- Page 1 HFD-FO-485-M2S User Manual...
-
Page 2: Table Of Contents
Table of Contents 1. Overview ................3 1.1 Introduction ……………………….……………………………..3 1.2 Technical Specification……………………………...………….3 1.3 Warranty .…………………...……………………….…..……...4 2. Installation ................4 2.1 Package Contents ………………………………………..…..5 2.2 Wall Mount Enclosure ............5 2.3 Caution ................…6 2.4 Install Application ..............…7 3. Dimensions ...............8 Page 2 of 8... -
Page 3: Overview
1. Overview 1.1 Introduction Product Description The RS-485 Multi-Drop Bus Fiber Optic Modem series products provide an optical bus network for RS-485, data interfaces over a pair of multimode or single mode optical fibers. The Terminal module units operate as the end or terminal points and provide an electrical connection and a two fiber optic connection. -
Page 4: Warranty
1.3 Warranty n Repair Please contact your local distributors when product is defective. Please apply RA in ¨ advance and prepay shipping cost when returning the defective product to us. We will pay the cost for sending it back to you. Please attach a statement clearly describing the problem. -
Page 5: Wall Mount Enclosure
2.2 Wall Mount Enclosure LED Indicators: POW: Power Supply On if power input is OK. ACT : RS-485 Data transmit/receive. Flashing if there is activity. TX1: The 1 channel Transmit Fiber Link Flashing if there is activity. RX1: The 1 channel Receive Fiber Link Flashing if there is activity.. -
Page 6: Caution
Fiber Connectors: FTX1: Fiber Optical ST of the 1 channel ( transmit & receive ) FRX1: NONE FTX2: Fiber Optical ST of the 2 channel ( transmit & receive) FRX2: NONE 2.3 Caution · Switch off all power supply before installation ·... -
Page 7: Install Application
2.4 Install Application Fiber Fifer Fiber Fiber Page 7 of 8... -
Page 8: Dimensions
3 Dimensions (mm) Page 8 of 8...
