ZIPLINE KIT WITH SEAT INSTRUCTIONS AND SAFETY RULES
Thank you for your purchase of the Slackers® ZIPLINE! This product was engineered to provide safe fun for ages 8+ years when
the instructions and rules are followed. For best and safe results please read and follow all instructions carefully when installing
and riding your Slackers® ZIPLINE. Obey all safety rules at all times.
IMPORTANT: FILL IN YOUR DATE OF PURCHASE
ON YOUR MAIN CABLE STICKER!
KIT CONTAINS:
A. (1) Trolley with sealed ball bearing pulleys. Non-slip hand grips.
Note: Actual trolley shape may vary.
B. (1) Main Cable length varies with model, 5mm galvanized steel
cable, with looped eye on one end.
C. (1) 2,10m Sling Cable 5mm steel cable w/looped eye.
D. (1) Turnbuckle 15cm steel w/ 2 eye bolts & nuts.
E. (3) U-clamps 5mm with thread cover caps.
F. (1) Seat and Rope
G. (1) Turnbuckle backup cable with 3 U-Clamps
H. (1) Entanglement Safety Tape
I. (1) 3-Way Wrench
(1) Instructions
1.
BE SAFE! ALWAYS FOLLOW THESE RULES
THIS PRODUCT IS INTENDED FOR USE BY 8+ years old.
To be setup and installed only by an Adult.
WARNING! Maximum weight 90kg. This zipline is designed for
children to ride a few feet off ground.
Wear suitable shoes and close fitting clothing. No jewelry, scarves
or other loose clothing.
Make sure everything is installed correctly. Inspect and test
the line before each use.
If worn or damaged parts are found, replace them. DO
NOT substitute with other, non-Slackers parts or
failure resulting in injury may result.
Remain seated for the entire ride, wait until you have stopped
COMPLETELY before letting go of the trolley or dismounting seat.
One zipline rider only at a time. Keep people and animals at least
8m away from the zipline course.
Never use the line when it is wet or if there is rain, frost or lightning in the
area.
Do not place fingers or hair inside of trolley or serious injury may result.
Do not reach up to grab cable while riding or as a
spectator to slow down rider or serious injury may result.
WARNING:
FOR DOMESTIC USE ONLY!
OUTDOOR USE ONLY!
A.
F.
C.
I.
DIRECT SUPERVISION OF AN ADULT -
cable attachment.
HAZARD
diseased, damaged, or not healthy and stable.
Improper tree selection may cause product failure
and serious injury or even death.
REQUIRED
using 113 kg at 150 cm from each end at the
Start and FinishPoints.
WARNING:
REQUIREMENT
can wear or loosen during use. Inspect and
tighten all hardware. Replace your cable after one
year of use.
READ CAREFULLY!
B.
E.
D.
5mm.
H
WARNING:
TO BE USED UNDER
WARNING:
UN-HEALTHY TREE
Do not attach or use a tree that is
-
WARNING:
ADULT STRESS TEST
This product should be tested
-
MAINTENANCE
This product has parts that
-
G.
Advertisement
Related Manuals for Slackers ZIPLINE
Summary of Contents for Slackers ZIPLINE
- Page 1 READ CAREFULLY! Thank you for your purchase of the Slackers® ZIPLINE! This product was engineered to provide safe fun for ages 8+ years when the instructions and rules are followed. For best and safe results please read and follow all instructions carefully when installing and riding your Slackers®...
- Page 2 Start Point Launching- CAUTION- The best and safest way to launch your riders, is to have them first get on the zipline seat at the lowest part of your course (where the most dipping/sagging occurs) and then tow them back up to the starting point.
- Page 3 USE CAUTION in the height of your zipline course, your riders should be as low as possible so that if they do lose their grip, they only fall a few feet to the ground. Their feet should not drag on the ground as they ride down the course.
- Page 4 This will help you pull out the slack and attach your U-Clamps. When you wrap your zipline around the finishing point tree, you want to form a “tear drop” shaped wrap around the tree-See illustration below. Do not tighten up tight against the tree! •...
- Page 5 5. TIGHTENING YOUR ZIPLINE AND INSTALLING ENTANGLEMENT SAFETY TAPE Using the turnbuckle to ghten - Inspect your ini al installa on work carefully and thoroughly. The zipline cable can hold weight many mes that of most riders. The loops, u-clamps and a achment trees are the most likely to fail, if not assembled correctly, and therefore should be inspected extra carefully and o en.
-
Page 6: Final Tuning
FINAL TUNING After the Course Speed Test, your zipline cable may “stretch” a little (which is normal) and require some additional tightening by using your turnbuckle. Check the tightness of all nuts and bolts of all clamps, the turnbuckle and the trolley. - Page 7 3. Do not move in front of, behind or in close proximity to a moving rider. 4. The best and safest way to launch your riders, is to have them first get on the zipline seat (or grip the trolley handle) at the lowest part of your course (where the most dipping/sagging occurs) and then tow them back up to the starting point and then carefully release them.
- Page 8 Tighten all hardware and inspect all components for wear. Check grips for loosening. Replace with only Slackers parts. CHECK YOUR INSTALLATION BEFORE EACH USE. rope/cable will FAIL if misused, abused, worn-out or damaged.
- Page 9 At the end of each play season or when the temperature drops below 0°C • Take down your entire zipline (including plastic swing seat) and store indoors, in a cool, dry location. PLEASE KEEP THE ASSEMBLY AND INSTALLATION INSTRUCTIONS FOR FURTHER REFERENCE...
- Page 10 WARRANTY: 1 year from date of purchase for parts and workmanship. The buyer, installer and user of the SLACKERS™ ZIPLINE must: Read, understand and follow the installation instructions and Safety Rules.
