- Page 1 Manx-camera ENG-2019-UMN005-R003 Company confidential. This document is the property of Xenics. It may not be reproduced – completely or partially – or passed to a third party without written permission from Xenics. Xenics nv T +32 16 38 99 00...
- Page 2 Company confidential. This document is the property of Xenics. It may not be reproduced – completely or partially – or passed to a third party without written permission from Xenics.
-
Page 3: Revision History
Changes Modified by Company confidential. This document is the property of Xenics. It may not be reproduced – completely or partially – or passed to a third party without written permission from Xenics. Xenics nv T +32 16 38 99 00... -
Page 4: Table Of Contents
Image processing ....................32 Camera non-volatile memory ................37 Company confidential. This document is the property of Xenics. It may not be reproduced – completely or partially – or passed to a third party without written permission from Xenics. Xenics nv... - Page 5 Appendix D - Firmware and XML upgrade ............63 Appendix E - Register Description............... 66 Company confidential. This document is the property of Xenics. It may not be reproduced – completely or partially – or passed to a third party without written permission from Xenics. Xenics nv...
-
Page 6: List Of Figures
Figure 6-2 Windows start menu with Euresys Genicam Browser installed ......41 Company confidential. This document is the property of Xenics. It may not be reproduced – completely or partially – or passed to a third party without written permission from Xenics. - Page 7 Figure 6-39 XML uploading in process ................65 Company confidential. This document is the property of Xenics. It may not be reproduced – completely or partially – or passed to a third party without written permission from Xenics. Xenics nv...
-
Page 8: List Of Tables
Table 6-15 User set control registers................73 Table 6-16 User set enumeration ..................73 Company confidential. This document is the property of Xenics. It may not be reproduced – completely or partially – or passed to a third party without written permission from Xenics. Xenics nv... -
Page 9: Introduction
Manx frame rate calculator Table 1-2 List of reference documents Company confidential. This document is the property of Xenics. It may not be reproduced – completely or partially – or passed to a third party without written permission from Xenics. Xenics nv... -
Page 10: Manual Overview
Warranty: The warranty becomes void in case of unauthorized tampering or any manipulations not approved by the manufacturer. Company confidential. This document is the property of Xenics. It may not be reproduced – completely or partially – or passed to a third party without written permission from Xenics. Xenics nv... -
Page 11: Contact Information
Please visit our website for more contact details: www.xenics.com Company confidential. This document is the property of Xenics. It may not be reproduced – completely or partially – or passed to a third party without written permission from Xenics. Xenics nv... -
Page 12: Getting Started
After installing the SDK, the SDK manual, together with the samples and header files can be found in the C:\Program Files\Xeneth\SDK directory. Company confidential. This document is the property of Xenics. It may not be reproduced – completely or partially – or passed to a third party without written permission from Xenics. Xenics nv... -
Page 13: Connect The Camera Via Xeneth
Non-uniformity correction. Figure 2-1 Connect camera to Xeneth Company confidential. This document is the property of Xenics. It may not be reproduced – completely or partially – or passed to a third party without written permission from Xenics. Xenics nv... -
Page 14: Acquiring The First Images
• Current time indicator Company confidential. This document is the property of Xenics. It may not be reproduced – completely or partially – or passed to a third party without written permission from Xenics. Xenics nv T +32 16 38 99 00... -
Page 15: Mechanical Overview
Figure 3-1 2D CAD of Manx – Tolerance ISO 2768 - f H Company confidential. This document is the property of Xenics. It may not be reproduced – completely or partially – or passed to a third party without written permission from Xenics. -
Page 16: Optical Position
Power supply – (GND) white Company confidential. This document is the property of Xenics. It may not be reproduced – completely or partially – or passed to a third party without written permission from Xenics. Xenics nv T +32 16 38 99 00... -
