Page 8: Introduction
This document is the Hardware Reference Manual for the Q7 Generic Carrier Card. This board is fully supported by iWave Systems Technologies Pvt. Ltd. This Manual includes system setup, debugging and provides detailed information on the overall design and usage of the Q7 Generic Carrier Card from a Hardware Systems perspective. - Page 9 On board Taiyo Yuden SDIO OEM Wi-Fi module “WYSAAVDX7” Miscellaneous 3V, Coin cell for RTC Reset Button Power On Button SPI header Additional Features from expansion connectors VGA Output (optional) Rev 1.0 iWave Systems Technologies Pvt. Ltd. Page 9 of 69...
- Page 10 - 0°C to +70°C Commercial grade PCB Nano-ITX- 120 mm × 120 mm (4.7 in × 4.7 in) Note: All Optional Features will not be supported in default configuration. Please contact iWave for optional features support. Rev 1.0 iWave Systems Technologies Pvt.
-
Page 11: Q7 Generic Carrier Card Kit Accessories
MSPS Milli Second Per Sample Printed Circuit board PUMS Power Up Mode Supply Pulse Width Modulation Red Green Blue RMII Reduced Media Independent Interface ROHS Restriction of Hazardous Substances Rev 1.0 iWave Systems Technologies Pvt. Ltd. Page 11 of 69... - Page 12 Real Time Clock Secure Digital SDIO Secure Digital Input Output Serial Peripheral Interface Synchronous Serial Interface UART Universal Asynchronous Receiver/Transmitters Universal Serial bus Voltage Video Graphics Array Gigabit Ethernet Rev 1.0 iWave Systems Technologies Pvt. Ltd. Page 12 of 69...
-
Page 13: Q7 Generic Carrier Card And Design
TV IN Keymatrix Connector - 2 Header RGB-24bit 50pin Cap TP 7” +12V DC Input MAIN RGB LCD Conn Power Jack Figure 1: Q7 Generic Carrier Card Block Diagram Rev 1.0 iWave Systems Technologies Pvt. Ltd. Page 13 of 69... -
Page 14: Qseven Mxm Connector
Aces 88882-2D0K 88882-2Dxx 5.0mm 7.5mm 2.2.1 Mechanical Dimensions of Qseven CPU Module Below figures shows the mechanical spec of CPU modules. For more information refer Qseven spec 1.20 “Qseven-Spec_1.20.pdf” Rev 1.0 iWave Systems Technologies Pvt. Ltd. Page 14 of 69... -
Page 15: Mxm Connector Pin Out
Table 3: MXM Connector Pin Out PIN NO SIGNAL NAME PIN NO SIGNAL NAME GBE_MDI3- GBE_MDI2- GBE_MDI3+ GBE_MDI2+ LINK 100# GBE_LINK 1000# ETH_TXN_GBE_MDI1- ETH_RXN_GBE_MDI0- ETH_TXP_GBE_MDI1+ ETH_RXP_GBE_MDI0+ ETH_LINK# ETH_ACT# ETH_CTREF SUS_S5# SUS_S3# PWRBTN# Rev 1.0 iWave Systems Technologies Pvt. Ltd. Page 15 of 69... - Page 16 SDIO_DAT1 SDIO_DAT0 SDIO_DAT3 SDIO_DAT2 SDIO_DAT5 SDIO_DAT4 SDIO_DAT7 SDIO_DAT6 AC_SYNC AC_RST# AC_BITCLK AC_SDI I2C_CLK AC_SDO I2C_DAT USB_P4- USB_P4+ USB_2_3_OC# USB_0_1_OC# USB_P3- USB_P2- USB_P3+ USB_P2+ USB_CC USB_ID USB_P1HC- USB_P0- USB_P1HC+ USB_P0+ Rev 1.0 iWave Systems Technologies Pvt. Ltd. Page 16 of 69...
