  • Page 1 SFP Modules Guide...
  • Page 2 Ross has become well known for the Ross Video Code of Ethics. It guides our interactions and empowers our employees. I hope you enjoy reading it below. If anything at all with your Ross experience does not live up to your expectations be sure to reach out to us at solutions@rossvideo.com.
  • Page 3 Copyright ©2020 Ross Video Limited, Ross®, and any related marks are trademarks or registered trademarks of Ross Video Limited. All other trademarks are the property of their respective companies. PATENTS ISSUED and PENDING. All rights reserved. No part of this publication may be reproduced, stored in a retrieval system, or transmitted in any form or by any means, mechanical, photocopying, recording or otherwise, without the prior written permission of Ross Video.
  • Page 4 If an item becomes defective within the warranty period Ross will repair or replace the defective item, as determined solely by Ross. Warranty repairs will be conducted at Ross, with all shipping FOB Ross dock. If repairs are conducted at the customer site, reasonable out-of-pocket charges will apply.
  • Page 5 To avoid the potential release of those substances into the environment and to diminish the need for the extraction of natural resources, Ross Video encourages you to use the appropriate take-back systems. These systems will reuse or recycle most of the materials from your end-of-life equipment in an environmentally friendly and health conscious manner.

  • Page 7: Table Of Contents

    Contents Introduction Related Publications ............................11 Documentation Conventions ..........................11 Block Diagram Conventions ..........................11 Referenced Guides .............................. 11 Important Instructions ............................11 Contacting Technical Support ..........................11 Getting Started Before You Begin ..............................13 Installation Overview ............................. 13 Configuring the SFP Options Before You Begin ..............................
  • Page 8 Recommended Operating Conditions .........................25 HDMI Input Characteristics ..........................25 Mechanical Specifications ............................25 SFP-ANA-IO Features ..................................27 Simplified Block Diagram .............................27 Functional Overview ..............................28 Receive Channel ..............................28 Transmit Channel ..............................28 Module Installation ..............................28 Technical Specifications ............................28 Absolute Maximum Ratings ..........................28 Recommended Operating Conditions .........................28 Composite Receive Channel Specifications ......................29 Composite Transmit Specifications ........................29 Mechanical Specifications ............................30...
  • Page 9 SFP-HDB-IO-3G Features .................................. 43 Simplified Block Diagram ............................. 43 Module Installation ..............................43 Technical Specifications ............................43 Absolute Maximum Ratings ..........................44 Recommended Operating Conditions ......................... 44 SDI Receive Characteristics ..........................44 SDI Transmit Characteristics ..........................45 Mechanical Features .............................. 45 Physical Channel Position ...........................
  • Page 10 iv • Contents Ultrix SFP Modules Guide (v11.0)

  • Page 11: Introduction

    When the Ultrix router cannot connect to the network, a Message dialog opens to report the connection problem. Contacting Technical Support At Ross Video, we take pride in the quality of our products, but if problems occur, help is as close as the nearest telephone.
  • Page 12 12 • Introduction Ultrix SFP Modules Guide (v11.0)

  • Page 13: Getting Started

    This section provides a general overview of how to install an SFP module into an AUX port on the rear panel of the Ultrix router. Refer to the documentation that accompanied your SFP module for installation details.  Ross Video Ultrix routers support only Ross Video branded SFP modules. SFP modules from other vendors may yield unpredictable results. Before You Begin...
  • Page 14 14 • Getting Started Ultrix SFP Modules Guide (v11.0)

  • Page 15: Configuring The Sfp Options

    Configuring the SFP Options The Ultrix router does not automatically detect when an AUX port is populated with an SFP module. You must manually enable the port and assign an SFP module type using the options in the Frame Configuration interface in DashBoard.
  • Page 16 16 • Configuring the SFP Options Ultrix SFP Modules Guide (v11.0)

  • Page 17: Sfp-Hdm-Out

    SFP-HDM-OUT The SFP-HDM-OUT is an electrical SFP Transmitter module designed to convert SDI signals to an HDMI/DVI output without scaling artifacts. A copy of the reclocked SD/HD/3G-SDI source is loopback to the router. Up to 8 channel of audio are supported and embedded in the HDMI signal. Features •...

