- Page 1 BUEN PTIC www.buenoptic.com HFB-FO-LON Series Lonworks Multi-drop BUS Fiber Optic Modem Datasheet & User Manual...
- Page 2 Table of Contents 1. Overview ................3 1.1 Introduction ……………………….……………………………..3 1.2 Technical Specification……………………………...………….3 1.3 Warranty .…………………...……………………….…..……...4 2. Installation ................ 5 2.1 Package Contents ………………………………………..…..5 2.2 Enclosure ................5 2.3 Install Method..............…6 2.4 Install Application .............. …7 3. Dimensions ...............8...
- Page 3 1. Overview 1.1 Introduction The LONWORKS Fiber Optic Modem is a multi-master and high performance Field bus Control System (FCS). Our Fiber Optic Modem uses the fiber cable as its transmission medium and utilizes Optical Fiber modulation/demodulation technology to changes the electric medium into a light medium transmission.
- Page 4 1.3 Warranty n Repair Please contact your local distributors when product is defective. Please apply ¨ RA in advance and prepay shipping cost when returning the defective product to us. We will pay the cost for sending it back to you. Please attach a statement clearly describing the problem.
- Page 5 2 Installation 2.1 Package Contents · OneLonworksFiber Optic Modem · One power supply adaptor · One User Manual Please contact dealer or distributor if part is missing or damaged. Wall Mount Enclosure LED Indicators: Power Supply On if power input is OK. ACT : Profibus Data transmit/receive.
- Page 6 Connectors: Terminal ( 10 pins ) assignment: 24VDC+ Power Ground 24VDC- None None None None GND of LON LONA T(+) LONB R(-)
- Page 7 FTX1: Fiber Optical ST of the secondary channel ( transmit ) FRX1: Fiber Optical ST of the secondary channel ( receive ) FTX2: Fiber Optical ST of the primary channel ( transmit ) FRX2: Fiber Optical ST of the primary channel ( receive ) Caution ·...
- Page 8 2.4 Install Application 3 Dimensions (mm) Wall Mount: 106.1...
