Precision Lighting Solo 11 Series Instruction Manual

instruction manual
Solo 11, 16 & 16 Plus series
Surface Mounted
Constant Current
Solo 11 4.2W 405lm
Solo 16 8.4W 700lm
Solo 16 Plus 12.6W 1245lm
These instructions cover procedures for all
surface mounted versions of Solo 11, 16 & 16
Plus series.
03.20
KEY PRODUCT FEATURES
A 2 x Screws
B Luminaire Body
C Microlens
D Microlens Cap
E Optic
Solo 11 & 16
C
A B
Solo 16 Plus
B E
A
1. All systems must be installed by
a suitably qualified professional
only. Installations must conform to
national installation and accident
prevention regulations.
2. Do not install any fixture closer
than 150mm from any combustible 4.
material. Do not install these
products in a damp or wet location.
3. To reduce the risk of fire and burns, 5.
COMPATIBLE
POWER SUPPLY
Eldoled 20W 1-10V
Eldoled 30W 1-10V
F Optic Cap
Eldoled 20W DALI
G Snoot
Eldoled 30W DALI
H Accessory (up to 2)
Eldoled 20W 1-10V
Eldoled 30W 1-10V
I Accessory Clip
Eldoled 20W DALI
J Double Accessory Holder
Eldoled 30W DALI
D
G
F
do not install these products where
exposed bare conductors can be 6.
shorted or contact any conductive
materials. Do not conceal or extend 7.
exposed conductors through a
building wall. 8.
Ensure all connections are tight. Bad
connections can cause overheating,
arcing and a potential fire risk. 9.
Always use appropriate optics and
MAX 16 SERIES
ORDER CODE
LUMINAIRE QTY
PSCC-20-350-A-EL -
PSCC-30-350-A-EL -
PSCC-20-350-D-EL -
PSCC-30-350-D-EL -
PSCC-20-700-A-EL 2
PSCC-30-700-A-EL 3
PSCC-20-700-D-EL 2
PSCC-30-700-D-EL 3
accessory holder (sold separately)
H I J
ensure they are fitted securely. 10. These are LED luminaires, they must
Use only as described in this
Precision Lighting manual.
Use only Precision Lighting 11. Regular cleaning of these products
recommended accessories.
Ensure that the luminaire is switched
off at mains supply before installing
or removing.
Luminaires may be extremely hot,
allow to cool before touching.
© 2020 Precision Lighting Ltd. We reserve the right to change details of design, materials and finish. Version 11.20
MAX 11 SERIES MAX 16 PLUS SERIES
LUMINAIRE QTY LUMINAIRE QTY
2 -
3 -
2 -
3 -
- 1
- 2
- 1
- 2
be connected to an appropriate
PSU.
is important. Switch off at mains
supply and allow to cool before
touching. Clean fittings with a soft
damp cloth and allow to dry before
reconnecting power supply