  • Page 18: Functional Overview

    Table 4.1 Support Formats Format CEA-861 VIC Code 1280x720p @ 60/59.94Hz 1280x720p @ 50Hz 1920x1080i @ 60/59.94Hz 1920x1080i @ 50Hz HD-SDI 1920x1080p @ 30/29.97Hz 1920x1080p @ 25Hz 1920x1080p @ 24/23.98Hz 1920x1080p @ 60/59.94Hz 3G-SDI 1920x1080p @ 50Hz Functional Overview The SFP-HDM-OUT 3G-SDI to HDMI converter output displays the native resolution without introducing any scaling artifacts.

  • Page 19: Recommended Operating Conditions

    Table 4.2 Absolute Maximum Ratings Parameter Min. Max. Notes Supply Voltage 3.6V Operating Case Temperature -20°C +80°C Measured on the top side of the module in the center Storage Temperature -40°C +85°C Operating Relative Humidity Non-condensing ESD Rating IEC61000-4-2 level 4 Recommended Operating Conditions Table 4.3 Recommended Operating Conditions Parameter...
  • Page 20 20 • SFP-HDM-OUT Ultrix SFP Modules Guide (v11.0)

  • Page 21: Sfp-Hdm-Out-12G

    SFP-HDM-OUT-12G The SFP-HDM-OUT-12G is an HD/3G/6G/12G-SDI to HDMI 2.0 converter, able to transmit one SDI signal via an HDMI Type D connector. Features • SMPTE 2082, SMPTE 2081, SMPTE 424, SMPTE 292, and HDMI 2.0 compliant • Supports video pathological patterns for HD-SDI and 3G-SDI •...

  • Page 22: Recommended Operating Conditions

    Recommended Operating Conditions Table 5.2 Recommended Operating Conditions Parameter Min. Typical Max. Notes Supply Voltage 3.135V 3.3V 3.465V Operating Case Temperature -20°C +85°C Measured on the top side of the module in the center SDI Serial 1483Mbps, ST292 Data Rate 1485Mbps 2967Mbps, ST424...

  • Page 23: Sfp-Hdm-In

    SFP-HDM-IN The SFP-HDM-IN is an electrical SFP Receiver module designed to convert an HDMI input (High Definition Multimedia Interface®) to an SDI format. Up to 4 channels of audio are supported. Features • SMPTE 259M, SMPTE 292M, SMPTE 344M, and SMPTE 424M compliant •...

  • Page 24: Functional Overview

    Table 6.1 Supported Formats HDMI Input Format CEA-861 VIC Code 640 x 480 50/59.94/60/75Hz 720 x 480 50/59.94/60/75Hz 720 x 576 50/59.94/60/75Hz 800 x 600 50/59.94/60/75Hz 1024 x 768 50/59.94/60/75Hz 1152 x 864 50/59.94/60/75Hz Graphic 1280 x 768 50/59.94/60/75Hz 1280 x 800 50/59.94/60/75Hz 1280 x 960 50/59.94/60/75Hz 1280 x 1024 50/59.94/60/75Hz 1366 x 768 50/59.94/60/75Hz...

