- Page 1 INSTRUCTION MANUAL PARTS CATALOGUE THE ALBUTT RANGE OF FOLDING FORKS THIS MUST BE USED IN CONJUNCTION WITH ALBUTT’S GENERAL OPERATOR’S MANUAL www.albutt.com | 01242 620 252 | keith@albutt.co.uk...
-
Page 2: Table Of Contents
CONTENTS Certificate….…………………………………………3 Safety Instructions…..…..……………………4-7 Maintenance………………………………………..8 Machine Specifications….……………………..9 Fitting & Operating Instructions………….10 Parts Lists……..……………….……………………11 Warning Stickers…………………………………12 www.albutt.com | 01242 620 252 | keith@albutt.co.uk... -
Page 3: Certificate
Glos. UK GL20 7AR declare in sole responsibility, that the product Type: FOLDING FORKS B912HX, B914HX, B916HX to which this certificate applies, conforms to the basic safety and health requirements of the EC Machinery Directive 2006/42 EC, and the Transposed Harmonised Standards:... -
Page 4: Safety Instructions
On delivery, your dealer gave you an explanation of the operation and maintenance of this Albutt Folding Fork. Please read and understand these operating instructions before operating the machine for the first time. It is essential that you observe all safety instructions. - Page 5 CAUTION Hydraulic oil forced out under pressure can break the skin and cause severe injury. In the event of a hydraulic oil leak stop the tractor flow immediately. DO NOT PUT HANDS NEAR A LEAKING PIPE. www.albutt.com | 01242 620 252 | keith@albutt.co.uk...
- Page 6 To ensure stability the Folding Fork should be stored in a safe position, supported to prevent it being knocked over. If the implement is to be transported on a trailer then it should be securely attached using suitable restraints. www.albutt.com | 01242 620 252 | keith@albutt.co.uk...
- Page 7 Always keep the Folding Fork and load as low as possible to maximise stability. When operating on the clamp keep the surface as level as possible to avoid lumps and soft spots which may lead to rollover. NEVER attempt to move the implement manually. www.albutt.com | 01242 620 252 | keith@albutt.co.uk...
-
Page 8: Maintenance
Regularly check all bolts and tighten if necessary. Lubricate the hydraulic cylinder and pivot pin daily before use. Only use clean grease complying to Din51502 Clean all grease nipples and the nozzle of the grease gun before lubrication. www.albutt.com | 01242 620 252 | keith@albutt.co.uk... -
Page 9: Machine Specifications
(mm) (ft/m) (mm) (mm) Hardox Tines 12’/ 1650 1530 1250/ B912HX 6.90m3 1500kg 3.70m 1400 14’/ 1650 1530 1250/ B914HX 8.00m3 1650kg 4.27m 1400 16’/ 1650 1530 1250/ B916HX 9.30m3 1780kg 4.88m 1400 www.albutt.com | 01242 620 252 | keith@albutt.co.uk... -
Page 10: Fitting & Operating Instructions
6)When clearing up the floor, ensure the Folding Fork is fully level with the ground, ensuring even wear across the tines and wear strip across the floor of the fork. www.albutt.com | 01242 620 252 | keith@albutt.co.uk... -
Page 11: Parts Lists
2.0 B914HX Parts Drawings www.albutt.com | 01242 620 252 | keith@albutt.co.uk... -
Page 12: Warning Stickers
2.2 Warning Stickers www.albutt.com | 01242 620 252 | keith@albutt.co.uk...