Page 17: Coaxpress Interface
It is also possible to right click on the function name and display the property documentation, which provide the details of each function. Company confidential. This document is the property of Xenics. It may not be reproduced – completely or partially – or passed to a third party without written permission from Xenics. Xenics nv... -
Page 18: Image Acquisition
Based on Equation 1, it is better to use the camera with lower gain factor, if there is a huge influx of incoming signal. Company confidential. This document is the property of Xenics. It may not be reproduced – completely or partially – or passed to a third party without written permission from Xenics. Xenics nv... -
Page 19: Figure 5-3 Exposure Time Setting On Xeneth
When the exposure time is more than acquisition line time, the actual line time equals to the exposure time Company confidential. This document is the property of Xenics. It may not be reproduced – completely or partially – or passed to a third party without written permission from Xenics. Xenics nv... -
Page 20: Figure 5-5 Acquisition Frame Time Setting On Xeneth
Company confidential. This document is the property of Xenics. It may not be reproduced – completely or partially – or passed to a third party without written permission from Xenics. -
Page 21: Figure 5-6 Acquisition Control Settings On Xeneth
A footer can be embedded into the last line of the frame. Company confidential. This document is the property of Xenics. It may not be reproduced – completely or partially – or passed to a third party without written permission from Xenics. -
Page 22: Figure 5-8 Footer Settings On Xeneth
Do not use Not used, value = 0 Company confidential. This document is the property of Xenics. It may not be reproduced – completely or partially – or passed to a third party without written permission from Xenics. Xenics nv... -
Page 23: Tec Control
Maintain sensor temperature below 50C to avoid risk of damaging the camera! Company confidential. This document is the property of Xenics. It may not be reproduced – completely or partially – or passed to a third party without written permission from Xenics. Xenics nv... -
Page 24: Triggering
This is illustrated in Figure 5-12. Company confidential. This document is the property of Xenics. It may not be reproduced – completely or partially – or passed to a third party without written permission from Xenics. -
Page 25: Figure 5-12 Free Running Internal Trigger
Figure 5-13 Trigger period longer than line(frame) period Company confidential. This document is the property of Xenics. It may not be reproduced – completely or partially – or passed to a third party without written permission from Xenics. Xenics nv... -
Page 26: Figure 5-14 Trigger Period Is Shorter Than Line(Frame) Period
R = 4.7k Table 5-6 Trigger in voltages Company confidential. This document is the property of Xenics. It may not be reproduced – completely or partially – or passed to a third party without written permission from Xenics. Xenics nv... -
Page 27: Table 5-7 Trigger In Source Configurations
Skipping of triggers and trigger in delay can be adjusted. This is how it is shown on Xeneth user interface. Company confidential. This document is the property of Xenics. It may not be reproduced – completely or partially – or passed to a third party without written permission from Xenics. Xenics nv... -
Page 28: Figure 5-15 Trigger In Settings As Shown On Xeneth
Table 5-9 Multiple lines(frames) per trigger Company confidential. This document is the property of Xenics. It may not be reproduced – completely or partially – or passed to a third party without written permission from Xenics. Xenics nv... -
Page 29: Figure 5-17 Multiple Lines(Frames) Per Trigger Setting On Xeneth
Refer to Appendix D - Firmware and XML upgrade for a graphic representation of the trigger in configurations. Company confidential. This document is the property of Xenics. It may not be reproduced – completely or partially – or passed to a third party without written permission from Xenics. Xenics nv... -
Page 30: Table 5-10 Digital Output (Trigger Output) Mode
It is possible to set both outputs with the same trigger out source. Company confidential. This document is the property of Xenics. It may not be reproduced – completely or partially – or passed to a third party without written permission from Xenics. -
Page 31: Figure 5-18 Trigger Out Pulse At Start Of Frame And Line
