S.D.P. EZ Track 4100 Training & Procedure Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
EZ Track 4100
Training & Procedure Manual

Advertisement

loading

Related Manuals for S.D.P. EZ Track 4100

Summary of Contents for S.D.P. EZ Track 4100

  • Page 1 EZ Track 4100 Training & Procedure Manual...

  • Page 2: Load Capacity

    Load Capacity of the EZ Track’s boom. The maximum weight capacity of the EZ Track 4100. • The load capacity of the boom • The load capacity of the boom depends upon the distance from center line of boom turret! •...
  • Page 3 EZ Track 4100 Safety While the EZ Track 4100 is smaller than a line truck, its function is the same and all safety precautions that would apply to a line truck also apply to the EZ Track 4100. The truck also apply to the EZ Track 4100. The EZ Track 4100 is a powerful machine that should be operated with respect &...
  • Page 4 Hard hats and protective gear must be worn by all personnel when using the EZ Track 4100. Track 4100.
  • Page 5 • Properly use all outriggers DANGER! whenever the boom is in use. The EZ Track 4100 boom must ALL OUTRIGGERS MUST never be operated without the BE FULLY EXTENDED outriggers being properly set. BEFORE OPERATING...
  • Page 6 Be sure to follow your company’s safety procedures to protect against electrocution. • The EZ Track 4100 is not designed to carry passengers. Never let anyone ride on the machine. • Operators must be properly trained before operating any part of the EZ Track 4100.
  • Page 7 Know the location and function of all controls before starting the machine. starting the machine. • The EZ Track 4100 can be shut down in an emergency by releasing all drive controls and turning the ignition switch to the “off” position.

  • Page 8: Pre-Trip Inspection

    Pre-trip Inspection • Before each day’s operation, the EZ Track 4100 must be inspected by the operator. • Do a visual inspection to check for lose, worn, missing or broken parts such as bolts, broken parts such as bolts, nuts, wires & retaining pins.
  • Page 9 Pre-trip Inspection Check all tires on the EZ Track 4100 trailer for EZ Track 4100 trailer for wear & proper inflation.
  • Page 10 Pre-trip Inspection Test all turn signal, parking and brake lights by turning them on. Be sure to test the braking action on the braking action on the trailer before traveling to the work site.
  • Page 11 Pre-trip Inspection • Check to make sure that EZ Track 4100 is properly secured to the trailer. • Look inside the trailer toolbox & make sure it contains all tools & equipment necessary for operating the EZ Track 4100.
  • Page 12 Pre-trip Inspection Turn on the remote control & check the function of all controls. Always check if the battery is charged.
  • Page 13 Pre-trip Inspection Inspect the lift line and hook for signs of wear or damage. Replace any worn or damages parts before using the parts before using the EZ Track 4100. (Pictures may not be a true representation of your machine.)
  • Page 14 EZ Track 4100 Controls Familiarize yourself with all of the controls and layout of the controls on the machine. As the operator you need to know!
  • Page 15 Remote Control Basic Operation Turn E-stop counter- clockwise to turn on remote and press to shut off remote. Auger switch: A position to dig, B position to reverse (clean). NOTE: Auger will stop digging during overload, reverse auger to stop overload. Audible alarm will sound.
  • Page 16 Driving the EZ Track 4100 The EZ Track 4100 does not require its full engine power when moving. Set the engine speed relatively low when driving the unit, reserving the higher engine speeds for powering hydraulic accessories.
  • Page 17 • Caution: While unloading the EZ Track 4100, always have the trailer attached to a truck and the boom in its lowest position. • Note: If the EZ Track 4100 engine is not started, start it and let it warm up for 5 minutes.
  • Page 18 (Pictures may not be a true representation of your machine.) NOTE: The EZ Track 4100 is secured for transport at the front and back of the trailer.
  • Page 19 Moving the EZ Track 4100 One of the advantages of the EZ Track 4100 is that it is tough enough to operate in areas which are considered too rugged to use a line truck.
  • Page 20 EZ Track 4100 Transporting a Pole Lifting and carrying a pole can be performed easily with the hydraulic outriggers. Attach the provided lifting chains to the pole and to the d-rings on the EZ Track 4100 outrigger arms as shown.
  • Page 21 Using the outrigger control levers lift both outriggers equally until pole is securely in place. NOTE: Pole must clear NOTE: Pole must clear tracks when completely lifted Reverse procedure when pole is ready to be lowered to the ground.
  • Page 22 Setting a Pole With the EZ Hauler 4100 • Remember the EZ Track 4100 is not totally electrically insulated. Use your company’s Use your company’s insulation procedure to avoid electrocution. Before setting a pole the load capacity chart must be thoroughly understood.
  • Page 23 Setting the Outriggers Make sure the PTO is pushed in for outrigger function. Use the outrigger controls to lower outriggers to level and support the machine. Oversized outrigger pads might be required depending on soil conditions.
  • Page 24 Auger Operation Procedure...
  • Page 25 Make sure that boom sections are fully retracted and that auger pins are in correct position. Using the auger remote circuit wind up the auger slightly to release tension on latch pin. NOTE: Use the flow control on the remote control to control the remote control to control the speed of the auger.
  • Page 26 Release auger latch and slowly lower auger. IMPORTANT: You must raise boom to lower auger assembly and avoid equipment damage.
  • Page 27 5. Carefully unwind (dig) auger and remove strap. You are now ready to use the remote control to auger as needed. (Pictures may not be a true representation of your machine.)
  • Page 28 5. Reverse this procedure to store the auger. Again making sure to have boom extensions fully retracted before stowing auger. DO NOT “OVER STORE” THE AUGER AS DAMAGE CAN OCCURE! NOTE: Make sure to place boom extension pins in proper CRANE location before extending boom sections.

