Labtec User Manual Labtec ECO static / dynamic Content Page foreword safety instructions device description technical data component description operating elements commissioning care and maintenance User Manual Labtec ECO page 1 www.labtec.de... -
Page 2: Foreword
This operating manual describes the operati- 400bar. Operating a device under high pres- on of the Labtec ECO series of test instru- sure requires the greatest care. Before ments. connecting and disconnecting a test item /... -
Page 3: Device Description
USB cable. Adapters for the connection of CPS, regula- Compared to Labtec ECO dynamic, Labtec tors and sealing caps for respirators must be ECO static test devices have no artificial ordered separately depending lung and are therefore only suitable for static connection used (e.g. -
Page 4: Technical Data
450 IP rating IP 54 permissible temperature range °C -10...+55 measuring volume dimensions W X L x H 500 x 630 x 540 41 (ECO dynamic) total weight 39 (ECO static) User Manual Labtec ECO page 4 www.labtec.de... -
Page 5: Component Description
C14 plug. The Labtec ECO dynamic model has a se- cond measuring point in the forehead area of USB-Interface (J) the head. This can be queried via the soft- The USB port for data transfer to a PC is lo- ware. -
Page 6: Operating Elements
Switch button for Artifical Lung (only active with ECO dyanmic, main valve has to be open) When pressed, the artificial lung is switched on and ventilated through the mouth opening of the test head. Pressing button again switches it off. User Manual Labtec ECO page 6 www.labtec.de... -
Page 7: Commissioning
> See separate test head care instructions Device connection (breathing mask) The test device must be serviced at least an- nually by a certified Labtec service technician. The test head must be completely vented. The breathing connection of the mask is closed The test device is recalibrated and deviations with a suitable sealing cap. - Page 8 DIN EN 837 Ausgabe / dates / en date du 1997 Diese Konformitätsbescheinigung wurde automatisch erstellt und ist ohne Unterschrift gültig. Datum / date This calibration certificate was produced automatically 01.01.2020 and is valid without signature. User Manual Labtec ECO page 8 www.labtec.de...
- Page 9 Switch off the pump by pressing the 10/lmin 1.3.5 Exhalation switch again. Deflate the test head with button for test head 1.3.6 deflation. Remove mask from test head. User Manual Labtec ECO page 9 www.labtec.de...
- Page 10 Completely vent the test device. All further tests require high pressure! Check correct device connection! The Labtec test bench + connected test device parts must be completely vented before connecting or removing test devices. Connect demand valve in combination with a Check correct device connection! SCBA base unit to the test device.
- Page 11 Read the low pressure on the display (LP). during the inhalation 2.5.5 Stop breathing with switch for artificial lung Close high pressure main valve with main valve 2.5.6 switch. 2.5.7 Completely vent the test device. User Manual Labtec ECO page 11 www.labtec.de...
- Page 12 (fast) or medium pressure relief (slower) 4.1.4 until an acoustic signal (warning whistle) beco- mes audible. Read the response pressure on the display (HP) 4.1.5 and compare with setpoint. 4.1.6 Completely vent the test device. User Manual Labtec ECO page 12 www.labtec.de...
- Page 13 After a preset time of # min, read the medium Compare difference value with per- 5.2.5 pressure again and compare it with the previous- missible deviation. ly measured value. 5.2.6 Completely vent the test device. User Manual Labtec ECO page 13 www.labtec.de...
- Page 14 After a preset time of # min, read the high pres- Compare difference value with per- 6.1.4 sure again and compare it with the previously missible deviation. measured value. 6.1.5 Completely vent the test device. User Manual Labtec ECO page 14 www.labtec.de...
- Page 15 - # mbar. Switch on stop watch. pressure relief button if necessary. After a preset time of # min. pressure change 8.1.4 read off the display (LP) and compare with set- point. 8.1.5 Completely vent the test device. User Manual Labtec ECO page 15 www.labtec.de...
