AMX AXM-EL Plus Dimensional Drawing
AMX AXM-EL Plus Dimensional Drawing

AMX AXM-EL Plus Dimensional Drawing

Rack mount
Hide thumbs Also See for AXM-EL Plus:

Advertisement

Quick Links

NOTICE: This drawing is the
UNLESS OTHERWISE SPECIFIED:
property of AMX Corporation.
TOLERANCE ON DECIMAL DIMENSIONS:
XX = .010
All information contained herein
XXX = .005
that is not generally known
TOLERANCE ON HOLE DIAMETERS:
shall be confidential except
UNDER .250 ú
= +/- .005
.250 TO .500
= +.006 -.005
to the extent the information
OVER .500
= +.008 -.005
has been previously established.
FRACTIONAL DIMENSIONS INCLUDING HOLES: +/- 1/64
This drawing may not be copied,
ANGLES: +/- 1.0°
SURFACE FLATNESS .003 TIR PER LINEAR INCH.
reproduced, or used as the basis
ALL DIMENSIONS IN INCHES.
for manufacture or sale without
DO NOT SCALE THIS DRAWING.
written permission.
REVISIONS
REV
ECN
DESCRIPTION
A
ADDED METRIC DIMENSIONS
B
3076 RESURRECTION
REL APPR
REL DATE
REV APPR
DRAWN
RDR
4/15/92
TM
ENGR SERV
ENGINEER
PICTORIAL
PROD ENGR
AXM-EL+ TOUCHPANEL
(RACK MOUNT)
MATL SUP
SIZE
SCALE
DWG. NO.
QUALITY
95-0797-03
C
FULL
THIRD ANGLE
PROJECTION
95-079703
DATE
APPROVED
12/22/93
11/26/01
REV.
B
1 OF 1
SHEET
