Kenwood KCH-14 Service Manual

Front panel kit
Hide thumbs Also See for KCH-14:
Table of Contents

Advertisement

Quick Links

Document Copyrights
Copyright 2006 by Kenwood Corporation. All rights reserved.
No part of this manual may be reproduced, translated, distributed, or transmitted in any
form or by any means, electronic, mechanical, photocopying, recording, or otherwise, for
any purpose without the prior written permission of Kenwood.
Disclaimer
While every precaution has been taken in the preparation of this manual, Kenwood
assumes no responsibility for errors or omissions. Neither is any liability assumed for
damages resulting from the use of the information contained herein. Kenwood reserves
the right to make changes to any products herein at any time for improvement purposes.

Advertisement

Table of Contents
loading

Related Manuals for Kenwood KCH-14

Summary of Contents for Kenwood KCH-14

  • Page 1 Kenwood. Disclaimer While every precaution has been taken in the preparation of this manual, Kenwood assumes no responsibility for errors or omissions. Neither is any liability assumed for damages resulting from the use of the information contained herein. Kenwood reserves...

  • Page 2: Table Of Contents

    DISASSEMBLY FOR REPAIR ....... 2 TERMINAL FUNCTION ........16 CIRCUIT DESCRIPTION ........5 PC BOARD SEMICONDUCTOR DATA ........7 DISPLAY UNIT (X54-3490-20) : KCH-14 ..18 COMPONENTS DESCRIPTION ......8 DISPLAY UNIT (X54-3500-20) : KCH-15 ..20 PARTS LIST ............9 SCHEMATIC DIAGRAM EXPLODED VIEW ..........

  • Page 3: Disassembly For Repair

    ■ Disassembly of the Display unit (X54-350):KCH-15 Disassembly Procedure 1. Remove the volume knob z and selector knob x. ■ Disassembly of the Display unit (X54-349):KCH-14 2. Remove the 2 hexagon nuts c. 1. Remove the volume knob z and selector knob x.
  • Page 4 KCH-14/15 DISASSEMBLY FOR REPAIR Precautions for Reassembly ■ Procedure when the packing (G53-0838-13) is removed from the Panel ASSY When the packing is removed from panel ASSY, affix new sheet (G11-4376-04) to the panel ASSY by following procedures. 1. Remove the white covering paper from the short side of the sheet z.
  • Page 5 ■ Fitting the convex (drain hole part) of the speaker packing to the hollow (drain hole part) of the panel ASSY : KCH-14 only Push the convex (drain hole part) of the speaker packing with a flat-head screwdriver as shown in figure until drain hole of the speaker fit to the drain hole of the panel.

  • Page 6: Circuit Description

    The optional display unit (front panel unit) for the TK- and the PTT and HOOK signals, are converted to serial data 5710(B)/5710H(B) comes in two models : KCH-14 and KCH- and sent to the control unit. Data is displayed on the 12-digit and 3-digit dot matrix alphanumeric display.
  • Page 7 KCH-14/15 CIRCUIT DESCRIPTION 1-2. KCH-15 • LCD brightness function This display unit consists of the CPU (IC3), 5V AVR (IC1) From the control of the CPU’s DM1/DM2 port, you can and other components. switch the LCD/KEY backlight or the optional KMC-28 key backlight as shown in the following table.

  • Page 8: Semiconductor Data

    KCH-14/15 SEMICONDUCTOR DATA CPU:30302M84Z2GP(Display unit IC3) Port Name Function Port Name Function No connection (KCH-14), [PF9] Key (KCH-15) − No connection No connection (KCH-14), [PF8] Key (KCH-15) − BYTE No connection (KCH-14), [PF7] Key (KCH-15) − CNVSS No connection (KCH-14), [PF6] Key (KCH-15) −...

  • Page 9: Components Description

    KCH-14/15 COMPONENTS DESCRIPTION Display unit (X54-3490-20):KCH-14 Display unit (X54-3500-20):KCH-15 Ref. No. Part name Description Ref. No. Part name Description Q1~3 Transistor DC switch Q1~3 Transistor DC switch DC switch DC switch Q5~9 Transistor 9V AVR Q5-20 Transistor 9V AVR Transistor...