Figure 5-19 Digital output (trigger output) settings on Xeneth Company confidential. This document is the property of Xenics. It may not be reproduced – completely or partially – or passed to a third party without written permission from Xenics. Xenics nv... -
Page 32: Image Processing
Gain20_50us_<camera SN> Gain20_100us_<camera SN> Company confidential. This document is the property of Xenics. It may not be reproduced – completely or partially – or passed to a third party without written permission from Xenics. Xenics nv T +32 16 38 99 00... -
Page 33: Figure 5-21 Select Software Calibration File
Figure 5-21 Select software calibration file Company confidential. This document is the property of Xenics. It may not be reproduced – completely or partially – or passed to a third party without written permission from Xenics. Xenics nv... -
Page 34: Figure 5-22 Typical Corrected Image With Uniform Lightings
Figure 5-22 Typical corrected image with uniform lightings A typical raw image looks like this. Company confidential. This document is the property of Xenics. It may not be reproduced – completely or partially – or passed to a third party without written permission from Xenics. Xenics nv... -
Page 35: Figure 5-23 Typical Raw Image With Uniform Lighting
Slot 2 X20_25us Company confidential. This document is the property of Xenics. It may not be reproduced – completely or partially – or passed to a third party without written permission from Xenics. Xenics nv T +32 16 38 99 00... -
Page 36: Figure 5-25 Enable Onboard Calibration
Source = Slot n (based on the above table) Figure 5-25 Enable onboard calibration Company confidential. This document is the property of Xenics. It may not be reproduced – completely or partially – or passed to a third party without written permission from Xenics. Xenics nv... -
Page 37: Camera Non-Volatile Memory
Upload the file into the camera memory using the function shown below. Figure 5-28 Upload calibration file Company confidential. This document is the property of Xenics. It may not be reproduced – completely or partially – or passed to a third party without written permission from Xenics. Xenics nv... -
Page 38: Figure 5-29 Saving User Set Settings
Figure 5-29 Saving user set settings To clear the slot, simply execute “Clear”. Company confidential. This document is the property of Xenics. It may not be reproduced – completely or partially – or passed to a third party without written permission from Xenics. Xenics nv... -
Page 39: Figure 5-30 Clearing Existing User Set Settings
Do a power cycle and connect to the camera and select “Calibration data: (Camera memory)”. Company confidential. This document is the property of Xenics. It may not be reproduced – completely or partially – or passed to a third party without written permission from Xenics. Xenics nv... -
Page 40: Figure 5-32 Starting Up A Camera With User Set Default Settings
Figure 5-33 User set default setting in used Company confidential. This document is the property of Xenics. It may not be reproduced – completely or partially – or passed to a third party without written permission from Xenics. Xenics nv... -
Page 41: Appendix
Figure 6-2 Windows start menu with Euresys Genicam Browser installed Company confidential. This document is the property of Xenics. It may not be reproduced – completely or partially – or passed to a third party without written permission from Xenics. -
Page 42: Figure 6-3 Gen3 Pice X4 Slot On The Motherboard
Figure 6-5 CoaXpress frame grabber board not ready Company confidential. This document is the property of Xenics. It may not be reproduced – completely or partially – or passed to a third party without written permission from Xenics. Xenics nv... -
Page 43: Figure 6-6 Coaxexpress Frame Grabber Board Detected On Device Manager
Reset the computer. (Might have to shut it down for a few seconds). Company confidential. This document is the property of Xenics. It may not be reproduced – completely or partially – or passed to a third party without written permission from Xenics. -
Page 44: Figure 6-8 Coaxpress Sequence On Manx
Figure 6-10 CoaXpress connection ready Company confidential. This document is the property of Xenics. It may not be reproduced – completely or partially – or passed to a third party without written permission from Xenics. Xenics nv... -
Page 45: Appendix B - Graphical Representation Of Trigger In Configurations
Comment block - Extra information. Event block - Only for external triggers. Company confidential. This document is the property of Xenics. It may not be reproduced – completely or partially – or passed to a third party without written permission from Xenics. Xenics nv... -
