- Page 1 RFID Cellular Home Security System USER’S GUIDE...
-
Page 2: Table Of Contents
CONTENTS DO THIS FIRST Things to be Noted Before Getting Started System Requirements IN THE BOX MEET YOUR ALARM SYSTEM How the Alarm System Works Getting to Know Your System Smart Hub Remote Tag RFID Tag Door/Window Sensor PIR Motion Detector 10 PLACEMENT/INSTALLATION 10 Where to Place/Install Smart Hub 10 Where to Place Door/Window Sensor... -
Page 3: Do This First
DO THIS FIRST. Things to be Noted Before Getting Started If using 4G SIM card, make sure the 2G network of your wireless service provider is still available in your country. You should purchase the hub with 4G cellular communicator if the 2G network is unavailable. System Requirements To set up and use Alarm System, you’ll need an unused indoor power outlet, and a micro SIM card supporting 2G/GSM(for 2G version) or 4G network (for 4G version). -
Page 4: In The Box
IN THE BOX. RFID Remote Tag x2 Wireless key to quickly Smart Hub (Panel) PIR Motion Detector x1 away-arm, home-arm and Senses when someone Alarm, indicators and disarm your home, and to walks nearby. keypad. trigger an emergency alarm. Door/Window Sensor Wireless Siren (Optional) RFID Tags x2 (Optional) x1(x2 optional) -
Page 5: Meet Your Alarm System
MEET YOUR ALARM SYSTEM. How the Alarm System Works RFID The hub receives the command and enters “Armed” mode. Arm the system by the When a Door/Window remote, RFID tag, the Sensor detects a ARM button of hub door/window is being touchscreen or the APP. -
Page 6: Getting To Know Your System
Getting to Know Your System All sensors are wirelessly connected to the hub. In the event of alarm activation, for example, when a sensor is triggered, a text message will be sent automatically and an alarm call will be made to all registered users. The system can be controlled and monitored both on-site by the remote control supplied or remotely from anywhere with our free dedicated mobile application through SMS. - Page 7 Cellular network indicator What you see What it means No SIM card is inserted or SIM card faulty Dark Blinking Searching network Solid Registered on cellular network Blinking very fast Calling/Recording Status indicator What you see What it means Solid red Armed Solid yellow Armed stay...
-
Page 8: Remote Tag
Remote Tag (Wireless Key) Remote Tag to quickly away-arm, stay-arm and disarm your home, and to trigger an emergency alarm. LED indicator Disarm button Arm button Use when you don’t want the security from Use when no one is at home. the system. -
Page 9: Door/Window Sensor
Door/Window Sensor Door/window sensors are set to Stay Arm Active mode in default and are ideal for protecting entry/exit locations, such as front/back doors and all windows. When the system is armed or home armed and a sensor is triggered (magnet is separated from the sensor), a push notification including the sensor name will be sent automatically to the registered users, and the alarm will sound. -
Page 10: Pir Motion Detector
PIR Motion Detector The motion detector is designed for the usage on interior walls and is set to Out Arm Active Mode in default. Whenever the sensor detects movement (only while the alarm is armed), a push notification including the sensor name will automatically be sent to the registered users, and the alarm will sound . - Page 11 O P E N C LO S E D Setting Jumpers Setting the Pulse Counter (PULSE2 & PULSE1 jumpers) The motion detector is equipped with a programmable pulse counter which can be set to count 1,3 or 5 pulses. Place the pulse count jumpers at the desired setting as shown below.
-
Page 12: Placement/Installation
PLACEMENT/INSTALLATION TIPS Where to Place/Install Smart Hub It should be close to where you come and go. So it’s easy to access on your way in and out. RFID Use an unswitched wall outlet. Find a spot with a good cellular signal. Choose an outlet that’s not controlled by The hub needs a cellular network so it can a switch, so you don’t accidentally turn... -
Page 13: How To Install Pir Motion Detector
How to Install PIR Motion Detector 2. 2m G round Mount the bracket with the included Mounting height screws as shown above. Then place the Motion Detector must be motion detector in the bracket. Specify mounted 79 to 87 inches(2 to the right direction of the detection range 2.2m) above the floor. -
Page 14: Getting Started
GETTING STARTED Install the SIM Card Important: A regular SIM card is required in order to use cellular services when connecting to GSM/4G networks. The availability of cellular capabilities depends on the wireless network. Cellular Network Connection If the blue cellular indicator turns solid, your hub is connected to a cellular network. NOTE: If the indicator is always dark or blinking, the hub has not been connected to a network. -
Page 15: How To Set Phone Numbers For Sms And Phone Calls
How to Set Phone Numbers for SMS and Phone Calls Up to 5 stored Phone Numbers will receive text messages (SMS) and phone calls in case of triggered alarms. Each number could be set independently to one of three alarm modes: ①SMS notification only, ②call only, ③both SMS notification and call. Setting Steps ... -
Page 16: How To Record A Voice Message
Exit Delay is 40 seconds. How to change the Exit Delay Enter System Password + √” Choose “Exit Delay” + √ Input Exit Delay value + √ Entry Delay Entry Delay allows you to enter your home and disarm your system while the system is in Away Arm Mode. -
Page 17: How To Pair A Wireless Sensor
How to Pair a Wireless Sensor Enter System Password + √” Choose “Pairing” + √ Choose “Wireless Sensor” + √ Press the setting button of wireless sensor to send a transmission signal to your hub before the 20 seconds countdown tick ends as shown below. Door/Window Sensor PIR Motion Detector ... -
Page 18: Setting Some Parameters By Instruction Mode
Setting some parameters by Instruction Mode You can input instruction and setting code to set some parameters in Instruction Mode. 1.Enter System Password + √” 2.Choose “Instruction Mode” + √ 3.Input Instruction Code + √ 4.Input Setting Code and √ to set a parameter you specified by Instruction Mode. 5.Go to Step 3 to set the next parameter. -
Page 19: App
Download App Scan the QR codes via a smart phone to download and install the application. You can arm, stay arm, disarm your system by sending text messages using the APP. You can also name your accessories, set Phone Number, Change Exit/Entry Delay or Enable/Disable some features by APP. -
Page 20: Smart Hub Features
Press to home arm. Press to disarm. Press to trigger an emergency alarm. RFID Tap to home arm. To disarm, enter your user passcode, then tap Tap to home arm. Tap to disarm. Tap to trigger an emergency alarm. Smart Hub Features Battery backup If the building has lost electrical power, Smart Hub includes a backup battery that will last for more than 6 hours. -
Page 21: Specifications
SPECIFICATIONS Power Supply: Micro USB 110/220VAC to 5V, 1000mA Backup Battery: 3.7V, 500mAh Rechargeable Lithium Battery Consumption: <55mA@normal Radio Frequency: 433Mhz GSM: 850/900/1800/1900MHz Operation Temperature: 0~55℃ Remote Control Power Supply: DC 3V (CR2025 Lithium Battery x1) Standby Current:<5uA Alarm Current: <15mA Transmitting Distance: <80m (Open Area and No Interference) Radio Frequency: 433Mhz Operation Temperature: 0~55℃...