  • Page 10: Parts List

    KCH-14/15 PARTS LIST CAPACITORS CC 45 TH 1H Capacitor value Color* CC45 010 = 1pF 0 = 22pF 1 = Type ... ceramic, electrolytic, etc. 100 = 10pF 4 = Voltage rating Multiplier 2 = Shape ... round, square, ect.
  • Page 11 0 OHM J 1/16W T07-0265-05 SPEAKER R2 ,3 RK73GB1J102J CHIP R 1.0K J 1/16W R92-1252-05 CHIP R 0 OHM J 1/16W DISPLAY UNIT (X54-3490-20) : KCH-14 ∗ RK73PB2H821J CHIP R J 1/2W RK73GB1J473J CHIP R J 1/16W D8 ,9 B30-2019-05 LED(RE/GR)
  • Page 12 KCH-14/15 PARTS LIST DISPLAY UNIT (X54-3490-20) KCH-15 (Y60-4060-20) DISPLAY UNIT (X54-3500-20) Address Parts No. Description Destination Address Parts No. Description Destination Ref. No. Ref. No. parts parts ∗ R28 -30 R92-0670-05 CHIP R 0 OHM G11-4380-14 SHEET ∗ R32 -34...
  • Page 13 KCH-14/15 PARTS LIST DISPLAY UNIT (X54-3500-20) Address Parts No. Description Destination Address Parts No. Description Destination Ref. No. Ref. No. parts parts ∗ CC73GCH1H101J CHIP C 100PF S2 ,3 S70-0502-05 TACT SWITCH ∗ CK73GB1H102K CHIP C 1000PF K S5 -15...

  • Page 14: Exploded View

    KCH-14/15 EXPLODED VIEW (KCH-14) Display unit (C/3) Display unit (A/3) Display unit (B/3) A : N82-2005-45 B : N82-3006-46 C : N87-2605-46 D : N87-2606-45 E : N87-2608-46 Parts with the exploded numbers larger than 700 are not supplied.
  • Page 15 KCH-14/15 EXPLODED VIEW (KCH-15) Display unit (B/2) Display unit (A/2) B : N82-3006-46 C : N87-2605-46 E : N87-2608-46 Parts with the exploded numbers larger than 700 are not supplied.

  • Page 16: Packing

    KCH-14/15 PACKING 42. KNOB 710. PROTECTION BAG (K29-5276-03) 43. KNOB (K29-5277-03) 44. KNOB 41. KNOB (K29-5305-03) (K29-4704-04) 47. KNOB (K29-9353-13) 50. SCREW SET 48. KNOB (N99-0364-05) (K29-9354-03) 49. KNOB (K29-9356-03) 711. PROTECTION BAG 712. PROTECTION BAG 26. PACKING FIXTURE (H12-3182-02) 713.

  • Page 17: Terminal Function

    KCH-14/15 TERMINAL FUNCTION Display unit (X54-3490-20): KCH-14 Name Description Name Description − LCD brightness CN1 (to Control unit W700 of the TK-5710(B)/TK-5710H(B)) − MIC GND CN14 (to Display unit A/3 CN13) PF1 switch signal output MIC signal output − PF2 switch signal output...
  • Page 18 KCH-14/15 TERMINAL FUNCTION Display unit (X54-3500-20): KCH-15 Name Description Name Description KVL3000 signal input (L:Connect, H:Disconnect) CN1 (to Control unit W700 of the TK-5710(B)/TK-5710H(B)) − I/O Serial data input/output for keypad MIC MIC GND MIC backlight control signal output MIC signal output −...

  • Page 19: Display Unit (X54-3490-20) : Kch-14

    KCH-14/15 PC BOARD CN13 J72-0946-19 A/3 DISPLAY UNIT (X54-3490-20) : KCH-14 Component side view (J72-0946-19) DISPLAY UNIT (X54-3490-20) : KCH-14 Foil side view (J72-0946-19) CN14 J72-0946-19 A/3 INT1 END 3 CN16 CN6 CN7 CN10 CN8 CN9 CN11 CN15 BUSY SCLK...
  • Page 20 KCH-14/15 PC BOARD DISPLAY UNIT (X54-3490-20) : KCH-14 Component side view (J72-0946-19) Ref. No. Address J72-0946-19 B/3 J72-0946-19 C/3 6-19 A/3 Component side Layer 1 Layer 2 Foil side Ref. No. Address Ref. No. Address Ref. No. Address 6-19 A/3...
  • Page 21 KCH-14/15 KCH-14/15 PC BOARD PC BOARD DISPLAY UNIT (X54-3490-20) : KCH-14 Component side view (J72-0946-19) Ref. No. Address J72-0946-19 B/3 J72-0946-19 C/3 CN13 J72-0946-19 A/3 DISPLAY UNIT (X54-3490-20) : KCH-14 Component side view (J72-0946-19) Component side Layer 1 Layer 2 Foil side Ref.

  • Page 22: Display Unit (X54-3500-20) : Kch-15

    KCH-14/15 PC BOARD DISPLAY UNIT (X54-3500-20) : KCH-15 Component side view (J72-0947-19) DISPLAY UNIT (X54-3500-20) : KCH-15 Foil side view (J72-0947-19) INT1 END 3 CN16 CN15...