- Page 17 LVDS_B3+ LVDS_A3- LVDS_B3- LVDS_A_CLK+ LVDS_B_CLK+ LVDS_A_CLK- LVDS_B_CLK- LVDS_BLT_CTRL_GP_PWM_OUT0 RSVD2 LVDS_DID_DAT_GP_I2C_DAT LVDS_BLC_DAT LVDS_DID_CLK_GP_I2C_CLK LVDS_BLC_CLK CAN0_TXD CAN0_RXD TMDS_CLK+_SDVO_BCLK+ TMDS_CLK-_SDVO_BCLK- TMDS_LANE1+_SDVO_GREEN+ TMDS_LANE1-_SDVO_GREEN- TMDS_LANE0+_SDVO_BLUE+ TMDS_LANE0-_SDVO_BLUE- TMDS_LANE2+_SDVO_RED+ HDMI_SDVO_CTL_DAT TMDS_LANE2-_SDVO_RED- HDMI_SDVO_CTL_CLK HDMI_HPD# PCIe_CLK_REF+ PCIe_WAKE# PCIe_CLK_REF- Rev 1.0 iWave Systems Technologies Pvt. Ltd. Page 17 of 69...
- Page 18 VCC_5V_CPU VCC_5V_CPU VCC_5V_CPU VCC_5V_CPU VCC_5V_CPU VCC_5V_CPU VCC_5V_CPU VCC_5V_CPU VCC_5V_CPU VCC_5V_CPU VCC_5V_CPU VCC_5V_CPU VCC_5V_CPU VCC_5V_CPU VCC_5V_CPU VCC_5V_CPU VCC_5V_CPU VCC_5V_CPU VCC_5V_CPU Note *: Denotes Optional features, not supported in default configuration. Rev 1.0 iWave Systems Technologies Pvt. Ltd. Page 18 of 69...
-
Page 19: Sd/Mmc Card Slot
SDIO cards (Wi-Fi, BT, etc) designed to fit in a standard SD card slot. SD/MMC slot is physically located on top of the board. Figure 3: SD/MMC Card Slot Rev 1.0 iWave Systems Technologies Pvt. Ltd. Page 19 of 69... -
Page 20: Debug Connectors
UART Transmit signal into RS232 signals at the driver section and convert the RS232 receive signals into CMOS signals at the Receiver section. This RS232 signals will be connected to 9-Pin Rev 1.0 iWave Systems Technologies Pvt. Ltd. Page 20 of 69... -
Page 21: Figure 6: Uart (Db9) Connector
Generic Q7 Carrier Card Hardware User Guide D-Sub Debug UART Connector which is physically located on top of the board for external debug access. Figure 6: UART (DB9) Connector Rev 1.0 iWave Systems Technologies Pvt. Ltd. Page 21 of 69... -
Page 22: Jtag Connector
A 10-pin JTAG connector is provided on the Q7 Generic Carrier Card. Logic signals to the JTAG connector are depends on the Qseven CPU manufactures. JTAG connector is physically located on bottom of the board. Rev 1.0 iWave Systems Technologies Pvt. Ltd. Page 22 of 69... -
Page 23: Figure 8: Jtag Connector
Supply Voltage MFG4_JTAG_TRST# Test Reset Signal MFG0_JTAG_TCK Test Clock MFG2_JTAG_TDI Test Data Input MFG1_JATG_TDO Test Data Output MFG3_JTAG_TMS Test Mode Select Supply Voltage Ground Figure 9: JTAG Connector Pin Out Rev 1.0 iWave Systems Technologies Pvt. Ltd. Page 23 of 69... -
Page 24: Gigabit Ethernet & Usb Host0 & 2 Interface
ETH_TXP_GBE_MDI1+ Media Dependent Interface (MDI) differential pair 1 ETH_TXN_GBE_MDI1- Ref Voltage(VCC_3V3) GBE_MDI2+ Media Dependent Interface (MDI) differential pair 2 GBE_MDI2- GBE_MDI3+ Media Dependent Interface (MDI) differential pair 3 GBE_MDI3- Rev 1.0 iWave Systems Technologies Pvt. Ltd. Page 24 of 69... -
Page 25: Usb Host4
Figure 11: RJ45 Magjack with Dual USB Type-A Connector Pin Out USB Host4 USB Host4 signals from the MXM connector is connected to standard USB Type-A connector. USB Host4 connector is physically located on top of the board. Rev 1.0 iWave Systems Technologies Pvt. Ltd. Page 25 of 69... -
Page 26: Usb Otg
(J22) option is provided for USB-ID pin, either proper Host and Device cable can be used or Jumper can be used to configure the port. USB1 OTG connector is physically located on top of the board. Rev 1.0 iWave Systems Technologies Pvt. Ltd. Page 26 of 69... -
Page 27: Figure 14: Usb1 Otg Connector