  • Page 25: Absolute Maximum Ratings

    Absolute Maximum Ratings Exceeding any of these ratings may permanently damage the module. Exposure to absolute maximum rating conditions for extended periods may affect device reliability. Table 6.2 Absolute Maximum Ratings Parameter Min. Max. Notes Supply Voltage 3.6V Operating Case Temperature 0°C +70°C Measured on the top side of...
  • Page 26 26 • SFP-HDM-IN Ultrix SFP Modules Guide (v11.0)

  • Page 27: Sfp-Ana-Io

    SFP-ANA-IO The SFP-ANA-IO is an electrical SFP Encoder/Decoder (Transceiver) module designed to encode/decode video composite signals over 75 coaxial cables via HD-BNCs. On the receive (Rx) channel, the module decodes NTSC\PAL composite input and converts it to an SD-SDI signal. On the transmit (Tx) channel, the module encodes the SD-SDI signal to NTSC\PAL composite.

  • Page 28: Functional Overview

    Functional Overview The SFP-ANA-IO is a Small Form Factor Pluggable (SFP) module with coaxial interface. The HD-BNC connectors are used to interface the module with 75 coaxial cables. Receive Channel The Receive (Rx) channel converts a NTSC/PAL video composite input signal to SD-SDI. The video decoder has a 10bit analog-to-digital video converter (ADC) sampling at 54MHz.

  • Page 29: Composite Receive Channel Specifications

    Composite Receive Channel Specifications Table 7.3 Composite RX Input Specifications Parameter Min. Typical Max. Notes Input Return Loss 25dB Input Voltage Range 270mVp-p 500mVp-p 830mVp-p Cutoff Frequency (3dB) 13MHz Passband Flatness 0.25dB Stopband Cutoff 53MHz Stopband Attenuation 36dB Full-Scale Conversion Range 670mVp-p 830mVp-p 270mVp-p...

  • Page 30: Mechanical Specifications

    Table 7.4 Composite TX (Output) Specifications Parameter Min. Typical Max. Notes Analog Output Delay Resolution 10Bits Luminance Nonlinearity ±0.5% Differential Gain 0.5% NTSC Differential Phase 0.6° NTSC SNR Ratio 58dB Luma ramp 75dB Flat field full bandwidth Mechanical Specifications Note that specifications are subject to change without notice. Mechanical Features Table 7.5 provides a brief list of the SFP-ANA-IO mechanical features.

  • Page 31: Sfp-Madi-Coax

    SFP-MADI-COAX The SFP-MADI-COAX is an electrical SFP Transceiver module designed to transmit and receive MADI signals of 125Mbps over 75 coaxial cables via HD-BNC connectors. Features • AES10-2008 compliant • HD-BNC 75 connectors • Equalizes Belden 1694A cable up to 300m •...

  • Page 32: Recommended Operating Conditions

    Table 8.1 Absolute Maximum Ratings Parameter Min. Max. Notes Supply Voltage 3.6V Operating Case Temperature -40°C +80°C Measured on the top side of the module Storage Temperature -40°C +85°C Operating Relative Humidity Non-condensing ESD Rating Recommended Operating Conditions Table 8.2 Recommended Operating Conditions Parameter Min.

  • Page 33: Mechanical Specifications

    Mechanical Specifications Note that specifications are subject to change without notice. Mechanical Features Table 8.5 provides a brief list of the SFP-MADI-COAX mechanical features. Table 8.5 Technical Specifications — Mechanical Features Parameter Specifications Connector Type HD-BNC (75) Plug Diameter Up to 7.8mm external HD-BNC plug diameter (standard) Mechanical release Simple pull up mechanical release system to disengage the module from its cage...
  • Page 34 34 • SFP-MADI-COAX Ultrix SFP Modules Guide (v11.0)

  • Page 35: Sfp-Fiber-3G,Sfp-Madi-1310Sm

    SFP-FIBER-3G,SFP-MADI-1310SM The SFP-FIBER-3G is an optical transceiver module engineered for exceptional performance in the presence of SDI pathological patterns. The transceiver features best-in-class optical receiver sensitivity for SMPTE 259M, SMPTE 344M, SMPTE 292M and SMPTE 424M serial rates, thus providing superior optical link budget and robustness.