Page 46: Figure 6-12 Continuous Acquisition, Line- And Frame Trigger Free Running
Figure 6-12 Continuous acquisition, line- and frame trigger free running Company confidential. This document is the property of Xenics. It may not be reproduced – completely or partially – or passed to a third party without written permission from Xenics. -
Page 47: Figure 6-13 Continuous Acquisition With Frame Trigger External And Line Trigger Free Running
Figure 6-13 Continuous acquisition with frame trigger external and line trigger free running Company confidential. This document is the property of Xenics. It may not be reproduced – completely or partially – or passed to a third party without written permission from Xenics. -
Page 48: Figure 6-14 Continuous Acquisition With Frame Trigger Free Running And Line Trigger External
Figure 6-14 Continuous acquisition with frame trigger free running and line trigger external with burst count 2 Company confidential. This document is the property of Xenics. It may not be reproduced – completely or partially – or passed to a third party without written permission from Xenics. -
Page 49: Figure 6-15 Continuous Acquisition With Line And Frame Trigger External
Figure 6-15 Continuous acquisition with line and frame trigger external Company confidential. This document is the property of Xenics. It may not be reproduced – completely or partially – or passed to a third party without written permission from Xenics. -
Page 50: Figure 6-16 Continuous Acquisition With Multi Frame Trigger
Figure 6-16 Continuous acquisition with multi frame trigger Company confidential. This document is the property of Xenics. It may not be reproduced – completely or partially – or passed to a third party without written permission from Xenics. Xenics nv... -
Page 51: Figure 6-17 Multiframe Acquisition
Figure 6-17 Multiframe acquisition Company confidential. This document is the property of Xenics. It may not be reproduced – completely or partially – or passed to a third party without written permission from Xenics. Xenics nv T +32 16 38 99 00... -
Page 52: Figure 6-18 Multiframe Acquisition With Frame Trigger
Figure 6-18 MultiFrame acquisition with frame trigger Company confidential. This document is the property of Xenics. It may not be reproduced – completely or partially – or passed to a third party without written permission from Xenics. Xenics nv... -
Page 53: Figure 6-19 Multiframe Acquisition With Multi Frame Trigger
Figure 6-19 MultiFrame acquisition with multi frame trigger Company confidential. This document is the property of Xenics. It may not be reproduced – completely or partially – or passed to a third party without written permission from Xenics. Xenics nv... -
Page 54: Appendix C - Non Uniformity Correction (Nuc)
Figure 6-20 Load calibration wizard Select “Two point calibration” and press “Next”. Company confidential. This document is the property of Xenics. It may not be reproduced – completely or partially – or passed to a third party without written permission from Xenics. Xenics nv... -
Page 55: Figure 6-21 Two Point Calibration
We recommend using a threshold of 350% for both FPN and temporal noise. Select “Perform capture and analysis” to proceed. Company confidential. This document is the property of Xenics. It may not be reproduced – completely or partially – or passed to a third party without written permission from Xenics. Xenics nv... -
Page 56: Figure 6-22 Two Point Calibration Dark Offset Analysis
Allow the camera to be illuminated to about 2/3 of the histogram. Company confidential. This document is the property of Xenics. It may not be reproduced – completely or partially – or passed to a third party without written permission from Xenics. -
Page 57: Figure 6-24 2/3 Of Histogram
We recommend using a threshold of 350% for both PRNU and temporal noise. Select “Perform capture and analysis” to proceed. Company confidential. This document is the property of Xenics. It may not be reproduced – completely or partially – or passed to a third party without written permission from Xenics. Xenics nv... -
Page 58: Figure 6-26 Two Point Calibration Flat Field Image Analysis
Refer to Xeneth user manual for more information (Ref 1). Company confidential. This document is the property of Xenics. It may not be reproduced – completely or partially – or passed to a third party without written permission from Xenics. -
Page 59: Figure 6-28 Edit Bad Pixel Map