USB1 Data negative USB_P1HC+ USB1 Data Positive USB ID USD ID signal Open(float): Device Ground USB1 Ground S1,S2,S3,S4 Shield Ground Shield Ground Figure 15: USB1 OTG Connector Pin Out Rev 1.0 iWave Systems Technologies Pvt. Ltd. Page 27 of 69... -
Page 28: Sata0 Interface
Serial ATA channel0, Transmit Output differential pair. SATA0_RX+ Ground P1,P2,P3 VCC_3V3 3.3V Power Supply(1000mA) P4,P5,P6 Ground P7,P8,P9 VCC_5V 5V Power Supply(1000mA) P10,P11,P12 GND Ground P13,P14,P15 VCC_12V 12V Power Supply(350mA) Rev 1.0 iWave Systems Technologies Pvt. Ltd. Page 28 of 69... -
Page 29: Sata1 Intrafce
Figure 18: SATA1 7pin Connector Pin No Pin Details Description Ground SATA1_TX+ Serial ATA channel1, Receive Input differential pair. SATA1_TX Ground SATA1_RX Serial ATA channel1, Transmit Output differential pair. SATA1_RX+ Rev 1.0 iWave Systems Technologies Pvt. Ltd. Page 29 of 69... -
Page 30: Can0 Interface
CAN_SHLD_GND CAN Shield Ground Ground CAN0H CAN Differential High Side No Connection VCC_12V 12V Power supply M1,M2, DSUB_SHLD_GND Shield Ground M3,M4 Figure 21: CAN 9-pin D-Sub Connector Pin Out Rev 1.0 iWave Systems Technologies Pvt. Ltd. Page 30 of 69... -
Page 31: Hdmi Interface
TMDS_LANE1+ Display GREEN+ differential signal D1_GND Green Pair Ground TMDS_LANE1- Display GREEN- differential signal TMDS_LANE0+ Display BLUE+ differential signal D0_GND Blue Pair Ground TMDS_LANE0- Display BLUE- differential signal Rev 1.0 iWave Systems Technologies Pvt. Ltd. Page 31 of 69... -
Page 32: Ac'97 Interface
Audio In and Out jacks both are physically located on top of the board. ALC5610 accepts the following inputs: Line input, Microphone input with MIC bias and Digital AC’97 input. ALC5610 supports the following outputs: Line output, Headphone output, Digital AC’97 output. Rev 1.0 iWave Systems Technologies Pvt. Ltd. Page 32 of 69... -
Page 33: Figure 24: Audio Jack
Generic Q7 Carrier Card Hardware User Guide Figure 24: Audio Jack Pin.NO Pin Detail Description Ground HP_L Headphone Left HP_R Headphone Right HP_DETECT Head Phone Detection No Connection Figure 25: Audio OUT Jack Pin Out Rev 1.0 iWave Systems Technologies Pvt. Ltd. Page 33 of 69... -
Page 34: Pcie0 Interface
2.13 PCIe0 Interface PCIe port0 signals from MXM connector are connected to X1 Slot PCIe connector. PCIe X1 slot physically located on top of the board. Figure 27: PCIe0 X1 Slot Rev 1.0 iWave Systems Technologies Pvt. Ltd. Page 34 of 69... - Page 35 3V Power Supply No Connection VCC_3V3A 3V Always Power Supply PCIe_WAKE# PCIe Wake signal No Connection Ground PCIE0_TX+ PCIe0 transmit signal differential pair PCIE0_TX Ground TXPCIECLK_OE1 Clock enable signal to PCIe Rev 1.0 iWave Systems Technologies Pvt. Ltd. Page 35 of 69...
-
Page 36: Mini Pcie Slot
USB Host3 signals from the MXM connector is connected to Mini PCIe connector for 3G module interface. Mini PCIe slot is physically located on bottom of the board. Figure 29: Mini PCIe Slot Rev 1.0 iWave Systems Technologies Pvt. Ltd. Page 36 of 69... - Page 37 B_PCIE0_RX+(optio not supported in present nal) configuration Ground Ground 3G_1V5 (optional) Optional 3G supply, not supported in present configuration Ground SMB_CLK System BUS Clock B_PCIE0_TX- not supported in present Rev 1.0 iWave Systems Technologies Pvt. Ltd. Page 37 of 69...
