LABTEC ECO static User Manual page 15

A 4 Testing of gas-tight chemical protective suits (CPS)
7 Tightness
7.1 Tightness of the suit
8 Valves
8.1 Tightness of the suit valves after # min. at - # mbar
(repeat the test depending on the number of valves)
Step Activity
Close the high-pressure device connection with
7.1.1
a plug.
Connect one tightening valve with test adapter,
7.1.2
seal all other tightening valves with plugs.
Couple the filling hose of the test adapter with
7.1.3
plug nipple of CPS test connector.
Insert the measuring hose of the test adapter
7.1.4
into the mouth of the test head.
Open high pressure main valve with main valve
7.1.5
switch.
7.1.6 Fill CPS by pressing the CPS inflation switch
Durch erneutes Drücken des Schalters CSA
7.1.7
füllen das Befüllen des Anzugs stoppen.
Press the CPS inflation switch again to stop fil-
7.1.8
ling the suit.
When time has elapsed, set the required test
7.1.9 pressure with the CPS inflation or CPS deflation
switches and start the stopwatch.
After a preset time of # min, read the low pres-
7.1.10 sure on the display (LP) and compare with the
previously set test pressure.
Close high pressure main valve with main valve
7.1.11
switch.
7.1.12 Completely vent the test device.
Insert the measuring hose of the test adapter
8.1.1
into the mouth of the test head.
Connect tightening valve with valve test adapter
8.1.2
from inside
Set test vacuum with negative pressure button to
8.1.3
setpoint value - # mbar. Switch on stop watch.
After a preset time of # min. pressure change
8.1.4 read off the display (LP) and compare with set-
point.
8.1.5 Completely vent the test device.
User Manual Labtec ECO
Comment
Device connection must be closed
during tightness test.
CPS test adapter CGA 200 and brand
-specific adapters
CPS test adapter CGA 200
CPS test adapter CGA 200
High pressure flows into the unit and
is present in the unit.
CPS is filled to +# mbar
when the required tightening internal
pressure is reached.
Setting the required settling time.
Compare difference value with per-
missible deviation.
Open the suit
CPS test adapter CGA 200
manufacturer-dependent adapter,
depending on the number of
existing valves.
Adjust the test pressure with the low
pressure relief button if necessary.
page 15
operating
elements
www.labtec.de
