Page 1: Table Of Contents
Português . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 163 www.rollei.com... -
Page 2: Safety Instructions
Safety instructions Please read this manual carefully before using the device . 1 . Please turn of the trigger, the flash light as well as the camera while connecting them with each other . 2 . Do not let the product fall down and do not shake it as this might cause damage to the product . -
Page 3: Function List
Function List 1 . Available flash modes: E-TTL, E-TTL (II), iTTL, M and Multi 2 . Front curtain sync / rear curtain sync / high speed sync (up to 1/8000s) 3 . Exposure compensation (FEC) 4 . Surrounded exposure (FEB) 5 . -
Page 4: Components
Components Rubber cap Group C / Sync mode button Micro USB Group D / Channel Setting Group B Power switch: ON / OFF Group A / Customized function Flash ratio setting setting (in master control mode) Mode Settings / OK button / Test restore to factory setting Parameter settings... -
Page 5: Lcd Screen
Components LCD screen Automatic focusing assist Focal distance Rear curtain sync Aperture High speed sync Strobe flash Manual / Multi Mode FEB logo Wireless channel Times Flash parameter setting for A Master control camera series Flash parameter setting for B Flash parameter setting for C Flash parameter setting for D Flash ratio... -
Page 6: Power Switch
Component instruction Power switch: • Slide to ON to turn the device on . • Slide to OFF to turn the device off again . Hot Shoe Use it to connect the device with your camera . This is compatible with Nikon and Canon cameras . Mode Transmitter mode Test... -
Page 7: Preparation
Preparation Inserting the batteries Open the battery compartment and install two AA batteries according to the positive and negative direction shown in the battery compartment . After- wards close the battery compartment again . • If you don‘t use the product for a long time, please remove the batteries . -
Page 8: Test
Functions Mode options Turn the trigger on and press the mode button repeatedly to switch between the different modes . You can select the universal mode, Canon mixed mode, Canon master control TTL mode, Canon master control M mode, Canone master control Multi mode, Nikon master control mixed mode, Nikon master control Multi mode . - Page 9 Customized function Press the Group A button for about 2 seconds and the trigger will go into the customized settings . Press the up and down buttons to select the desired function and change the value from on to off by using the left and right buttons . Customized Functions Status setting Instruction...
-
Page 10: Customized Function
Customized function Sync mode setting In the universal mixed mode press the group C button for about 2 seconds and the sync mode will change between high speed sync , rear curtain sync front curtain (no sign on the LCD) . In the Canon master TTL or M mode press the button for 2 seconds and the sync mode will change between high speed sync and front curtain sync (no sign on the LCD) . -
Page 11: Assisted Focusing Light
Customized function Assisted focusing light If the assist focusing light is turned on in the custom settings, the light will automatically help to focus in low light situations . To use the focusing light correctly, you need to set the camera in the automatic mode . Turn on the auto focus function on the camera lens . -
Page 12: Canon Mixed Mode
Canon mixed mode 1. Group mode and parameter setting 1) Press the mode button to select the transmitter mode universal mixed mode (as shown on the picture) . 2) Press A, B, C, D shortly to select or exit the flash group setting . - Page 13 Canon mixed mode • In this mode you can set different flash groups in different flash modes and power . Flash groups that are in TTL mode can do ETTL if a Canon camera is used and iTTL if a Nikon camera is used . •...
- Page 14 Canon mixed mode 3) You can set the sync speed for the shutter and the group setting FEB exposure in the internal menu setting of your camera . Press the test button so that the transmitter is passing over all the settings to the flash lights . After that the flash units should display the reveiving information on the LCD (modes and parameters) .
-
Page 15: Canon Master Control Ttl Mode
Canon master control TTL mode 1. Parameter setting for groups 1) Press the mode button to select the transmitter mode Canon master control TTL mode (as shown on the picture below) . High speed sync Canon master control mode Wireless channels Focal distance Automatic focus assist Aperture... - Page 16 Canon master control TTL mode If the flash ratio is disabled (ALL) this means that all flash units of the three groups will have the same output in brightness, exposure compensation and surrounded exposure. If the flash ratio A:B is selected that means that the flashes of group A and B will flash in the same power output. And if the ratio A:B:C is selected that means that all flashes of the three groups will flash, the groups A and B will have the output brightness and group C is the power exposure. 3) P ress the OK button repeatedly until the flash ratio number is indicated with an arrow. Press the left and right button to set the flash ratio. 4) I f the flash ratio is A:B:C press the OK button repeatedly until the group C is indicated with the arrow. Press the left and right button to set the exposure compensation. • If the flash ratio A:B is selected the flash units of group C won‘t flash. • If the flash units of group C are positioned towards the subject, the subject will be overexposed. ENGLISH...