-
Page 38: Figure 30: Mini Pci E Slot Pino
3.3V Power Supply M1,M2, Mechanical Mechanical Support M3,M4, Support M5,M6, M7,M8 Figure 30: Mini PCIe Slot Pin Out Pin.NO Pin Detail Description SIM Power Supply SIM Reset SIM Clock Ground Rev 1.0 iWave Systems Technologies Pvt. Ltd. Page 38 of 69... -
Page 39: Display Lvds Interface
TFT1_VCC_3V3 Supply voltage for TFT TFT1_VCC_3V3 Supply voltage for TFT Ground Ground LVDS_A0- LVDS primary channel differential pair 0. LVDS_A0+ Ground LVDS_A1- LVDS primary channel LVDS_A1+ differential pair 1. Rev 1.0 iWave Systems Technologies Pvt. Ltd. Page 39 of 69... -
Page 40: Figure 33: Lvds0 Connectorp
Pin No Pin Detail Description LED_A0 LED Anode LED_K0 LED Cathode M1,M2 Mechanical Support Mechanical Support Note: Backlight Connector part number: SM02B-BHSS-1-TB Figure 34: LVDS0 Backlight Connector Pin Out Rev 1.0 iWave Systems Technologies Pvt. Ltd. Page 40 of 69... -
Page 41: Figure 35: Lvds1 Connectors
Ground Ground LVDS_B0- LVDS secondary channel differential pair 0. LVDS_B0+ Ground LVDS_B1- LVDS secondary channel differential pair 1. LVDS_B1+ Ground LVDS_B2- LVDS secondary channel differential pair 2. LVDS_B2+ Ground Rev 1.0 iWave Systems Technologies Pvt. Ltd. Page 41 of 69... -
Page 42: Figure 36: Lvds1 Connectorp
Change Current sensing resistor R : R576 to required calculated value to set the output current. Where V = 190mV, I is current required for LCD backlight LEDs. Rev 1.0 iWave Systems Technologies Pvt. Ltd. Page 42 of 69... -
Page 43: Resistive Touch Lcd Interface
Pin Detail Description L_VLED Power Voltage for LED Driver L_VLED Power Voltage for LED Driver LVDS_BLT_CTRL_GP_P PWM for backlight WM_OUT0 GLED1 Ground GLED2 Ground TFT1_VCC_3V3 Supply voltage for TFT Rev 1.0 iWave Systems Technologies Pvt. Ltd. Page 43 of 69... -
Page 44: Figure 39: 7`` Resistive Lcd Connector Pin Out
Red Data 2 (LSB+2) Ground DISP_CLK Display Clock Ground L/R1 Left or Right Scanning Direction U/D1 Up or Down Scanning Direction Figure 39: 7`` Resistive LCD Connector Pin Out Rev 1.0 iWave Systems Technologies Pvt. Ltd. Page 44 of 69... -
Page 45: Capacitive Touch Lcd Interface (Optional)
Figure 41: 7`` Capacitive Touch LCD Connector Pin No Pin Detail Description LED_A0 LED Anode LED_A0 LED Anode LED_K0 LED Cathode LED_K0 LED Cathode Ground Rev 1.0 iWave Systems Technologies Pvt. Ltd. Page 45 of 69... - Page 46 Red Data Input DISP_R4 Red Data Input DISP_R3 Red Data Input DISP_R2 Red Data Input DISP_R1 Red Data Input DISP_R0 Red Data Input (LSB) Ground DISP_CLK Clock input Ground Rev 1.0 iWave Systems Technologies Pvt. Ltd. Page 46 of 69...