  • Page 36: Optical Performance Specifications

    Table 9.1 Absolute Maximum Ratings Parameter Value Storage Temperature -40°C to 85°C Operating Relative Humidity ±1kV HBM ESD Rating 5%-95% RH Optical Performance Specifications Table 9.2 Optical Performance Specifications — Transmitter Parameter Min. Typical Max. Notes Wavelength 1280nm 1310nm 1340nm Measured at 25°C Spectral Line Width (RMS) 1.5nm...

  • Page 37: Mechanical Specifications

    Mechanical Specifications Note that specifications are subject to change without notice. Physical Channel Position Figure 9.2 SFP Package Outline, Front View — Channel Position Ultrix SFP Modules Guide (v11.0) SFP-FIBER-3G,SFP-MADI-1310SM • 37...
  • Page 38 38 • SFP-FIBER-3G,SFP-MADI-1310SM Ultrix SFP Modules Guide (v11.0)

  • Page 39: Sfp-Fiber-12G

    SFP-FIBER-12G The SFP-FIBER-12G is an optical transceiver module that supports data rates up to 12Gbps for single fiber communications. Features • SMPTE 297-2006 compatible for SD-SDI, HD-SDI, 3G-SDI, 6G-SDI, and 12G-SDI • Compliant with SFP MSA (Small Form-Factor Pluggable Transceiver Multi-Source Agreement) and SFS-8472 •...

  • Page 40: Recommended Operating Environment And Electrical Ratings

    Recommended Operating Environment and Electrical Ratings Table 10.2 Recommended Ratings Parameter Min. Typical Max. Supply Voltage +3.2V +3.3V +3.4V Supply Current 300mA Operating Case Temperature 0°C +70°C Data Rate 270Mbps 11.88Gbps Optical Specifications Table 10.3 Optical Specifications — Transmitter Parameter Min.

  • Page 41: Physical Channel Position

    Table 10.6 Electrical Specifications — Transmitter Parameter Min. Typical Max. Notes Differential Input Voltage 100mV 800mV TX_Disable Normal Operation -0.3V 0.8V Laser Disable 2.0V VCC+0.3V Table 10.7 Electrical Specifications — Receiver Parameter Min. Typical Max. Notes Differential Output Voltage 400mV 900mV Rx_LOS Fault...
  • Page 42 42 • SFP-FIBER-12G Ultrix SFP Modules Guide (v11.0)

  • Page 43: Sfp-Hdb-Io-3G

    SFP-HDB-IO-3G The SFP-HDB-IO-3G is an electrical SFP Transceiver module designed to transmit and receive SDI signals up to 2.97Gbps over 75 coaxial cables over 75 HD-BNC connectors. Cable driver provides two selectable slew rates in order to achieve compliance to SMPTE 424M/SMPTE 292M and SMPTE 259M. Equalizer features DC restoration to compensate for the DC content of SMPTE pathological test patterns.

  • Page 44: Absolute Maximum Ratings

    Absolute Maximum Ratings Exceeding any of these ratings may permanently damage the module. Exposure to absolute maximum rating conditions for extended periods may affect device reliability. Table 11.1 Absolute Maximum Ratings Parameter Min. Max. Notes Supply Voltage 3.6V Operating Case Temperature -40°C +80°C Measured on the top side of the...

  • Page 45: Sdi Transmit Characteristics

    SDI Transmit Characteristics Table 11.4 SDI TX Characteristics Parameter Min. Typical Max. Notes Output Voltage Swing 720mV 800mV 880mV 75 load Output Return Loss 15dB 27dB Bandwidth 0-1.5GHz 10dB 13dB Bandwidth 1.5-3GHz Additive Jitter SD-SDI 15ps p-p HD-SDI 18ps p-p 3G-SDI 20ps p-p Rise/Fall Time...
  • Page 46 46 • SFP-HDB-IO-3G Ultrix SFP Modules Guide (v11.0)

  • Page 47: Sfp-Hdb-Io-12G

    SFP-HDB-IO-12G The SFP-HDB-IO-12G is an electrical SFP Transceiver module designed to transmit and receive one SDI signal up to 11.88Gbps (UHD12) over 75 coaxial cables. Features • SMPTE 2081, SMPTE 2082, SMPTE 424, SMPTE 292, and SMPTE 259 compliant • HD-BNC 75 connectors •...