- Page 17 Canon master control TTL mode 2. Canon camera internal menu setting This is only available for Canon cameras of the series A and the camera exposure mode needs to be P/AV/TC/M . Enter the menu of your camera and select the flash control . Then select the external flash function setting to set the strobe flash parameter options .
-
Page 18: Flash Ratio Setting
Canon master control TTL mode 4) Flash ratio setting 1 . ALL (A+B+C) If the flash ratio off is chosen that means that all flash groups have the same power output . 2 . A:B Here you can set the flash ratio (8:1–1:8 in 1/2 steps) and the flash exposure compen- sation for both groups A and B . -
Page 19: Canon Master Control M Mode
Canon master control M mode 1. Parameter setting for groups 1) Press the mode button repeatedly to select the transmitter mode as Canon master control M mode (as shown on the picture below) . Automatic focus assist Cannon master control mode High speed sync Focal distance Wireless channel... - Page 20 Canon master control M mode 2) After the mode has been selected and nothing else has been changed so far, press the left and right button to set the power output for group A . Press the up and down button to set the flash ratio between Off, A:B and A:B:C . A:B C If the flash ratio off is chosen that means that all flash groups have the same power output .
- Page 21 Canon master control M mode 4) Group C flash power output (A:B:C) Press the OK button repeatedly until the arrow is indicating the group C . Press the left and right button to set the output power of group C . Press the OK button repeatedly until the focal distance number is highlighted for each group and press the left and right button to change the value .
- Page 22 Canon master control M mode 2) Channel setting (by wireless flash menu) After the wireless flash is enabled the transmitter‘s channel can be set by the camera menu (only from1 to 4 channels) and the changed channel will be shown on the transmitter .
- Page 23 Canon master control M mode Manual settings for all groups (A,B,C) 1 . Set flash output for all groups (A,B,C) . 2 . Set flash output seprately for A:B, unable for group C . 3 . Set flash output seprately for A:B:C .
-
Page 24: Canon Master Control Multi Mode
Canon master control Multi mode Parameter settings for groups 1 . Press the mode button repeatedly to select the transmitter mode as Canon master control Multi mode (as shown on the picture below) . Automatic Focus Assist Canon master control mode Master Multi mode Focal distance Wireless channel... - Page 25 Canon master control Multi mode If the flash ratio off is chosen that means that all flash groups have the same power output . If the ratio A:B is selected the groups A and B are enabled and the power of both groups can be set individually . If the ratio A:B:C is selected all groups are enabled and the power of each group can be set individually .
- Page 26 Canon master control Multi mode 5 . Flash power output of group B (A:B, A:B:C) Press the OK button repeatedly until group B is highlighted with an arrow . Press the left and right button to set the power output of group B . 6 .
-
Page 27: Nikon Master Control Mixed Mode
Nikon master control mixed mode Parameter settings for groups 1 . Press the mode button repeatedly to select the transmitter mode as Nikon master control mixed mode (as shown on the picture below) . Automatic focus assist Nikon master control mode High speed sync Focal distance Wireless channel... - Page 28 Nikon master control mixed mode 3 . After you have selected the group press the mode button to set the flash mode for this group . The mode parameters are as follows: TTL: The exposure compensation can be set from -3,0EV to +3,0EV . In total you have 22 levels .
-
Page 29: Nikon Master Control Multi Mode
Nikon master control Multi mode Parameter setting for groups 1 . Press the mode button repeatedly to select the transmitter mode as Nikon master control multi mode (as shown in the picture below) . Within this modes all parameters of each groups are the same . Automatic focusing assist Nikon master control mode Master control Multi mode... - Page 30 Nikon master control Multi mode 2 . If the mode is chosen, press the left and right button to set the flash power which is available from 1/4 to 1/128 (in total 6 levels) . 3 . Press the OK button repeatedly until the frequency number is highlighted . Press the left and right button to set the flash frequency from 1 –...
-
Page 31: Compatible Devices
Compatible Devices Two series of Canon cameras based on different functions 1 . Available for camera-menu-controlled external flashlights (Series A): 350D, 400D, 450D, 500D, 550D, 600D, 650D, 700D, 1100D, 1000D, 1200D, 40D, 30D, 1D Mark III, 1D Mark IV, 1Ds Mark III, 5D, 7D, 70D, 80D, 60D, 50D, 5D Mark II, 5D Mark III, 5D Mark IV 2 . -
Page 32: Disposal | Ce Conformity
. Do not dispose old devices into the household waste! If the Rollei Pro Radio Transmitter 2 .4 G for Canon / Nikon is no longer used, every consumer is legally obligated to dispose them separately from the household waste, for example, at a collection site of his community / city district .