  • Page 29: Digging The Hole

    Digging the Hole • Position the machine over the desired hole replacement area. Extending boom 12 or 14 inches and allowing enough slack in rope to drill a straight hole down. • Turn on the remote and toggle the Auger switch to the correct direction then lower the auger direction then lower the auger to begin digging.
  • Page 30 Take small bites and let the auger dig at its own pace until the hole is the proper depth. Different regions have many different soil compositions; familiarize yourself with your digging surface for your safety and those around you. (Pictures may not be a true representation of your machine.)
  • Page 31 If needed, the extension bar may adjusted for more digging depth. (Pictures may not be a true representation of your machine.)
  • Page 32 Setting the Pole 1. Unwind winch line. 2. Unpin 3rd stage fiberglass extension. 3. Pull extension out past first pin holes. Making sure stop latch handle is in a vertical position.
  • Page 33 4. Pull extension out until stop latch pin engages. WARNING! Fiberglass final stage must be fully stage must be fully extended and pinned for dielectric insulation! 5. Reinstall lock pin.
  • Page 34 • Install hydraulic pole guide. Refer to installation instructions. • Raise the boom into position so that the lift line will be lifting straight up. Follow load lifting straight up. Follow load chart specifications on weight in relationship to boom angle. •...
  • Page 35 • Lift the pole straight up and set into the hole. • Always operate EZ Hauler 4100 from a safe distance using the remote control. • Never use manual lever overrides for normal operation, they are for emergency use only.
  • Page 36 Bucket Assembly Standard Operating Procedure Operating Procedure...
  • Page 37 • CAUTION: Prior to using the bucket assembly, extend and secure all outriggers to the fullest settings. • NOTATION: The bucket assembly has the lifting capabilities of 300 pounds. pounds. • The following instructions are provided to ensure safe operation of the bucket assembly.
  • Page 38 The bucket attachment switch allows for the operator to disable the winch function on the remote control and disengage the H.O.P. overload system as to prevent the operator from locking the unit in a from locking the unit in a vertical position.
  • Page 39 With remote control extend boom to bucket and pin bucket to boom. Follow all safety procedures and weight charts when operating the bucket. After completing the tasks, return the hydraulic boom sections to the retracted “stowed” position before lowering the bucket to a flat surface.
  • Page 40 Hydraulic Pole Guide Procedure Procedure...
  • Page 41 1. Slide pole guide in to receiver of sheave head. 2. Install and secure pin.
  • Page 42 3. Make sure hydraulic couplers on pole guide and hose reel are clean. 4. Connect hydraulic couplers from hose reel to pole guide. Make sure connection is secure.
  • Page 43 5. Remember that the pole guide is conductive so it will not be insulated against cross fazing, but with the fiberglass stage boom properly pinned in place the EZ Hauler 4100 and its operator will be substantially protected.
  • Page 44 IMPORTANT! The EZ Track 4100 series of machines are all dielectrically tested to 46kv category “C” guidelines. This qualification test is performed at the factory in accordance with ANSI A10.31 guidelines. It is important that periodic tests be performed to the EZ Track just as any other digger-derrick in a companies fleet.