  • Page 23: Schematic Diagram Display Unit (X54-3490-20) : Kch-14

    KCH-14/15 PC BOARD DISPLAY UNIT (X54-3500-20) : KCH-15 Component side view (J72-0947-19) Ref. No. Address J72-0947-19 B/2 Component side Layer 1 Layer 2 J72-0947-19 A/2 Foil side DISPLAY UNIT (X54-3500-20) : KCH-15 Foil side view (J72-0947-19) Ref. No. Address Ref. No. Address Ref.
  • Page 24 KCH-14/15 KCH-14/15 PC BOARD PC BOARD DISPLAY UNIT (X54-3500-20) : KCH-15 DISPLAY UNIT (X54-3500-20) : KCH-15 Component side view (J72-0947-19) Component side view (J72-0947-19) Ref. No. Address J72-0947-19 B/2 Component side Layer 1 Layer 2 J72-0947-19 A/2 Foil side DISPLAY UNIT (X54-3500-20) : KCH-15...
  • Page 25 KCH-14/15 SCHEMATIC DIAGRAM KCH-14 DISPLAY UNIT (X54-3490-20)(A/3) 9V AVR 2SC2873(Y) LEDA E40-5953-05 VOLTAGE REFERENCE 02CZ9.1(X,Y) RESET 13.48V TA7805F RESET DC SW E40-5704-05 2SK1824 XOUT L77-1956-05 INT1 INT0 E40-5952-05 HOOK 4.7k 100p 100p RXD2 1SS355 9V AVR DC SW TXD2 BUSY...
  • Page 26 KCH-14/15 SCHEMATIC DIAGRAM KCH-14 DISPLAY UNIT (X54-3490-20)(A/3) 9 10 E40-5823-05 4.95V 9V AVR 9V AVR 8.70V LEDA 9V AVR DTC144EE DTC144EUA DTC144EUA CN10 CN11 0-4.95V 4.95V DC SW 2.2k 1SS301 RESET BYTE CNVSS (X54-3490-20)(B/3) RESET XOUT XOUT 30302M84Z2GP 4.95V INT1...
  • Page 27 KCH-14/15 SCHEMATIC DIAGRAM KCH-14 DISPLAY UNIT KCH-14 DISPLAY UNIT (X54-3490-20)(A/3) (X54-3490-20)(A/3) 9 10 E40-5823-05 4.95V 9V AVR 9V AVR 2SC2873(Y) 9V AVR 8.70V LEDA LEDA 9V AVR DTC144EE DTC144EUA DTC144EUA CN10 E40-5953-05 VOLTAGE CN11 REFERENCE 0-4.95V 4.95V 02CZ9.1(X,Y) RESET DC SW 2.2k...
  • Page 28 KCH-14/15 SCHEMATIC DIAGRAM KCH-15 DISPLAY UNIT (X54-3500-20)(A/2) 9V AVR 2SC2873(Y) LEDA E40-5953-05 VOLTAGE REFERENCE 02CZ9.1(X,Y) RESET 13.48V TA7805F RESET DC SW 2SK1824 E40-5704-05 XOUT L77-1956-05 INT1 INT0 E40-5952-05 HOOK 4.7k 100p 100p RXD2 1SS355 9V AVR DC SW TXD2 BUSY...
  • Page 29 KCH-14/15 SCHEMATIC DIAGRAM KCH-15 DISPLAY UNIT (X54-3500-20)(A/2) 9 10 E40-5823-05 9V AVR 4.95V 8.70V 9V AVR 9V AVR LEDA DTC144EE DTC144EUA DTC144EUA CN10 CN11 0-4.95V 4.95V DC SW 1SS301 2.2k RESET BYTE CNVSS RESET XOUT XOUT 30302M84Z2GP 4.95V INT1 INT1...
  • Page 30 KCH-14/15 SCHEMATIC DIAGRAM KCH-15 DISPLAY UNIT KCH-15 DISPLAY UNIT (X54-3500-20)(A/2) (X54-3500-20)(A/2) E40-5823-05 9 10 9V AVR 9V AVR 4.95V 2SC2873(Y) 8.70V 9V AVR 9V AVR LEDA LEDA DTC144EE DTC144EUA DTC144EUA CN10 E40-5953-05 CN11 VOLTAGE REFERENCE 0-4.95V 4.95V 02CZ9.1(X,Y) DC SW...
  • Page 31 Rembrücker Str. 15, 63150 Heusenstamm, Germany Leuvensesteenweg 248 J, 1800 Vilvoorde, Belgium 13, Boulevard Ney, 75018 Paris, France KENWOOD House, Dwight Road, Watford, Herts., WD18 9EB United Kingdom Amsterdamseweg 37, 1422 AC Uithoorn, The Netherlands Via G. Sirtori, 7/9 20129 Milano, Italy Bolivia, 239-08020 Barcelona, Spain (A.C.N.
