- Page 1 OWNER'S MANUAL REFRIGERATOR Read this owner's manual thoroughly before operating the appliance and keep it handy for reference at all times. ENGLISH www.lg.com MFL70525072 Rev.00_052720 Copyright © 2020 LG Electronics Inc. All Rights Reserved.
-
Page 2: Table Of Contents
Water Dispenser Tank (Non plumbed models only) ......... 28 Using the Folding Shelf ( * ) ..............29 Other Functions ..................29 SMART FUNCTIONS .............30 LG ThinQ Application ................30 Smart Diagnosis ..................31 MAINTENANCE ..............33 Notes for Cleaning ..................33 Cleaning the Condenser Cover .............. -
Page 3: Safety Instructions
SAFETY INSTRUCTIONS The following safety guidelines are intended to prevent unforeseen risks or damage from unsafe or incorrect operation of the appliance. The guidelines are separated into ‘WARNING’ and ‘CAUTION’ as described below. This symbol is displayed to indicate matters and operations that can cause risk. - Page 4 •Do not damage the refrigerant circuit. •Do not use mechanical devices or other means to accelerate the defrosting process. •Keep ventilation openings, in the appliance enclosure or in the built-in structure, clear of obstruction. •Do not use electrical appliances inside the refrigerator. •The refrigerant and insulation blowing gas used in the appliance require special disposal procedures.
- Page 5 •Only qualified service personnel from LG Electronics service centre should disassemble, repair, or modify the appliance. Contact an LG Electronics customer information centre if you move and install the appliance in a different location. •Do not use a hair drier to dry the inside of the appliance or place a candle inside to remove the odours.
- Page 6 •Ensure that the outlet socket is properly grounded, and that the earth pin on the power cord is not damaged or removed from the power plug. For more details on grounding, inquire at an LG Electronics customer information centre. •This appliance is equipped with a power cord having an equipment-grounding conductor and a grounding power plug.
- Page 7 •Do not bend the power cable excessively or place a heavy object on it. •Immediately unplug the power plug and contact an LG Electronics customer information centre if you detect a strange sound, odour, or smoke coming from the appliance.
- Page 8 •If there is a gas leakage (isobutane, propane, natural gas, etc.), do not touch the appliance or power plug and ventilate the area immediately. This appliance uses a refrigerant gas (isobutane, R600a). Although it uses a small amount of the gas, it is still combustible gas.
- Page 9 They may break if exposed to sudden temperature changes. •Do not insert the shelves upside down. The shelves may fall. •To remove frost from the appliance, contact an LG Electronics customer information centre. •Dispose of the ice inside the ice bin in the freezer compartment...
-
Page 10: Installation
INSTALLATION Before Installation Ambient Temperature Dimensions and Clearances • The appliance is designed to operate within a limited range of ambient temperatures, depending on the climate zone. Do not use Ventilation around the refrigerator is important the appliance at a temperature exceeding the to provide efficient operation. -
Page 11: Removing/Assembling The Doors
Removing/Assembling the Remove the connector by pulling it in both directions by pressing down on the hook of Doors the wire harness connector. • When it is necessary to move the appliance through a narrow opening, removing the doors is the recommended procedure. WARNING •... - Page 12 Refitting the Fridge Doors Removing the Freezer Doors Mount the doors in the reverse sequence of Remove the two hinge bolts. their removal once the appliance has been passed through all access doors. NOTE • If the water tube end is damaged, it should be trimmed to ensure it does not leak when refitted.