  • Page 48: Recommended Operating Conditions

    Recommended Operating Conditions Table 12.2 Recommended Operating Conditions Parameter Min. Typical Max. Notes Supply Voltage 3.135 3.465 Operating Case Temperature -40°C +85°C Measured on the top side of the module in the center Serial Data SD-SDI 270Mbps ST259 Rate HD-SDI 1483Mbps, ST292 1485Mbps...

  • Page 49: Sdi Transmit Characteristics

    SDI Transmit Characteristics Table 12.4 SDI TX Characteristics Parameter Min. Typical Max. Notes Output Voltage Swing 720mVp-p 800mVp-p 880mVp-p Output Return 0-1.5Ghz 15dB 16.5dB Loss 1.5-3Ghz 10dB 12.5dB 3-6Ghz 11.5dB 6-12Ghz Rise/Fall Time SD-SDI 390ps 550ps 1500ps (80%-20%) HD-SDI 60ps 270ps 3G-SDI 59ps...

  • Page 50: Physical Channel Position

    Physical Channel Position Figure 12.2 SFP Package Outline, Front View — Channel Position 50 • SFP-HDB-IO-12G Ultrix SFP Modules Guide (v11.0)

  • Page 51: Sfp-Madi-850Mm

    SFP-MADI-850MM The SFP-MADI-850MM is an optical transceiver module designed to transmit and receive electrical and optical serial digital signals as defined in SMPTE 297-2006 and AES10. A highly-reliable 850nm wavelength Vertical Cavity Surface Emitting Laser (VCSEL) is used in the transmitter. The transceivers satisfy Class I Laser Safety requirements in accordance with the U.S.

  • Page 52: Transmitter Performance Characteristics

    Transmitter Performance Characteristics Table 13.2 Transmitter Specifications Parameter Min. Typical Max. Notes Data Rate 0.05Gbps 3Gbps Center Wavelength 830nm 850nm 860nm Spectral Width Average Optical Output Power -8dBm -3dBm Extinction Ratio Relative Intensity Noise 110dB/Hz -118dB/Hz Optical Signal SMPTE 424M 165ps Rise Time 2.97Gbps...

  • Page 53: Mechanical Specifications

    Mechanical Specifications Note that specifications are subject to change without notice. Physical Channel Position Figure 13.2 SFP Package Outline, Front View — Channel Position Ultrix SFP Modules Guide (v11.0) SFP-MADI-850MM • 53...
  • Page 54 54 • SFP-MADI-850MM Ultrix SFP Modules Guide (v11.0)

  • Page 55: Sfp-Madi-1300Mm

    SFP-MADI-1300MM The SFP-MADI-1300MM is a small form-factor pluggable LC transceiver for use with 50/125 and 60/125 multi-mode fiber. The SFP-MADI-1300MM will provide a 1300 nanometer MADI interface to Ross Ultrix routing systems. Features • Industry SFP package • LC duplex connector interface •...

  • Page 56: Transmitter Optical Characteristics

    Transmitter Optical Characteristics Table 14.3 Transmitter Optical Characteristics Parameter Min. Typical Max. Notes Center Wavelength 1270nm 1308nm 1380nm Spectral Width - FWHM 147nm Optical Output 62.5/125µm -20.0dBm -17.0dBm -14.0dBm Power 50/125µm -23.5dBm -20.0dBm -14.0dBm Extinction Ratio 10dB Optical Rise Time (10%-90%) 0.6ns 1.0ns 3.0ns...
