
I n f o r m a t I o n
d e s c r I p t I o n
s u p p ly
o n t h e s a f e t y
- 2 -
a n d a s s e m b l y
SDSP 506 ... SDSP 1732
).