-
Page 13: Leveling
Leveling Turn the adjustment hinge pin clockwise or counterclockwise using the spanner If the appliance seems unsteady, or the doors To lower the door, turn the adjustment hinge do not close easily, adjust the appliance’s tilt. pin clockwise. To raise the door, turn the adjustment hinge pin counterclockwise. -
Page 14: Connecting The Water Line (Plumbed Models Only)
Connecting the Water Line Adjusting the Height of the Left Fridge Door (Plumbed models Only) If the left door is lower, lift the left door, and turn Water Supply Requirements the hinge bolt using the spanner as in the drawing. A cold water supply with water pressure between 138 kPa and 827 kPa (1.4-8.4 kgf/cm²) is requried to operate the water dispenser. -
Page 15: Assembling The Water Filter
Connecting the Water Tube to the Refit the Water filter cover. Appliance Unscrew the metal threaded collar nut at the back of the appliance and place it over one end of the water tube. Firmly push the water tube onto the water inlet valve and tighten up the collar nut. -
Page 16: Connecting The Appliance
Connecting the Appliance After installing the apopliance connect the power plug into a socket outlet. NOTE • After connecting the power supply cord (or plug) to the outlet, wait 2 or 3 hours before you put food into the appliance. If you add food before the appliance has cooled completely, your food may spoil. -
Page 17: Operation
OPERATION Parts and Functions Exterior Control Panel Sets the fridge and freezer temperatures, the water filter condition and the dispenser mode. Filtered Water and Ice Dispenser Dispenses purified water and ice. Door-in-Door ( * ) The Door-in-Door is a double layered door system. It can be opened individually or together with the main door. - Page 18 Interior...
- Page 19 Automatic Icemaker ( * ) This is where ice is automatically produced and stored. LED Lamp The LED lamps inside the appliance light up when you open the door. NOTE When the freezer door is opened, the LED lamp on the bottom of the fridge door lights up. Pure N Fresh This function reduces and removes odors inside the fridge compartment.
- Page 20 Smart Diagnosis Unit Use this function when contacting LG Electronics customer information centre to help make an accurate diagnosis when the appliance operates abnormally or a failure occurs. Door-in-Door ( * ) A convenient storage area for frequently-used items that require easy access.
-
Page 21: Notes For Operation
Notes for Operation Suggestion for Energy Saving • Ensure there is sufficient space between • Users should keep in mind that frost can form. stored foods. This allows cold air to be If the door is not closed completely, if the circulated evenly and lowers electricity bills. - Page 22 Storing Foods Effectively Max Freezing Capacity • Store frozen food or refrigerated food inside • The Express Freeze function will set the sealed containers. It is normal for freezer to its maximum freezing capacity. condensation or frost to form inside sealed •...
-
Page 23: Using Control Panel
Using Control Panel Units and Functions Express Frz. (Express Freeze) * Lock • This locks the buttons on the control • This sets Express Freeze functions. panel. * Wi-Fi Water Filter (*) • This sets the refrigerator to connect to your home’s Wi-Fi network. -
Page 24: Water And Ice Dispenser
Setting the Temperature Setting and Resetting Lock This sets the fridge temperature or freezer This locks the buttons on the control panel. temperature. • When you press the Lock button for 3 • Press the Fridge button or Freezer button to seconds, the Lock/Unlock icon on the control adjust the temperature. -
Page 25: Automatic Icemaker
Automatic Icemaker CAUTION • Keep children away from the dispenser to The automatic icemaker can automatically make prevent children playing with or damaging the 10 cubes at a time, over 100 pieces within a controls. 24hr period but only if conditions are favorable. •... -
Page 26: Detaching The In-Door Ice Bin
To remove the in-door ice bin, grip the front source. If the problem continues, contact the handle, lift up slightly while holding both the LG Electronics customer information centre. top and bottom parts (1), and slowly pull out Do not use the ice or water until the problem the bin as shown (2). -
Page 27: Folding Door Mullion
Removing the Case from the Door Folding Door Mullion in Door This door mullion prevents cold air from leaking from the appliance. Hold the case from inside the door in door with both hands and remove it by lifting it upward. CAUTION •... -
Page 28: Water Dispenser Tank (Non Plumbed Models Only)
Open the cover or cap of the water dispenser Knock twice on the glass to turn the LED tank. light inside the Door-in-Door on or off. The LED light turns off automatically after ten seconds. • The InstaView Door-in-Door function is disabled when the right refrigerator door and the left freezer door are open, for two seconds after closing the door, and when the ice... -
Page 29: Using The Folding Shelf ( * )
LG Electronics customer information center and report the error code. If you turn off the Using the Folding Shelf ( * ) power, the repair technician from the LG Electronics customer information centre may Store taller items, such as a gallon container or have difficulty finding the problem. -
Page 30: Smart Functions
Internet service provider or refer to your wireless router manual. NOTE • LG ThinQ is not responsible for any network • If you change your wireless router, Internet connection problems or any faults, malfunctions, service provider, or password, delete the or errors caused by network connection. -
Page 31: Smart Diagnosis
Initial Appliance Registration Smart Diagnosis • Run the LG ThinQ application and follow the instructions in the application to register the This feature is only available on models with the appliance. - Page 32 LG ThinQ diagnosis will be displayed in the application. application. • Launch the LG ThinQ application and select the NOTE Smart Diagnosis feature in the menu. Follow • For best results, do not move the phone while the instructions provided in the LG ThinQ the tones are being transmitted.
