ACOPOWER PS 500 User Manual

Portable
Solar Generator
User Manual
1.Get To Know Your Gear
1
A
2
3
4
5
6
A:
1
Main Power LED Indicator
2
Main Power Button
3
Remaining Power Level LED Indicator
4
Type-C PD Output
5
Wireless Speaker AUX-IN
6
Wireless Speaker Play Control Button
7
LED Light Panel
8
USB QC3.0 Output
9
USB 5V/2.4A Outputs x2
10
LED Light Panel Switch
DC Input Port
11
12 Wireless Speaker Working LED Indicator
13 Wireless Speaker
7
14
8
B
9
10
15
11
16
12
13
17
B:
14
Car Socket
15 DC Outputs x3
16 AC Power Indicator
17 AC Power Outputs x2
18 AC Output Switch
2. Tech Speci cation
462Wh (3.7V/124,800mAh)
Capacity:
515.04Wh (3.7V/139,200mAh)
Battery Type: Lithium-ion Cell
DC Input: DC 19V/4.5A by Adapter
MPPT Solar Input: 14-25V by Solar Panel (Max 120W)
AC Output Power: Rated Output Power: 500W
100-120V~/ 60Hz ( for Generator1 Version)
AC Output:
220-240V~/ 50Hz ( for Generator2 Version)
USB-A Outputs: 5V/2.4A x2
USB-A QC3.0 x1 (5V/3A,9V/2A)
USB-C PD 60W x1
DC Output:
DC 9-12.6V/10A Cigarette Lighter Socket x1
DC 9-12.6V, 5A Max Output x3
LED Lighting Function 5W
Wireless Speaker 10W
Inverter Waveform: Pure Sine Wave
Net Weight: 5.5Kg
Dimension: 290x155x190mm
Warranty: 12 months
3.Charging Your Generator
18
4.Powering on and o
1. Long press the Power Button for 2 seconds until the green LED light
comes on.
2. When not in use, long press the Power Button for 2 seconds until the
green LED light turns off.
Please make sure the green light is on before using.The Solar Generator
will stay on even without any power drawing.Make sure you turn it off
when not in use to prevent the battery from draining.
Option
Option
Total Share 10A Max