-
Page 47: Figure 42: 7`` Capacitive Touch Lcd Connector Pin Out
Figure 42: 7`` Capacitive Touch LCD Connector Pin Out Pin No Pin Detail Description VDD_TOUCH Power Supply Ground Touch Interrupt I2C_CLK I2C Clock I2C_DAT I2C Data Figure 43: Capacitive touch Connector Pin Out Rev 1.0 iWave Systems Technologies Pvt. Ltd. Page 47 of 69... -
Page 48: Sdio Wi-Fi (Optional)
Pin No Pin Detail Description Ground SDIO_DAT1 Data Line (bit1) SDIO_DAT0 Data Line (bit0) Ground SDIO_CLK SDIO Clock Signal VCC_3V3 Power Supply SDIO_CMD SDIO Command Signal SDIO_DAT3 Data Line (bit3) Rev 1.0 iWave Systems Technologies Pvt. Ltd. Page 48 of 69... -
Page 49: Spi Header
2.19 SPI Header The Q7 Generic Carrier Card supports SPI header for external interface, SPI signals are connected to MXM connector. SPI header is physically located on bottom of board. Rev 1.0 iWave Systems Technologies Pvt. Ltd. Page 49 of 69... -
Page 50: Rtc Battery
Figure 47: SPI Connector Pin Out 2.20 RTC Battery The Q7 Generic Carrier Card supports on board 3.3V backup Coin cell battery for RTC. This coin cell battery is connected MXM connector VCC-RTC pin. Rev 1.0 iWave Systems Technologies Pvt. Ltd. Page 50 of 69... -
Page 51: Additional Features From Expansion Connectors
Secondary CAN, Secondary UART, Keypad etc. All additional interfaces are provided through two 80pin expansion connectors and these interfaces are non-standard interfaces from Qseven. Some interfaces are specific to iWave Qseven CPU modules. Please contact iWave for more information and support. -
Page 52: Tv-In Interface
The Q7 Generic Carrier Card supports TV-In interface through 80pin expansion connector. ADC “TVP5150AM1IPBSR” from Texas Instruments is present on Q7 carrier card and connected through processor CMOS camera interfaces. TV-In RCA connector is physically located on top of board. Rev 1.0 iWave Systems Technologies Pvt. Ltd. Page 52 of 69... -
Page 53: Camera Interface
The Q7 Generic Carrier Card supports 8/10bit CMOS Camera Interface through 80pin expansion connectors. External clock for camera is provided using on board Oscillator of frequency 26MHz. 24-pin Camera connector is physically located on bottom of board. Rev 1.0 iWave Systems Technologies Pvt. Ltd. Page 53 of 69... -
Page 54: Figure 52: Camera Connector
0= Reset asserted B_CSI0_VSYNC Vertical Synch B_CAM_PWDN1 Power Down, Active High 1= Power Down mode B_CSI0_HSYNC Horizontal Synch VCC_1V8 Digital Power Supply DOVDD IO Power Supply B_CSI0_D9 Camera Data9 Rev 1.0 iWave Systems Technologies Pvt. Ltd. Page 54 of 69... -
Page 55: Tv-Out Interface (Optional)
This is not standard interface recommended in Qseven, it is additional interface provided by iWave to support TV-Out that is directly available from some processors like i.Mx53X, i.Mx51X. TV-Out connector is physically located on top of board. -
Page 56: Secondary Can (Optional)
Pin No Pin Detail Description Ground CAN1H CAN Differential Pair High Side CAN1L CAN Differential Pair Low Side M1,M2 Mechanical Support Mechanical Support Figure 57: Secondary CAN Connector Pin Out Rev 1.0 iWave Systems Technologies Pvt. Ltd. Page 56 of 69... -
Page 57: Secondary Uart
Figure 58: Secondary UART Connector Pin No Pin Detail Description TXD2 Transmit Line from CPU No Connection RXD2 Receive Line to CPU No Connection Ground Figure 59: Secondary UART Connector Pin Out Rev 1.0 iWave Systems Technologies Pvt. Ltd. Page 57 of 69... -
Page 58: Keypad Interface
KP_ROW1 Keypad Row1 KP_ROW2 Keypad Row2 KP_ROW3 Keypad Row3 Ground Ground KP_COL0 Keypad Column0 KP_COL1 Keypad Column1 KP_COL2 Keypad Column2 KP_COL3 Keypad Column3 Figure 61: Keypad Connector Pin Out Rev 1.0 iWave Systems Technologies Pvt. Ltd. Page 58 of 69... -
Page 59: Expansion Connectors
The Q7 Generic Carrier Card has two 80pin board to board expansion connectors. These two connectors are used to bring the unused pins and features from iWave’s Qseven CPU modules to Q7 Generic Carrier Card. Please note that many pins are muxed, so that not all features are available at the same time and also some features are specific to some CPU modules. - Page 60 W_DISABLE LVDS2_PPEN LS_ADC1_PD LS_ADC1_GLCO ADC1_INTREQ GPIO LS_ADC1_AVID MIC_IN_DETECT GPAI_MCLK GPAI_LRCK GPAI_BCLK GPAI_DATA GPIO HP_DETECT GPIO LVDS_BLEN GPIO TSC_INT# GPIO AC97_IRQOUT GPAO_DATA GPAO_BCLK GPAO_LRCK AO_MCLK UART1_TXD UART1_RTS UART UART1_RXD UART1_CTS Rev 1.0 iWave Systems Technologies Pvt. Ltd. Page 60 of 69...