-
Page 33: Maintenance
Please, • Detach the shelves and drawers and clean contact the LG Electronics customer information centre. them with water, and then dry them sufficiently, before replacing them. -
Page 34: Cleaning The Water Dispenser
Cleaning the Water Dispenser Pull the shelf out tilted at an angle. Cleaning the Dispenser Tray The dispenser tray may become wet easily due to spilled ice or water. Wipe the entire area with a damp cloth. Refitting the Fridge Shelf Refit the Shelf in the reverse sequence of their removal. -
Page 35: Cleaning The Vegetable Drawer
Refitting the Folding Shelf Remove the contents of the drawer. Hold the handle of the drawer and gently pull it Tilt the back of the shelf up and guide the rear out completely until it stops. Repeat to shelf hooks into the slots. Then, lower the back remove the second drawer. -
Page 36: Cleaning The Door-In-Door Compartment
Cleaning the Door-in-Door Refitting the Door-in-Door Compartment Compartment Mount them in the reverse order of the removal Removing the Door-in-Door process. Compartment Cleaning the Freezer Drawer Lift the case from Door-in-Door up and take it out with both hands. The sliding freezer drawers allow easy access and convenience of use. -
Page 37: Replacing The Pure N Fresh Filter
Replacing the Pure N Fresh CAUTION Filter • The drawers are heavy. Always use two hands when removing or assembling the drawers to To maintain the performance of the Pure N avoid product damage or personal injury. Fresh filter, if a message indicating the filter •... -
Page 38: Replacing The Water Filter (Plumbed Models Only)
• When setting the appliance to On or Power mode after replacing the filter, check if the LED lamp near the filter is on. • The filter can be purchased from an LG Electronics customer information centre. Replacing the Water Filter... - Page 39 Remove the disposable water filter. Replace with a new water filter. Insert the new filter into the filter head and rotate it clockwise until the arrow on the new filter lines up with the arrow on the filter head. Swing the filter back into the compartment. Refit the Water filter cover.
-
Page 40: Troubleshooting
If the inside lamp does not turn on, please contact the does not turn LG Electronics customer information centre. Is the appliance leaning forward? • Adjust the front feet to raise the front side slightly. - Page 41 Symptoms Possible Causes & Solution Did you open the door right after you closed it? It is difficult to • If you try to open the appliance door within one minute after you closed it, open the you may have difficulties because of the pressure inside the appliance. Try to appliance door.
- Page 42 Symptoms Possible Causes & Solution Did you open and close the appliance door frequently or is the appliance door improperly closed? Frost or • Frost or condensation can form if the outside air penetrates inside the condensation appliance. has formed Is the installation environment humid? inside or outside •...
- Page 43 (For more details on how to use, visit small amount of LG electronics website or use your smart device.) ice. Is the temperature of the freezer compartment set too high? • If the set temperature is too warm, ice will be produced slowly or not at all.
- Page 44 Symptoms Possible Causes & Solution Unable to hear the sound of ice coming out? • In the control panel, select the modes for cubed ice and crushed ice alternately to dispense the ice. Ice is not Is the ice path blocked? (You can check the ice passage by separating dispensed.
- Page 45 Symptoms Possible Causes & Solution The defrost control will click when the automatic defrost cycle begins and ends. The thermostat control (or appliance control on some models) Clicking noises will also click when cycling on and off. • Normal Operation Rattling noises may come from the flow of appliance, the water line on the back of the unit (for plumbed models only), or items stored on top of or around the appliance.
- Page 46 The password for the Wi-Fi that you are trying to connect to is incorrect. • Find the Wi-Fi network connected to your smartphone and remove it, then register your appliance on LG ThinQ. Mobile data for your smartphone is turned on.
- Page 47 Memo...