Manx-camera Figure 6-28 Edit bad pixel map Company confidential. This document is the property of Xenics. It may not be reproduced – completely or partially – or passed to a third party without written permission from Xenics. Xenics nv T +32 16 38 99 00... -
Page 60: Figure 6-29 Disable Software Image Correction
Select “Recalibrate offset”. Press “Next”. Company confidential. This document is the property of Xenics. It may not be reproduced – completely or partially – or passed to a third party without written permission from Xenics. Xenics nv T +32 16 38 99 00... -
Page 61: Figure 6-32 Recalibration Offset
We recommend using a threshold of 350% for both FPN and temporal noise. Select “Perform capture and analysis” to proceed. Company confidential. This document is the property of Xenics. It may not be reproduced – completely or partially – or passed to a third party without written permission from Xenics. Xenics nv... -
Page 62: Figure 6-33 One Point Dark Offset Analysis
Figure 6-34 Selected bad pixel from dark offset analysis Select “Finish” to save the file. Company confidential. This document is the property of Xenics. It may not be reproduced – completely or partially – or passed to a third party without written permission from Xenics. Xenics nv... -
Page 63: Appendix D - Firmware And Xml Upgrade
Go to the settings tab - storage icon as shown by the arrow below. Figure 6-35 Setting tab – Storage icon Company confidential. This document is the property of Xenics. It may not be reproduced – completely or partially – or passed to a third party without written permission from Xenics. Xenics nv... -
Page 64: Figure 6-36 Firmware Upgrade File Selection
Power cycle the camera for the new firmware to take effect. Company confidential. This document is the property of Xenics. It may not be reproduced – completely or partially – or passed to a third party without written permission from Xenics. -
Page 65: Figure 6-38 Xml Upgrade File Seletion
Power cycle the camera for the new XML to take effect. Company confidential. This document is the property of Xenics. It may not be reproduced – completely or partially – or passed to a third party without written permission from Xenics. -
Page 66: Appendix E - Register Description
15..0 for the multi frame mode Company confidential. This document is the property of Xenics. It may not be reproduced – completely or partially – or passed to a third party without written permission from Xenics. Xenics nv T +32 16 38 99 00... - Page 67 FrameTriggerSoftware Software (Manual) frame trigger generation Company confidential. This document is the property of Xenics. It may not be reproduced – completely or partially – or passed to a third party without written permission from Xenics. Xenics nv T +32 16 38 99 00...
-
Page 68: Table 6-9 Acquisition And Trigger Control Registers
Enable/disable correction – processing blocks 31..0 Company confidential. This document is the property of Xenics. It may not be reproduced – completely or partially – or passed to a third party without written permission from Xenics. Xenics nv T +32 16 38 99 00... -
Page 69: Table 6-10 Image Correction And Processing Control Registers
0x01100007 : mono 16-bit “mono16” Table 6-11 Image format control registers Company confidential. This document is the property of Xenics. It may not be reproduced – completely or partially – or passed to a third party without written permission from Xenics. Xenics nv... -
Page 70: Table 6-12 Digital Output Control Registers
Do not use Table 6-12 Digital output control registers Company confidential. This document is the property of Xenics. It may not be reproduced – completely or partially – or passed to a third party without written permission from Xenics. Xenics nv... -
Page 71: Table 6-13 Device Control Registers
4 : 3125 fF (x1) Table 6-13 Device control registers Company confidential. This document is the property of Xenics. It may not be reproduced – completely or partially – or passed to a third party without written permission from Xenics. Xenics nv... -
Page 72: Table 6-14 File Access Control Registers
Table 6-14 File access control registers Company confidential. This document is the property of Xenics. It may not be reproduced – completely or partially – or passed to a third party without written permission from Xenics. Xenics nv T +32 16 38 99 00... -
Page 73: Table 6-15 User Set Control Registers
User set 15 Table 6-16 User set enumeration Company confidential. This document is the property of Xenics. It may not be reproduced – completely or partially – or passed to a third party without written permission from Xenics. Xenics nv...