-
Page 61: Figure 62: Expansion Connector1 Pin Out
GPIO UART2_485DE GPIO UART2_TXD UART CSI1_MCLK CSI1_PCLK CSI1_HSYNC CS1_VCLK CSI1_VSYNC CSI1_DAT0 Camera CSI1_DAT1 CSI1_DAT2 CSI1_DAT3 CSI1_DAT4 CSI1_DAT6 CSI1_DAT7 CSI1_DAT5 GPPIN_17 GPIO GPIN18_CAN1_RXD GPIN19_CAN1_TXD Figure 62: Expansion Connector1 Pin Out Rev 1.0 iWave Systems Technologies Pvt. Ltd. Page 61 of 69... -
Page 62: Table 6: Expansion Connector2 Pin Out
Touch TSC_Y2 TSC_Y1 KP_ROW0 KP_ROW1 KP_ROW2 KP_ROW3 Keypad KP_COL0 KP_COL1 KP_COL2 KP_COL3 GPEM_DA1 GPEM_DA0 GPEM_DA3 GPEM_DA2 GPEM_DA5 GPEM_DA4 GPEM_DA7 GPEM_DA6 EIMF GPEM_DA9 GPEM_DA8 GPEM_DA11 GPEM_DA10 GPEM_DA13 GPEM_DA12 GPEM_DA15 GPEM_DA14 Rev 1.0 iWave Systems Technologies Pvt. Ltd. Page 62 of 69... - Page 63 CSI2_D12 CSI2_D15 CSI2_D14 CSI2_D17 Camera 3V3/2V75 CSI2_D16 CSI2_D18 CSI2_D19 CSI2_HSYNC CSI2_VSYNC CSI2_PIXCLK IOUTF Analog Video Output VGA_TV_RED GPIF_P2 IOUTE Analog Video Output VGA_TV_GRN GPIF_P4 GPIO Analog Video Output IOUTD Rev 1.0 iWave Systems Technologies Pvt. Ltd. Page 63 of 69...
-
Page 64: Figure 63: Expansion Connector2 Pin Out
Qseven module. Note-2: This signals assignments in the expansion connector are specific to iWave Q7 modules and the exact features supported in this expansion connectors will vary based on the Q7 module populated. -
Page 65: Power Supply
(F1). Reverse polarity protection is provided using Schottky diode B560C-13-F (D14) and for over voltage protection Zener diode DFLZ12-7 (D15) is used. The circuit is shown below in Figure. Rev 1.0 iWave Systems Technologies Pvt. Ltd. Page 65 of 69... -
Page 66: Figure 64: Power In Circuit
Generic Q7 Carrier Card Hardware User Guide Figure 64: Power In Circuit Figure 65: Power Jack Pin No Pin Detail Description Positive Terminal Ground Negative Terminal Ground Negative Terminal Figure 66: Power Jack Pin Out Rev 1.0 iWave Systems Technologies Pvt. Ltd. Page 66 of 69... -
Page 67: Mechanical Details
Q7 Generic Carrier PCB for factor is Nano-ITX- 120 × 120 mm (4.7 × 4.7 in), the overall dimensions of the Q7 Generic Carrier PCB is shown in below Figure. Figure 67: Q7 Generic Carrier Card PCB Dimension Rev 1.0 iWave Systems Technologies Pvt. Ltd. Page 67 of 69... -
Page 68: Reference
Rainbow-G15M-Q7 (i.Mx6x Q7 CPU Module): http://www.iwavesystems.com/?q=node/239 Rainbow G12M-Q7 (AM389x Q7 Module): http://www.iwavesystems.com/?q=node/134 Rainbow G8M-Q7 (i.Mx51 Q7 CPU Module): http://www.iwavesystems.com/?q=node/138 Rainbow G6M-Q7 (Atom Q7 Module): http://www.iwavesystems.com/?q=node/133 Rev 1.0 iWave Systems Technologies Pvt. Ltd. Page 68 of 69... -
Page 69: Technical Support
Generic Q7 Carrier Card Hardware User Guide 5. TECHNICAL SUPPORT iWave Systems Technologies Pvt. Ltd. # 7/B, 29 Main, BTM Layout 2 Stage, Bengaluru – 560 076 Phone: +91-80-26683700, 26786245 : +91-80-26685200 Email : mktg@iwavesystems.com Rev 1.0 iWave Systems Technologies Pvt. Ltd.
